TABLE OF CONTENTS
L
SHEET NO.
SHEET DESCRIPTION
NOTES
L
1
2
3
4
5
6
K
DUAL KEY CONFIGURATION
SINGLE KEY CONFIGURATION
VIEWS
BOM
TERMINAL AND CABLE SEAL
K
3
J
CPA (OPTIONAL)
P/N 340660001
J
NOTES: VALID UNLESS OTHERWISE SPECIFIED
1. GENERAL:
a. APPLICATION SPECIFICATION SEE: 1600730001-AS
-CONTAINS: PRODUCT INTRODUCTION, PRODUCT SUMMARY,
CONNECTOR ASSEMBLY, PACKAGING INFORMATION, CONNECTOR
MATING, SERVICE INSTRUCTIONS, ELECTRICAL CONTINUITY
CHECKING, CRIMPING, AND TROUBLESHOOTING.
-DESIGNED TO MATE WITH DEVICE OR CONNECTOR AS SPECIFIED
H
H
1
RECEPTACLE HOUSING
P/N 342510001 (REF)
IN THE MATING INTERFACE/CONNECTOR DRAWINGS CHART.
*DENOTES DRAWINGS THAT CAN BE ACCESSED AT <http://ewcap.uscarteams.org/>.
-ASSEMBLY SHIPPED WITH PLR IN PRE-LOCK POSITION
G
4
PERIMETER SEAL
P/N 342530001
P/N 342530002
(SEE PLR PRE-LOCK VIEW SHEET 4).
b. PRODUCT SPECIFICATION SEE: 1600730001-PS
c. PACKAGING SPECIFICATION PER MOLEX DRAWING: SEE PK-31300-068
d. PARTS MUST BE IN COMPLIANCE TO MOLEX CHEMICAL SUBSTANCES FOR
PRODUCTS AND PACKAGING SPECIFICATION: QEHS-699000-301
e. DATA MUST BE SUBMITTED UNDER THE MOLEX PART NUMBER TO IMDS
G
(COMPANY ID#13255)
F
2
2. DESIGN - MATERIALS:
F
TPA
P/N 342520001
a. FOR BILL OF MATERIALS SEE: BOM IN SHEET 5
3. DESIGN - GEOMETRY:
a. THE 3-D CAD DATA IS BASIC (WITHOUT TOLERANCE) AND MASTER FOR THIS PART
WITH THE EXCEPTION OF UNDERLINED DIMENSIONS. DIMENSIONAL INFORMATION NOT SHOWN
ON THIS DRAWING IS DEFINED BY THE DATA FILE AT ITS LATEST REVISION.
E
b. GEOMETRIC DIMENSIONS AND TOLERANCES PER ASME Y14.5M-2009
c. EDGES AND UNDIMENSIONED DETAILS PER ISO13715
d. CORNERS SHOWN AS SHARP TO BE R 0.2 MAX.
E
e. LETTERING SHALL BE 0.15 MAX RAISED IN 0.25 MAX RECESS PAD.
THIS INCLUDES RECYCLING CODE, CAVITY ID, VENDOR IDENTIFICATION,
AND CUSTOMER MATERIAL NUMBER.
f. VISUAL DEFECTS SHALL MEET COSMETIC STANDARD PS-45499-002 (Class B).
D
g. LASER MARKING:
1. PART NUMBER
2. DAY OF THE YEAR
3. SHIFT
D
4. YEAR
FOR ADDITIONAL INFORMATION SEE SECTION 5 UNDER PROCEDURES IN ES-34735-008.
C
C
B
SYMBOLS
=
0
=
0
=
0
=
0
=
0
=
0
=
0
=
0
=
0
7
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
mm
ANGULAR TOL
±
±
±
±
±
±
2:1
3.0 °
CURRENT REV DESC:
B
GENERAL TOLERANCES
(UNLESS SPECIFIED)
4 PLACES
3 PLACES
2 PLACES
1 PLACE
0 PLACES
0.1
0.3
A
DRWN:
PXU25
CHK'D: KBORUSZEWSKI
APPR:
MVANSLAMBROU
INITIAL REVISION:
DRWN:
CYMA
APPR:
KDEKOSKI
THIRD ANGLE PROJECTION
DRAWING
EC NO:
171123
2017/12/26
2018/01/26
2018/02/02
2016/07/20
2017/02/08
SERIES
RECEPTACLE ASSEMBLY
3-WAY USCAR CONNECTOR 1.5MM CABLE SEAL
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
SD-160073-001
MATERIAL NUMBER
CUSTOMER
PSD
001
R
A
DOCUMENT STATUS
FORMAT: master-tb-prod-A1
REVISION: H
DATE: 2017/10/06
18
P1
17
RELEASE DATE
16
2018/02/02
15
15:21:24
C
14
13
12
11
10
9
8
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
6
5
A1-SIZE
160073
4
GENERAL MARKET
3
2
1 OF 6
