1059686-1 Product Details
Live Product Chat
Product View
Blind Mate RF Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
1059686-1
T E I nternal N umber: 1 0 5 9 6 8 6 - 1
Product Highlights:
l
C onnector
l
OSP Miniature Modular Product Line
l
Terminate To Printed C ircuit Board
l
Plug
l
Not Sealed
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Product Line = OSP Miniature Modular
l
Gender
= Plug
l
Sealed = No
l
Body Style = Straight
l
Dielectric Material = TFE Fluorocarbon
l
Body Material = Stainless Steel
l
Body Finish = Gold
Mechanical Attachment:
l
Panel Attachment = Without
Electrical Characteristics:
l
Frequency = DC - 18 GHz
l
Insulation Resistance (M?) = 5,000
l
Impedance (Nominal) (?) = 50
Body Related Features:
l
O-Ring Material = Fluorosilicone
Contact Related Features:
l
C enter C ontact Material = Beryllium C opper
l
C enter C ontact Plating = Gold
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C , Reflow
solder capable to 245?C , Reflow solder capable to 260?C , Pin-in-
Paste capable to 245?C , Pin-in-Paste capable to 260?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Terminate To = Printed C ircuit Board
Other:
l
Brand = AMP
