OPIA814, OPIA815, OPIA817
OPIA1210, OPIA4010
DIP Package
Features:
•
•
•
•
•
•
5,000 Vrms electrical isolation
Choice of a Single and Dual LED
Phototransistor or Photodarlington Sensor
Low-cost plastic Dual-In-Line (DIP) package
UL Certification No: E58730
VDE No
:
40026625 40026536, 40026654
Approval Agency:
Description:
The OPIA series optocouplers are designed for applications that use an analog output (Phototransistor or
Photodarlington) in a dual-in-line package. A wide selection of configurations are available. With typical isolation
voltage of 5,000 Volts(RMS), these products meet typical power system isolation requirements.
Theory of operation: The LED transmitter is used to illuminate the Photosensor providing electrical isolation
between two power systems while maintaining the ability to transmit information from one power system to the
other. In many applications, analog signal levels may be required to be transmitted between two power systems
while maintaining isolation between the power systems up to 5,000 volts(RMS). A variety of LED and photosensor
configurations are available depending on the system requirements.
The ratio Current Transfer Ratio (CTR) is determined by using the output current and input current for analog
photosensors. CTR ratios can range from as low as 5 to over 9,000 depending on the device.
CTR
=
Photosenso
r
−
Current
LED
−
Current
=
20
mA
* 100
=
200
10
mA
All DIP product is shipped in a shipping tube with “TU” identified on the end of the part number.
Example: OPIA817DTUE is a 4-Pin DIP shipped in a tube (TU).
Applications:
•
•
•
•
•
High voltage isolation: 5,000 Volts RMS
PCBoard power system isolation
Industrial equipment power isolation
Medical equipment power isolation
Office equipment
RoHS
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Issue A.5
8/09
Page 1 of 17
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
OPIA814, OPIA815, OPIA817
OPIA1210, OPIA4010
DIP Package
Package Outline Dimensions and Schematics:
Top-View
Pin #
Part Number
1
OPIA817
OPIA814
OPIA815
OPIA4010
OPIA1210
A
A-K
A
A
A
2
K
K-A
K
K
K
3
E
E
E
E
E
4
C
C
C
C
C
Analog Output Devices Ordering Information
Part Number
OPIA817D
OPIA814D
OPIA815D
OPIA4010D
OPIA1210D
Isolation Voltage
Max. (Vrms)
5,000
5,000
5,000
5,000
5,000
CTR
Min/Typ/Max
Typ. Tr / Tf (µs)
R
L
= 100 ohms
Package
4-Pin DIP
4-Pin DIP
4-Pin DIP
4-Pin DIP
4-Pin DIP
Configuration
A K—C E
A K, K A—C E
A K—C E (Dar)
A K—C E (Dar)
A K—C E
50 / - / 600
4/3
60 / - / 600
5/4
70 / - / -
80 / 72
600 / - / 9,000
60 / 50
50 / - / 600
2/3
Configuration: Definition of Terms
LED Identification—Sensor Identification
A = Anode
B = Base
K = Cathode
C = Collector
Configuration
Information
LED
Sensor
E = Emitter
(Dar) = Photodarlington
Example:
OPIA817DTUE
Packaging
Part Number Suffix:
TU
= Shipped in Tubes
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Issue A.5
8/09
Page 2 of 17
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
OPIA814, OPIA815, OPIA817
OPIA1210, OPIA4010
DIP Package
Absolute Maximum Ratings
(T
A
= 25
o
C unless otherwise noted)
Storage Temperature
Operating Temperature
Isolation voltage (1 minute)
Total Package Power Dissipation
Lead Soldering Temperature (1/16” (1.6 mm) from case for 5 seconds with soldering iron)
Input Diode
-55° C to +125° C
-30° C to +100° C
5,000 Vrms
200 mW
260° C
Continuous Forward Current
Peak Forward current (1 µs pulse width, 300 pps)
Reverse Voltage
OPIA817, OPIA815, OPIA4010, OPIA1210
OPIA814, OPIA4010
Power Dissipation
Output Phototransistor
50 mA
1A
6V
-
70 mW
Collector-Emitter Voltage
OPIA817, OPIA814
OPIA4010
OPIA815
OPIA1210
Emitter-Collector Voltage
OPIA817, OPIA814, OPIA815
OPIA4010
OPIA1210
Collector Current
OPIA817, OPIA814, OPIA1210
OPIA4010
OPIA815
Power Dissipation
All except the part numbers noted below
OPIA4010
60 V
300 V
35 V
350 V
6V
0.1 V
7V
50 mA
150 mA
80 mA
150 mW
200 mW
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
Issue A.5
8/09
Page 3 of 17
OPIA814, OPIA815, OPIA817
OPIA1210, OPIA4010
DIP Package
Electrical Characteristics
SYMBOL
PARAMETER
MIN
TYP
MAX
UNITS
TEST CONDITIONS
Input Diode
V
F
Forward Voltage
All except those noted below
OPIA1210
Peek Forward Voltage
OPIA814, OPIA4010
OPIA1210
Reverse Current
All except those noted below
OPIA814
OPIA1210
Terminal Capacitance
All except those noted below
OPIA815
-
1.0
1.2
1.2
1.4
1.3
I
F
= 20 mA
I
F
= 10 mA
V
V
FM
-
-
-
-
3.5
3.0
V
I
FM
= 500 mA
I
R
-
-
-
-
-
-
-
-
30
30
10
-
10
-
250
µA
V
R
= 4 V
-
V
R
= 5 V
V = 0.0 V, f = 1K Hz
V = 0.0 V, f = 1K Hz
C
t
pf
Output Phototransistor
I
CEO
Collector Dark Current
OPIA817, OPIA814
OPIA1210
Collector-Emitter Saturation Voltage
OPIA817
OPIA814
OPIA1210
Cutt-Off Frequency
All except those noted below
OPIA817, OPIA814, OPIA1210
Rise Time
OPIA817
OPIA814
OPIA1210
Fall Time
OPIA817D
OPIA814
OPIA1210
-
-
-
10
100
200
I
F
= 0 mA, V
CE
= 20 V
I
F
= 0 mA, V
CE
= 300 V
nA
V
CE(SAT)
-
-
-
-
-
0.1
0.1
-
-
80
0.2
0.3
0.4
-
-
V
I
F
= 20 mA, I
C
= 1 mA
I
F
= 20 mA, I
C
= 1 mA
I
F
= 8 mA, I
C
= 2.4 mA
f
C
K Hz
V
CC
= 5 V, I
C
= 2 mA, R
L
= 100
Ω
t
R
-
-
-
4
5
2
18
20
-
µs
V
CC
= 2 V, I
C
= 2 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 2 mA, R
L
= 100
Ω
V
CC
= 10 V, I
C
= 2 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 2 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 2 mA, R
L
= 100
Ω
V
CC
= 10 V, I
C
= 2 mA, R
L
= 100
Ω
t
F
-
-
-
3
4
3
18
20
-
µs
Continued on Next Page
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
Issue A.5
8/09
Page 4 of 17
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
OPIA814, OPIA815, OPIA817
OPIA1210, OPIA4010
DIP Package
Electrical Characteristics - Continued from Previous Page
SYMBOL
PARAMETER
MIN
TYP
MAX
UNITS
TEST CONDITIONS
Output PhotoDarlington
I
CEO
Collector Dark Current
OPIA4010
OPIA815
Collector-Emitter Saturation Voltage
OPIA815
OPIA4010
Cut-Off frequency
OPIA815
OPIA4010
Rise Time
OPIA815
OPIA4010
Fall Time
OPIA815
OPIA4010
-
-
-
-
1.0
-
-
-
-
-
-
-
0.8
-
6.0
7.0
80
60
72
50
1.0
1.0
1.0
1.5
-
-
300
300
250
250
I
F
= 0 mA, V
CE
= 200 V
I
F
= 0 mA, V
CE
= 10 V
I
F
= 20 mA, I
C
= 5 mA
I
F
= 20 mA, I
C
= 5 mA
V
CC
= 2 V, I
C
= 20 mA, R
L
= 100
Ω
V
CC
= 5 V, I
C
= 2 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 20 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 20 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 20 mA, R
L
= 100
Ω
V
CC
= 2 V, I
C
= 20 mA, R
L
= 100
Ω
µA
V
CE(SAT)
V
f
C
K Hz
t
r
µs
t
f
µs
Coupled Characteristics
Current Transfer Ratio
OPIA817, OPIA1210
OPIA814
OPIA815
OPIA4010
Floating Capacitance
Isolation Resistance
50
60
70
600
-
5X10
10
-
-
-
-
0.6
10
11
600
600
-
9,000
1.0
-
I
F
= 5.00 mA, V
CE
= 5.0 V
I
F
= 1.00 mA, V
CE
= 2.0 V
I
F
= 0.05 mA, V
CE
= 3.3 V
I
F
= 1.00 mA, V
CE
= 2.0 V
V = 0.0 V, f = 1M Hz
C500V, 40% to 60%RH
CTR
%
C
f
R
ISO
pF
ohm
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. —
1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747
FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
Issue A.5
8/09
Page 5 of 17
