174216-1: DescriptionCONNECTOR,D-SHELL,PCB MNT,RECEPT,30 CONTACTS,PIN,0.05 PITCH,PC TAIL TERMINAL; CategoryThe connector The connector; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

174216-1 Overview

CONNECTOR,D-SHELL,PCB MNT,RECEPT,30 CONTACTS,PIN,0.05 PITCH,PC TAIL TERMINAL

174216-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	300072014
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	0
body width	0.287 inch
subject depth	0.165 inch
body length	1.01 inch
Body/casing type	RECEPTACLE
Contact to complete cooperation	AU ON NI
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
Dielectric withstand voltage	500VAC V
Insulation resistance	1000000000 Ω
Insulator color	BLACK
insulator material	POLYETHYLENE
Plug contact pitch	0.05 inch
Match contact row spacing	0.1 inch
Installation method	STRAIGHT
Installation type	BOARD
PCB row number	4
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
PCB contact row spacing	1.905 mm
Plating thickness	8u inch
Rated current (signal)	1 A
Guideline	UL, CSA
Terminal length	0.122 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	30

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

D-Subminiature C onnectors

Product Feature Selector

> Product Details

174216-1 Product Details

Live Product Chat

Product Photo

.050 Series Board Mount Connectors

5 of 6 EU R oHS/ELV C om plia nt

(

Find R oHS C om plia nt

Alte rna te s

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

174216-1

T E I nternal N umber: 1 7 4 2 1 6 - 1

Product Highlights:

C onnector

C onnector Type = Plug

Number of Positions = 30

PC B Mount Angle = Vertical

Through Hole C ontact Termination Type

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Obsolete

C ontact Product Information C enter

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

REPRESENTATIVE TERMINALS AND C ONNEC TORS

(PDF, English)

Product Specifications:

AMPLIMITE* .050 Series I, Board-to-Board C onnector

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= C onnector

C onnector Type = Plug

Number of Positions

= 30

PC B Mount Angle = Vertical

PC B Mount Polarization

= Without

Shielded

= No

Shell Type

= All Plastic

Product Series

= Series I

Flux Drain Holes = With

Mechanical Attachment:

Mating Retention = Without

Mating Alignment = Without

Termination Related Features:

Termination Post Length (mm [in])

= 3.10 [0.122]

Termination Method = Through Hole

Body Related Features:

C enterline (mm [in]) = 1.27 [0.050]

Post Plating = Tin Lead over Nickel

Contact Related Features:

C ontact Termination Type

= Through Hole

C ontact Mating Area Plating Material

= Gold Flash

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Material = Thermoplastic

Housing Flammability Rating = UL 94V-0

Housing C olor = Black

Configuration Related Features:

PC B Mount Retention = Without

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Wave solder capable to 240?C

Conditions for Usage:

Terminate To = Printed C ircuit Board

Other:

Brand = AMP

Additional Information:

Product Line Information
