NLVVHC1GT04
Inverting Buffer /
CMOS Logic Level Shifter
LSTTL−Compatible Inputs
The NLVVHC1GT04 is a single gate inverting buffer fabricated
with silicon gate CMOS technology. It achieves high speed operation
similar to equivalent Bipolar Schottky TTL while maintaining CMOS
low power dissipation.
The internal circuit is composed of three stages, including a buffer
output which provides high noise immunity and stable output.
The device input is compatible with TTL−type input thresholds and
the output has a full 5 V CMOS level output swing. The input protection
circuitry on this device allows overvoltage tolerance on the input,
allowing the device to be used as a logic−level translator from 3 V
CMOS logic to 5 V CMOS Logic or from 1.8 V CMOS logic to 3 V
CMOS Logic while operating at the high−voltage power supply.
The NLVVHC1GT04 input structure provides protection when
voltages up to 7.0 V are applied, regardless of the supply voltage. This
allows the NLVVHC1GT04 to be used to interface 5 V circuits to 3 V
circuits. The output structures also provide protection when V
CC
=
0 V. These input and output structures help prevent device destruction
caused by supply voltage − input/output voltage mismatch, battery
backup, hot insertion, etc.
Features
www.onsemi.com
MARKING
DIAGRAMS
5
5
1
SC−88A
DF SUFFIX
CASE 419A
1
VK M
G
G
M
5
5
1
TSOP−5
DT SUFFIX
CASE 483
1
VK M
G
G
•
•
•
•
•
•
•
•
•
High Speed: t
PD
= 3.8 ns (Typ) at V
CC
= 5 V
Low Power Dissipation: I
CC
= 1
mA
(Max) at T
A
= 25°C
TTL−Compatible Inputs: V
IL
= 0.8 V; V
IH
= 2 V
CMOS−Compatible Outputs: V
OH
> 0.8 V
CC
; V
OL
< 0.1 V
CC
@ Load
Power Down Protection Provided on Inputs and Outputs
Balanced Propagation Delays
Pin and Function Compatible with Other Standard Logic Families
VK = Device Code
M
= Date Code*
G
= Pb−Free Package
(Note: Microdot may be in either location)
*Date Code orientation and/or position may vary
depending upon manufacturing location.
PIN ASSIGNMENT
1
2
3
4
5
NC
IN A
GND
OUT Y
V
CC
Chip Complexity: FETs = 105; Equivalent Gates = 26
NLV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
•
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
NC
IN A
GND
1
2
3
4
OUT Y
5
V
CC
FUNCTION TABLE
A Input
L
H
Y Output
H
L
Figure 1. Pinout
(Top View)
IN A
1
OUT Y
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 4 of this data sheet.
Figure 2. Logic Symbol
©
Semiconductor Components Industries, LLC, 2015
1
November, 2015 − Rev. 0
Publication Order Number:
NLVVHC1GT04/D
NLVVHC1GT04
MAXIMUM RATINGS
Symbol
V
CC
V
IN
V
OUT
I
IK
I
OK
I
OUT
I
CC
P
D
q
JA
T
L
T
J
T
stg
V
ESD
DC Supply Voltage
DC Input Voltage
DC Output Voltage
Input Diode Current
Output Diode Current
DC Output Current, per Pin
DC Supply Current, V
CC
and GND
Power dissipation in still air
Thermal resistance
Lead temperature, 1 mm from case for 10 s
Junction temperature under bias
Storage temperature
ESD Withstand Voltage
Human Body Model (Note 1)
Machine Model (Note 2)
Charged Device Model (Note 3)
Above V
CC
and Below GND at 125°C (Note 4)
SC−88A, TSOP−5
SC−88A, TSOP−5
V
OUT
< GND; V
OUT
> V
CC
V
CC
= 0
High or Low State
Characteristics
Value
−0.5 to +7.0
−0.5 to +7.0
−0.5 to 7.0
−0.5 to V
CC
+ 0.5
−20
+20
+25
+50
200
333
260
+150
−65 to +150
> 2000
> 400
N/A
±500
Unit
V
V
V
mA
mA
mA
mA
mW
_C/W
°C
°C
°C
V
I
Latchup
Latchup Performance
mA
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
1. Tested to EIA/JESD22−A114−A
2. Tested to EIA/JESD22−A115−A
3. Tested to JESD22−C101−A
4. Tested to EIA/JESD78
RECOMMENDED OPERATING CONDITIONS
Symbol
V
CC
V
IN
V
OUT
T
A
t
r
, t
f
DC Supply Voltage
DC Input Voltage
DC Output Voltage
Operating Temperature Range
Input Rise and Fall Time
V
CC
= 3.3 V
±
0.3 V
V
CC
= 5.0 V
±
0.5 V
V
CC
= 0
High or Low State
Characteristics
Min
3.0
0.0
0.0
0.0
−55
0
0
Max
5.5
5.5
5.5
V
CC
+125
100
20
Unit
V
V
V
°C
ns/V
Functional operation above the stresses listed in the Recommended Operating Ranges is not implied. Extended exposure to stresses beyond
the Recommended Operating Ranges limits may affect device reliability.
DEVICE JUNCTION TEMPERATURE VERSUS
TIME TO 0.1% BOND FAILURES
NORMALIZED FAILURE RATE
Junction
Temperature
°C
80
90
100
110
120
130
140
Time, Hours
1,032,200
419,300
178,700
79,600
37,000
17,800
8,900
Time, Years
117.8
47.9
20.4
9.4
4.2
2.0
1.0
FAILURE RATE OF PLASTIC = CERAMIC
UNTIL INTERMETALLICS OCCUR
TJ = 130
°
C
TJ = 120
°
C
TJ = 100
°
C
TJ = 110
°
C
TJ = 80
°
C
100
TIME, YEARS
TJ = 90
°
C
1
1
10
1000
Figure 3. Failure Rate vs. Time Junction Temperature
www.onsemi.com
2
NLVVHC1GT04
DC ELECTRICAL CHARACTERISTICS
V
CC
(V)
3.0
4.5
5.5
3.0
4.5
5.5
V
IN
= V
IH
or V
IL
I
OH
= −50
mA
V
IN
= V
IH
or V
IL
I
OH
= −4 mA
I
OH
= −8 mA
V
IN
= V
IH
or V
IL
I
OL
= 50
mA
V
IN
= V
IH
or V
IL
I
OL
= 4.0 mA
I
OL
= 8.0 mA
V
IN
= 5.5 V or GND
V
IN
= V
CC
or GND
Input: V
IN
= 3.4 V
V
OUT
= 5.5 V
3.0
4.5
3.0
4.5
3.0
4.5
3.0
4.5
0 to
5.5
5.5
5.5
0.0
2.9
4.4
2.58
3.94
0.0
0.0
0.1
0.1
0.36
0.36
±0.1
1.0
1.35
0.5
3.0
4.5
T
A
= 25°C
Min
1.4
2.0
2.0
0.53
0.8
0.8
2.9
4.4
2.48
3.80
0.1
0.1
0.44
0.44
±1.0
20
1.50
5.0
Typ
Max
T
A
≤
85°C
Min
1.4
2.0
2.0
0.53
0.8
0.8
2.9
4.4
2.34
3.66
0.1
0.1
0.52
0.52
±1.0
40
1.65
10
mA
mA
mA
mA
V
V
Max
−55
≤
T
A
≤
125°C
Min
1.4
2.0
2.0
0.53
0.8
0.8
Max
Unit
V
Symbol
V
IH
Parameter
Minimum High−Level
Input Voltage
Maximum Low−Level
Input Voltage
Minimum High−Level
Output Voltage
V
IN
= V
IH
or V
IL
Test Conditions
V
IL
V
V
OH
V
V
V
OL
Maximum Low−Level
Output Voltage
V
IN
= V
IH
or V
IL
I
IN
I
CC
I
CCT
I
OPD
Maximum Input
Leakage Current
Maximum Quiescent
Supply Current
Quiescent Supply
Current
Output Leakage
Current
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
AC ELECTRICAL CHARACTERISTICS
C
load
= 50 pF, Input t
r
= t
f
= 3.0 ns
T
A
= 25°C
Symbol
t
PLH
,
t
PHL
Parameter
Maximum Propagation
Delay, Input A to Y
Test Conditions
V
CC
= 3.3
±
0.3 V
V
CC
= 5.0
±
0.5 V
C
IN
Maximum Input
Capacitance
C
L
= 15 pF
C
L
= 50 pF
C
L
= 15 pF
C
L
= 50 pF
Min
Typ
5.0
6.2
3.8
4.2
5.0
Max
10.0
13.5
6.7
7.7
10
T
A
≤
85°C
Min
Max
11.0
15.0
7.5
8.5
10
−55
≤
T
A
≤
125°C
Min
Max
13.0
17.5
8.5
9.5
10
pF
Unit
ns
Typical @ 25°C, V
CC
= 5.0 V
C
PD
Power Dissipation Capacitance (Note 5)
10
pF
5. C
PD
is defined as the value of the internal equivalent capacitance which is calculated from the operating current consumption without load.
Average operating current can be obtained by the equation: I
CC(OPR
)
= C
PD
V
CC
f
in
+ I
CC
. C
PD
is used to determine the no−load dynamic
power consumption; P
D
= C
PD
V
CC2
f
in
+ I
CC
V
CC
.
www.onsemi.com
3
NLVVHC1GT04
A
50%
GND
t
PLH
Y
50% V
CC
V
OL
t
PHL
V
OH
3.0 V
Figure 4. Switching Waveforms
TEST POINT
OUTPUT
DEVICE
UNDER
TEST
C
L
*
*Includes all probe and jig capacitance
Figure 5. Test Circuit
ORDERING INFORMATION
Device
NLVVHC1GT04DFT1G*
NLVVHC1GT04DFT2G*
NLVVHC1GT04DTT1G*
Package Type
SC−88A
(Pb−Free)
3000 / Tape & Reel
TSOP−5
(Pb−Free)
Package
†
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specifications Brochure, BRD8011/D.
*NLV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP
Capable.
www.onsemi.com
4
NLVVHC1GT04
PACKAGE DIMENSIONS
SC−88A (SC−70−5/SOT−353)
CASE 419A−02
ISSUE L
A
G
NOTES:
1. DIMENSIONING AND TOLERANCING
PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. 419A−01 OBSOLETE. NEW STANDARD
419A−02.
4. DIMENSIONS A AND B DO NOT INCLUDE
MOLD FLASH, PROTRUSIONS, OR GATE
BURRS.
5
4
S
1
2
3
−B−
DIM
A
B
C
D
G
H
J
K
N
S
D
5 PL
0.2 (0.008)
M
B
M
N
J
C
INCHES
MIN
MAX
0.071
0.087
0.045
0.053
0.031
0.043
0.004
0.012
0.026 BSC
---
0.004
0.004
0.010
0.004
0.012
0.008 REF
0.079
0.087
MILLIMETERS
MIN
MAX
1.80
2.20
1.15
1.35
0.80
1.10
0.10
0.30
0.65 BSC
---
0.10
0.10
0.25
0.10
0.30
0.20 REF
2.00
2.20
H
K
SOLDER FOOTPRINT
0.50
0.0197
0.65
0.025
0.65
0.025
0.40
0.0157
1.9
0.0748
SCALE 20:1
mm
inches
www.onsemi.com
5
