175677-7 Product Details
Live Product Chat
Product View
1.27 [.050] Series II and Series III Connectors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
175677-7
T E I nternal N umber: 1 7 5 6 7 7 - 7
Product Highlights:
l
Mating Type = Plug
l
Number of Positions = 50
l
Terminate To C able
l
With Mating C onnector Lock
l
Wire Size = 28 mm? [AWG]
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
REPRESENTATIVE TERMINALS AND C ONNEC TORS
(PDF, English)
Product Specifications:
l
C HAMP.050 Series(II) C onnector Wire to Board Type
(PDF, English)
l
PRODUC T SPEC IFIC ATION, C HAMP 050 SERIES (II) C ONNEC TOR
(PDF, English)
Application Specifications:
l
C HAMP 050 II 75 Degree Type C onnector
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version L)
l
3D Model
(IGES, Version L)
l
3D Model
(STEP, Version L)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Mating Type
= Plug
l
Number of Positions
= 50
l
Mating C onnector Lock
= With
l
Wire Size (mm? [AWG])
= 28
l
Product Series
= Series II
l
Wire Insulation Diameter (mm [in]) = 0.51 – 0.71 [0.020 – 0.028]
l
Mating C onnector Lock Type = Use with Backshell Kit
l
C olor = Black
l
C over Material = Glass-filled PBT
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Solder Tail C ontact Plating = Tin-Lead
Body Related Features:
l
C enterline (mm [in]) = 1.27 [0.050]
l
C over Flammability Rating = UL 94V-0
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (12)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material Temperature
= Standard
l
Housing Material = PBT - GF
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Conditions for Usage:
l
Terminate To
= C able
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
