74HC4051D Overview

IC MUX 8:1 4 OHM 16SOIC

74HC4051D Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Toshiba Semiconductor
package instruction	,
Reach Compliance Code	unknown
Factory Lead Time	12 weeks
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

74HC4051D,74HC4052D

CMOS Digital Integrated Circuits Silicon Monolithic

74HC4051D,74HC4052D

1. Functional Description

74HC4051D:8-Channel Analog Multiplexer/Demultiplexer

74HC4052D:Dual 4-Channel Analog Multiplexer/Demultiplexer

2. General

The 74HC4051D, 74HC4052D are high speed CMOS ANALOG MULTIPLEXER/DEMULTIPLEXER fabricated

with silicon gate C

MOS technology. They achieve the high speed operation similar to equivalent LSTTL while

maintaining the CMOS low power dissipation.

The 74HC4051D has an 8 channel configuration and the 74HC4052D has a 4 channel× 2 configuration.

The digital signal to the control terminal turns "ON" the corresponding switch of each channel a large amplitude

signal (V

- V

) can then be switched by the small logical amplitude (V

- GND) control signal.

For example, in the case of V

= 5 V, GND = 0 V, V

= -5 V, signals between -5 V and +5 V can be switched

from the logical circuit with a single power supply of 5 V. As the ON-resistance of each switch is low, they can be

connected to circuits with low input impedance.

All inputs are equipped with protection circuits against static discharge or transient excess voltage.

3. Features

(1)

(2)

(3)

Low power dissipation: I

= 4.0

µA

(max) (V

= 6.0 V, V

= GND, T

= 25

)

Low ON-resistance: R

= 130

Ω

(typ. V

= V

), 75

Ω

(typ. V

= V

) at V

- V

= 9 V

High noise immunity: THD = 0.02 % (typ.) at V

- V

= 9 V

4. Packaging

SOIC16

Start of commercial production

2016-04

2016-09-12

Rev.3.0

74HC4051D Related Products

	74HC4051D	74HC4052D
Description	IC MUX 8:1 4 OHM 16SOIC	IC MUX 2 X 4:1 4 OHM 16SOIC
Is it Rohs certified?	conform to	conform to
Maker	Toshiba Semiconductor	Toshiba Semiconductor
Reach Compliance Code	unknown	unknown
Factory Lead Time	12 weeks	12 weeks
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER	DIFFERENTIAL MULTIPLEXER
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	1	1
