173279-4 Product Details
Live Product Chat
Product Photo
.050 Series Board Mount Connectors
5 of 6 EU R oHS/ELV C om plia nt
(
Find R oHS C om plia nt
Alte rna te s
/
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
173279-4
T E I nternal N umber: 1 7 3 2 7 9 - 4
Product Highlights:
l
C onnector
l
C onnector Type = Receptacle
l
Number of Positions = 60
l
PC B Mount Angle = Vertical
l
Through Hole C ontact Termination Type
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
REPRESENTATIVE TERMINALS AND C ONNEC TORS
(PDF, English)
Product Specifications:
l
AMPLIMITE* .050 Series I, Board-to-Board C onnector
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version C )
l
3D Model
(IGES, Version C )
l
3D Model
(STEP, Version C )
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
C onnector Type = Receptacle
l
Number of Positions
= 60
l
PC B Mount Angle = Vertical
l
PC B Mount Polarization
= Without
l
Shielded
= No
l
Shell Type
= All Plastic
l
Product Series
= Series I
l
C omment = To mount connector to pc board, use M2 screws and
nuts (not supplied).
Mechanical Attachment:
l
Mating Retention = Without
l
Mating Alignment = Without
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.10 [0.122]
l
Termination Method = Through Hole
Body Related Features:
l
C enterline (mm [in]) = 1.27 [0.050]
l
Post Plating = Tin Lead over Nickel
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Mating Area Plating Material
= Gold Flash
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
l
Housing C olor = Black
Configuration Related Features:
l
PC B Mount Retention = With
l
PC B Mount Retention Type = Mounting Holes
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Conditions for Usage:
l
Terminate To = Printed C ircuit Board
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
