IPC0172 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Development board/suite/development tools> IPC0172

Preview

IPC0172: DescriptionDFN-8/MLP-8 TO DIP-12 SMT ADAPTE; CategoryDevelopment board/suite/development tools; File Size36KB，2 Pages; ManufacturerChip Quik

Download Datasheet Parametric View All

IPC0172 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	IPC0172	-	-	View	Buy Now

IPC0172 Overview

DFN-8/MLP-8 TO DIP-12 SMT ADAPTE

IPC0172 Parametric

Parameter Name	Attribute value
Prototype board type	SMD to DIP
Accepted packages	DFN，MLP
Number of pins	8
spacing	0.050"（1.27mm）
Board thickness	0.063"（1.60mm）
Material	FR4 epoxy glass
size/dimensions	1.000" long x 0.600" wide (25.40mm x 15.24mm)

Preview

Download Datasheet

View All

IPC0172

Datasheet revision 1.0

www.Proto-Advantage.com

DFN-8/MLP-8 to DIP-12 SMT Adapter (1.27 mm pitch, 6 x 8 mm body)

DIMENSIONS

REF.

A

B

C

B2

C2

D

D2

E

F

G

H

MIN.

mm

TYP.

7.00

0.80

0.50

3.40

4.30

0.77

1.80

1.27

MAX.

MIN.

inches

TYP.

MAX.

0.600

0.100

0.025

Top View (SMT Footprint)

A

B

C

E

D

C2

B2

D2

(Representative drawing only - not to scale)
