SERIES:
SDM36-UD
│
DESCRIPTION:
AC-DC POWER SUPPLY
FEATURES
• up to 36 W continuous power
• meets DoE Level VI efficiency
• universal input voltage range
• compact size
• no load power consumption < 0.10 W
• over voltage and short circuit protections
• UL/cUL, TUV, and PSE safety approvals
• LED indicator
• custom designs available
MODEL
SDM36-5-UD
SDM36-7.5-UD
SDM36-9-UD
SDM36-12-UD
SDM36-15-UD
SDM36-18-UD
SDM36-24-UD
Notes:
output
voltage
(Vdc)
output
current
max
(A)
output
power
max
(W)
ripple
and noise
1
max
(mVp-p)
efficiency
level
5
7.5
9
12
15
18
24
5
4
4
3
2.4
2
1.5
25
30
36
36
36
36
36
80
80
90
120
150
180
240
VI
VI
VI
VI
VI
VI
VI
1. At full load, nominal input, 20 MHz bandwidth oscilloscope, output terminated with 0.1 μF multilayer ceramic and 10 μF low ESR electrolytic capacitors.
PART NUMBER KEY
SDM36
-
XX
- UDX
-
XXX
-
CXX
Base Number
Output Voltage
AC Inlet Type:
IEC320/C8
Reserved for Custom
Configurations
DC Plug Type:
XXX = See output plug options
on page 5 for more details
Input Cable:
“Blank” = No Cable
C = North America input cable
2 = Europe input cable
cui.com
For more information, please visit the
product page
|
For information on related products, view
Dc Power Connectors
CUI Inc
│
SERIES:
SDM36-UD
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
01/29/2018
│
page
2 of 6
INPUT
parameter
voltage
frequency
current
inrush current
leakage current
no load power consumption
at 230 Vac
at 230 Vac, full load, 25°C, cold start
conditions/description
min
90
47
typ
max
264
63
1
70
0.1
0.10
units
Vac
Hz
A
A
mA
W
OUTPUT
parameter
regulation
conditions/description
5 Vdc model
all other models
min
typ
±6
±5
max
units
%
%
PROTECTIONS
parameter
over voltage protection
over current protection
short circuit protection
conditions/description
output shut down
output shut down, auto recovery
output shut down, auto recovery
min
typ
max
200
200
units
%
%
SAFETY & COMPLIANCE
parameter
isolation voltage
isolation resistance
safety approvals
EMI/EMC
MTBF
RoHS
conditions/description
input to output at 10 mA for 1 minute
input to output at 500 Vdc
Medical: UL/cUL, TUV
ITE: PSE
FCC Part 15B Class B, CE
as per Telcordia SR-332, 25°C
2011/65/EU
300,000
hours
10
min
typ
4,000
max
units
Vac
MΩ
ENVIRONMENTAL
parameter
operating temperature
storage temperature
operating humidity
storage humidity
non-condensing
non-condensing
conditions/description
min
0
-20
20
10
typ
max
40
80
80
90
units
°C
°C
%
%
cui.com
For more information, please visit the
product page
|
For information on related products, view
Dc Power Connectors
CUI Inc
│
SERIES:
SDM36-UD
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
01/29/2018
│
page
3 of 6
MECHANICAL
parameter
dimensions
inlet plug
weight
conditions/description
99 x 50 x 33
IEC320/C8
without ac cord
210
g
min
typ
max
units
mm
MECHANICAL DRAWING
units: mm
tolerance:±1.0 mm
DC CORD
units: mm
Table 1
MODEL NO.
SDM36-5-UD
SDM36-7.5-UD
SDM36-9-UD
SDM36-12-UD
SDM36-15-UD
SDM36-18-UD
SDM36-24-UD
CABLE
UL2468, 16 AWG
UL2468, 18 AWG
UL2468, 18 AWG
UL2468, 18 AWG
UL2468, 18 AWG
UL2468, 20 AWG
UL2468, 20 AWG
cui.com
CORD LENGTH
1,500 mm ±30
1,500 mm ±30
1,500 mm ±30
1,500 mm ±30
1,500 mm ±30
1,500 mm ±30
1,500 mm ±30
For more information, please visit the
product page
|
For information on related products, view
Dc Power Connectors
CUI Inc
│
SERIES:
SDM36-UD
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
01/29/2018
│
page
4 of 6
AC CORDS
units: mm
NORTH AMERICA
EUROPE
cui.com
For more information, please visit the
product page
|
For information on related products, view
Dc Power Connectors
CUI Inc
│
SERIES:
SDM36-UD
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
01/29/2018
│
page
5 of 6
DC PLUG TYPE PART NUMBER KEY
XXX
Plug Polarity:
P = Center Positive
N = Center Negative
Plug Code:
X = Choose a code from the
options below
Plug Angle:
“blank” = Straight
R = Right Angle
Plug Polarity
Center Pos.
●
●
●
●
●
●
●
●
●
●
N/A
N/A
Center Neg.
●
●
●
●
●
●
●
●
●
●
N/A
N/A
Code
Option
5
6
7
8
9
10
11
12
13
14
ST
MUB
USB
Type
Standard
Standard
Standard
Standard
Standard
Locking
Locking
EIAJ-1
EIAJ-2
EIAJ-3
A
Dimensions (mm)
B
2.1
2.5
1.35
1.35
1.05
2.1
2.5
0.7
1.7
1.7
Micro USB Type B
C
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
9.5
5.5
5.5
3.5
3.8
3.8
5.5
5.5
2.35
4.0
4.75
Plug Angle
Straight
●
●
●
●
●
●
●
●
●
●
N/A
●
Right
●
●
●
●
●
N/A
N/A
●
●
●
N/A
N/A
Stripped & Tinned
Note: 1. Contact CUI for additional plug options
Standard
C
EIAJ
C
B
A
A
B
C
B
A
A
C
B
Straight
Right Angle (R)
Straight
Right Angle (R)
Locking
C
Stripped & Tinned
USB
5.4±0.4
A
B
P5(-)
P1(+)
