S-1711 Series
www.ablic.com
www.ablicinc.com
© ABLIC Inc., 2004-2015
SUPER-SMALL PACKAGE 2-CIRCUIT HIGH RIPPLE-REJECTION
LOW DROPOUT CMOS VOLTAGE REGULATOR
Rev.3.1
_02
The S-1711 Series is a 2-channel positive voltage regulator with a low dropout voltage, high-accuracy output voltage, and
low current consumption (150 mA output current) developed based on CMOS technology.
A 1.0
F
small ceramic capacitor can be used, and a 2-circuit voltage regulator with
1.0%
high-accuracy output voltage is
incorporated in SOT-23-6 or super-small SNT-6A package. A/ B/ E/ F type is provided with a discharge shunt function
allowing high-speed output response when the ON/OFF pin is used.
Compared with the conventional 150 mA output current 2-channel CMOS voltage regulators, high-density mounting is
realized by using super-small SNT-6A package and a small ceramic capacitor. Also, the low current consumption makes
the S-1711 Series ideal for mobile devices.
Features
1.5 V to 5.5 V, selectable in 0.1 V step
2.0 V to 6.5 V
1.0%
200 mV typ. (3.0 V output product, I
OUT
= 150 mA)
During operation:
70
A
typ., 90
A
max. (Per circuit)
During power-off:
0.1
A
typ., 1.0
A
max.
Possible to output 150 mA (V
IN
V
OUT(S)
1.0 V)
*1
(Per circuit)
Output current:
Input and output capacitors:
A ceramic capacitor of 1.0
F
or more can be used.
Ripple rejection:
70 dB typ. (f = 1.0 kHz)
Built-in overcurrent protection circuit: Limits overcurrent of output transistor.
Built-in ON/OFF circuit:
Ensures long battery life.
Pull-up or pull-down resistor is selectable.
Discharge shunt function is selectable.
Operation temperature range:
Ta =
40C
to
85C
*2
Lead-free, Sn 100%, halogen-free
*1.
Attention should be paid to the power dissipation of the package when the output current is large.
*2.
Refer to “
Product Name Structure”
for details.
Output voltage:
Input voltage:
Output voltage accuracy:
Dropout voltage:
Current consumption:
Applications
Constant-voltage power supply for cellular phone
Constant-voltage power supply for battery-powered device
Constant-voltage power supply for home electric appliance
Packages
SNT-6A
SOT-23-6
1
