WJ114FL
Distributor: Electro-Stock www.electrostock.com Tel: 630-682-1542 Fax: 630-682-1562
FEATURES:
•
Switching capacity 16A
•
Low profile 15.7mm
•
F Class insulation standard
•
UL/CUL certified
E197852
29.0 x 12.6 x 15.7 mm
CONTACT DATA
Contact Arrangement
1A = SPST N.O.
1B = SPST N.C.
1C = SPDT
12A @ 250VAC/30VDC general purpose
16A @ 250VAC/30VDC general purpose
< 50 milliohms initial
AgSnO
2
480W, 4000VA
440VAC, 110VDC
16A
Contact Rating
Contact Resistance
Contact Material
Maximum Switching Power
Maximum Switching Voltage
Maximum Switching Current
COIL DATA
Coil Voltage
VDC
Coil
Resistance
Ω ±
10%
Pick Up Voltage
VDC (max)
75%
of rated voltage
Release Voltage
VDC (min)
10%
of rated voltage
Coil Power
W
Operate Time
ms
Release Time
ms
Rated
Max.
5
6.5
62
3.75
0.5
6
7.8
90
4.50
0.6
9
11.7
202
6.75
0.9
.41
12
15.6
360
9.00
1.2
10
24
31.2
1440
18.00
2.4
48
62.4
5760
36.00
3.6
60
78.0
7500
45.00
4.5
.48
110
143.0
25200
82.50
8.25
CAUTION:
1. The use of any coil voltage less than the rated coil voltage may compromise the operation of the relay.
2. Pickup and release voltages are for test purposes only and are not to be used as design criteria.
5
GENERAL DATA
Electrical Life @ rated load
Mechanical Life
Insulation Resistance
Dielectric Strength, Coil to Contact
Contact to Contact
Shock Resistance
Vibration Resistance
Terminal (Copper Alloy) Strength
Operating Temperature
Storage Temperature
Solderability
Weight
100K cycles, typical
10M cycles, typical
1000MΩ min @ 500VDC
5000V rms min. @ sea level
1000V rms min. @ sea level
500m/s
2
for 11ms
1.50mm double amplitude 10-40Hz
5N
-40
°C
to + 125
°C
-40
°C
to + 155
°C
230
°C ±
2
°C
for 10
±
0.5s
13.5g
WJ114FL
Distributor: Electro-Stock www.electrostock.com Tel: 630-682-1542 Fax: 630-682-1562
ORDERING INFORMATION
1. Series:
WJ114FL
WJ114FL
2.Contact Arrangement:
1A = SPST N.O.
1B = SPDT N.C.
1C = SPDT
3. Sealing Options:
S = Sealed
4. Contact Rating:
12 = 12A
16 = 16A
5. Coil Voltage:
5VDC
6VDC
9VDC
12VDC
24VDC
48VDC
60VDC
110VDC
6. Terminal Spacing:
3.5 = 3.5mm
5.0 = 5.0mm **Standard for 16A version
1C
S
16
12VDC
5.0
DIMENSIONS (Units = mm)
SCHEMATICS & PC LAYOUTS (BOTTOM VIEWS)
1A (12A)
1B (12A)
1C (12A)
1A (16A)
1B (16A)
1C (16A)
