LTC2966C ................................................ 0°C to 70°C
LTC2966I .............................................–40°C to 85°C
LTC2966H .......................................... –40°C to 125°C
Storage Temperature Range .................. –65°C to 150°C
Lead Temperature (Soldering, 10 sec)................... 300°C
PIN CONFIGURATION
TOP VIEW
TOP VIEW
OUTA
OUTB
V
INA
V
INB
V
INA
1
NC 2
OUTA 3
12 GND
17
GND
11 INHB
10 INLB
9
5
RS2A
6
PSA
7
PSB
8
RS2B
RS1B
NC 4
REF 5
INHA 6
INLA 7
RS1A 8
RS2A 9
PSA 10
SW PACKAGE
20-LEAD PLASTIC SO
T
JMAX
= 150°C,
θ
JA
= 35°C/W
20 V
INB
19 NC
18 OUTB
17 NC
16 GND
15 INHB
14 INLB
13 RS1B
12 RS2B
11 PSB
16 15 14 13
REF 1
INHA 2
INLA 3
RS1A 4
UD PACKAGE
16-LEAD (3mm
×
3mm) PLASTIC QFN
T
JMAX
= 150°C,
θ
JA
= 68°C/W
EXPOSED PAD (PIN 17) PCB GND CONNECTION OPTIONAL
ORDER INFORMATION
LEAD FREE FINISH
TUBE
LTC2966CUD#PBF
LTC2966IUD#PBF
LTC2966HUD#PBF
LTC2966CSW#PBF
LTC2966ISW#PBF
LTC2966HSW#PBF
TAPE AND REEL
LTC2966CUD#TRPBF
LTC2966IUD#TRPBF
LTC2966HUD#TRPBF
LTC2966CSW#TRPBF
LTC2966ISW#TRPBF
LTC2966HSW#TRPBF
http://www.linear.com/product/LTC2966#orderinfo
PART MARKING*
LGMG
LGMG
LGMG
LTC2966SW
LTC2966SW
LTC2966SW
PACKAGE DESCRIPTION
16-Lead (3mm × 3mm) Plastic QFN
16-Lead (3mm × 3mm) Plastic QFN
16-Lead (3mm × 3mm) Plastic QFN
TEMPERATURE RANGE
0°C to 70°C
–40°C to 85°C
–40°C to 125°C
20-Lead Plastic Small Outline (Wide .300 Inch) 0°C to 70°C
20-Lead Plastic Small Outline (Wide .300 Inch) –40°C to 85°C
20-Lead Plastic Small Outline (Wide .300 Inch) –40°C to 125°C
Consult LTC Marketing for parts specified with wider operating temperature ranges. *The temperature grade is identified by a label on the shipping container.
Consult LTC Marketing for information on nonstandard lead based finish parts.
For more information on lead free part marking, go to:
http://www.linear.com/leadfree/
For more information on tape and reel specifications, go to:
http://www.linear.com/tapeandreel/.
Some packages are available in 500 unit reels through
designated sales channels with #TRMPBF suffix.
2966fc
2
For more information
www.linear.com/LTC2966
LTC2966
The
l
denotes the specifications which apply over the full operating
temperature range, otherwise specifications are at T
