Terminal Blocks - Single Row
All Series Marking Options
Single Row Terminal Blocks
Marking Options & Accessories
Standard Marking
Markings are applied directly to the sides of Series 1000, 2000, 3000,
4000, and 5000. Standard characters are white and 1/8” high. Factory
may substitute 3/32” high characters.
Standard
marking
this side
Terminal Blocks:
Single Row
Blocks to be marked on both sides require a different code for
each side. Example: “L1” on one side of the block requires “L2”
on the other side to ensure common terminal marking. Specify by
adding suffix to part number.
EuroMag Series
1
3
L1
Upright Numerals
Left to Right
L2
Upright Numerals
Right to Left
L3
Left Lying Numerals
Left to Right
L4
Right Lying Numerals
Right to Left
L5
Upside-Down Numerals
Right to Left
L6
Upside-Down Numerals
Left to Right
Special Marking
Special markings are available upon request at an additional charge
for preparation. Production charges for setup, handling and marking
are the same as for standard marking and the same quantity
discounts apply. Consult factory for price and delivery.
Z
%
A
¤
RE
BL D
BL K
U
%
#
Ω
Closed Barrier Terminal Block Marking Options
for (CB1000, CB2000 and CB3000)
L1 & LT1 = Upright numerals, numbered from left to right
L2 & LT2 = Upright numerals, numbered from right to left
L3 = Left lying numerals, numbered from left to right
L4 = Right lying numerals, numbered from right to left
L5 & LT5 = Upside down numerals, numbered from right to left
L6 & LT6 = Upside down numerals, numbered from left to right
Options LT1 - LT6
Top Marking
For high visibility in tight packages.
6
5
4
3
2
1
8
7
8
7
6
5
4
3
2
1
Marker Strips
Black marker strips with white numerals mount beneath the terminal
blocks to clearly identify terminal and wire positions. Available with
forward or reverse markings, top or bottom of strip. If special
markings are required, submit a drawing.
1
1
2
2
3
3
4
4
1
1
2
2
3
3
4
4
4
4
3
3
2
2
1
1
4
4
3
3
Options L1 - L6
Regular Marking
2
2
Bottom Forward -
BF
Top Forward -
TF
Bottom Reverse -
BR
Top Reverse -
TR
M
n
n
S
n
Series
MS1
- 1000 Series
MS2
- 2000 Series
MS3
- 3000 Series
Base
n
nn
Poles
02
to
36
nn
Marking
1
- mount end, feed thru
2
- barrier end, feed thru
3
- mount end, insulator tubes
4
- barrier end, insulator tubes
5
- mount end, non feed-thru
BF
- bottom forward
TF
- top forward
BR
- bottom reverse
TR
- top reverse
For additional product information, visit
www.eaton.com/connectors
3
1
3
2
2
2
2
2
1
3
3
1
1
3
2
1
Edge Connectors,
One-Sided Boards
Compliance
References
