PROFET™+ 12 V
BTS40k2-1ENC
Smart High-Side Power Switch Single Channel, 200 mΩ
Package
Marking
PG-TDSO-8-31
40k2-ENC
1
Application
•
•
Overview
Suitable for resistive, inductive and capacitive loads
Replaces electromechanical relays, fuses and discrete circuits
Voltage Regulator
OUT
GND
C
VDD
VS
V
BAT
T
1
C
VS
D
Z
R
OL
VDD
GPIO
R
DEN
DEN
VS
Microcontroller
OUT
GPIO
R
IN
IN
R
PD
C
OUT
Bulb
ADC IN
GND
R
SENSE
IS
GND
C
SENSE
R
IS
R
GND
D
Application_example_Single.emf
Application Diagram with BTS40k2-1ENC
Data Sheet
www.infineon.com/profet
1
Rev. 1.0
2018-05-14
PROFET™+ 12 V
BTS40k2-1ENC
Overview
Basic Features
•
•
•
•
•
•
•
•
•
Single channel device
Very low stand-by current
3.3 V and 5 V compatible logic inputs
Electrostatic discharge protection (ESD)
Optimized electromagnetic compatibility
Logic ground independent from load ground
Very low power DMOS leakage current in OFF state
Green product (RoHS compliant)
AEC qualified
Description
The BTS40k2-1ENC is a 200 mΩ single channel Smart High-Side Power Switch, embedded in a PG-TDSO-8-31,
Exposed Pad package, providing protective functions and diagnosis. The power transistor is built by an
N-channel vertical power MOSFET with charge pump. The device is integrated in Smart6 technology. It is
specially designed to drive relays and lamps up to 1x R5W 12V, as well as LEDs.
Table 1
Parameter
Operating voltage range
Maximum supply voltage
Maximum ON state resistance at
T
J
= 150°C
Nominal load current
Typical current sense ratio
Minimum current limitation
Maximum standby current with load at
T
J
= 25°C
Diagnostic Functions
•
•
•
•
•
•
•
•
•
•
•
•
Proportional load current sense
Open load detection in ON and OFF
Short circuit to battery and ground indication
Overtemperature switch off detection
Stable diagnostic signal during short circuit
Enhanced
k
ILIS
dependency with temperature and load current
Stable behavior during undervoltage
Reverse polarity protection with external components
Secure load turn-off during logic ground disconnection with external components
Overtemperature protection with restart
Overvoltage protection with external components
Enhanced short circuit operation
Product Summary
Symbol
V
S(OP)
V
S(LD)
R
DS(ON)
I
L(NOM)
k
ILIS
I
L5(SC)
I
S(OFF)
Value
5 V ... 36 V
65 V
400 mΩ
1.5 A
300
5A
500 nA
Protection Functions
Data Sheet
2
Rev. 1.0
2018-05-14
PROFET™+ 12 V
BTS40k2-1ENC
Pin Configuration
3
3.1
Pin Configuration
Pin Assignment
GND
IN
DEN
IS
Figure 2
Pin Configuration
1
2
3
4
8
7
6
5
OUT
OUT
OUT
NC
Pinout Single.vsd
3.2
Pin Definitions and Functions
Table 2
Pin
1
2
3
4
5
6, 7, 8
Cooling Tab
Pin Definitions and Functions
Symbol
GND
IN
DEN
IS
NC
OUT
VS
Function
GrouND:
Ground connection
INput channel:
Input signal for channel activation
Diagnostic ENable:
Digital signal to enable/disable the diagnosis of the
device
Sense:
Sense current of the selected channel
Not Connected:
No internal connection to the chip
OUTput:
Protected high side power output channel
1)
Voltage Supply:
Battery voltage
1) All output pins must be connected together on the PCB. All pins of the output are internally connected together. PCB
traces have to be designed to withstand the maximum current which can flow.
Data Sheet
4
Rev. 1.0
2018-05-14
