FACTSHEET F-201
CPC2–028–F– 03–SG
CPC4–128–S–SG
CPC2–020–S–01–SG
CPC2–016–S–02–SG–CU
CPC4–064–S–SG
CHIP PACKAGE
CPC2, CPC4 SERIES
SPECIFICATIONS
Materials:
Insulator Material:
Liquid Crystal Polymer
Contact Material:
Phosphor Bronze
Operating Temp Range:
-65°C to +105°C with Tin;
-65°C to +125°C with Gold
Plating:
Au over 50µ"
(1,27µm) Ni
Current Rating:
Testing Now!
Max Processing Temp:
230°C for 60 seconds
SMT Lead Coplanarity:
(0,10mm) .004" max
CPC2
NO. OF
POSITIONS
LEAD
PITCH
BODY
STYLE
Specify
BODY
STYLE
from
chart
BODY
STYLE
–01
–02
–03
A
B
PLATING
OPTION
OTHER
OPTION
–S
004, 008, 010, 016,
020, 024, 028
No. of positions x pitch / 2
+ (3,81) .150
No. of positions x
pitch / 2 + (1,50) .059
No. of positions
x pitch / 2
+ (0,08) .003
= (0,64mm)
.025" Pitch
–F
= (1,27mm)
.050" Pitch
LEAD
PITCH
–S
–F
D
(0,64)
.025
(1,27)
.050
= 30
µ
"
(0,76
µ
m)
Soft Gold
(.9999 pure)
–SG
Leave blank
for Cavity
Down
–CU
= Cavity
Up
C
–LDC
= (1,52mm)
.060" thick
cupped
lid with
(0,76mm)
.030" cavity
(3,81) (7,54) (9,68)
.150 .297 .381
(7,62) (11,35) (13,49)
.300 .447 .531
(12,70) (16,43) (18,57)
.500 .647 .731
B
A
C
(2,31)
.091
(0,81)
.032
–LDF
(0,71)
.028 TYP
(2,79) (1,65)
.110 .065
(1,14)
.045
= (0,76mm)
.030" thick
flat lid
–CU Option
(Cavity up)
ALSO AVAILABLE
Optional
lids for
chip/wire
bond
protection.
(0,20)
.008
D
Standard Option
(Cavity down)
CPC4
NO. OF POSITIONS
S
PLATING
OPTION
OTHER
OPTION
Leave blank for
Cavity Down
–064, –128
C (SQ)
= 30
µ
" (0,76
µ
m)
Soft Gold
(.9999 pure)
–SG
–CU
= Cavity Up
B (SQ)
A (SQ)
NO. OF
POSITIONS
064
128
–LDC
A
B
C
(12,01) (15,75) (17,88)
.473
.620
.704
(21,67) (25,40) (27,53)
.853 1.000 1.084
= (1,52mm) .060"
thick cupped
lid with
(0,76mm) .030"
cavity
–LDF
(0,20)
.008
(0,64)
.025
(1,14)
.045
(1,65)
.065
(0,81)
.032
(2,79)
.110
= (0,76mm) .030"
thick flat lid
–CU Option
(Cavity up)
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
Standard Option
(Cavity down)
Due to technical progress, all designs, specifications and components are subject to change without notice.
