DM74ALS574A Octal D-Type Edge-Triggered Flip-Flop with 3-STATE Outputs
September 1986
Revised February 2000
DM74ALS574A
Octal D-Type Edge-Triggered Flip-Flop
with 3-STATE Outputs
General Description
These 8-bit registers feature totem-pole 3-STATE outputs
designed specifically for driving highly-capacitive or rela-
tively low-impedance loads. The high-impedance state and
increased high-logic-level drive provide these registers with
the capability of being connected directly to and driving the
bus lines in a bus-organized system without need for inter-
face or pull-up components. They are particularly attractive
for implementing buffer registers, I/O ports, bidirectional
bus drivers, and working registers.
The eight flip-flops of the DM74ALS574A are edge-trig-
gered D-type flip-flops. On the positive transition of the
clock, the Q outputs will be set to the logic states that were
set up at the D inputs.
A buffered output control input can be used to place the
eight outputs in either a normal logic state (HIGH or LOW
logic levels) or a high-impedance state. In the high-imped-
ance state the outputs neither load nor drive the bus lines
significantly.
The output control does not affect the internal operation of
the flip-flops. That is, the old data can be retained or new
data can be entered even while the outputs are OFF.
Features
s
Switching specifications at 50 pF
s
Switching specifications guaranteed over full tempera-
ture and V
CC
range
s
Advanced oxide-isolated, ion-implanted Schottky TTL
process
s
Functionally equivalent with DM74LS374
s
Improved AC performance over DM74LS374 at approxi-
mately half the power
s
3-STATE buffer-type outputs drive bus lines directly
Ordering Code:
Order Number
DM74ALS574AWM
DM74ALS574ASJ
DM74ALS574AN
Package Number
M20B
M20D
N20A
Package Description
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300 Wide
20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300 Wide
Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.
Connection Diagram
© 2000 Fairchild Semiconductor Corporation
DS006110
www.fairchildsemi.com
DM74ALS574A
Absolute Maximum Ratings
(Note 1)
Supply Voltage
Input Voltage
Voltage Applied to Disabled Output
Operating Free Air Temperature Range
Storage Temperature Range
Typical
θ
JA
N Package
M Package
56.0°C/W
75.0°C/W
7V
7V
5.5V
0°C to
+70°C
−65°C
to
+150°C
Note 1:
The “Absolute Maximum Ratings” are those values beyond which
the safety of the device cannot be guaranteed. The device should not be
operated at these limits. The parametric values defined in the Electrical
Characteristics tables are not guaranteed at the absolute maximum ratings.
The “Recommended Operating Conditions” table will define the conditions
for actual device operation.
Recommended Operating Conditions
Symbol
V
CC
V
IH
V
IL
I
OH
I
OL
f
CLOCK
t
W
t
SU
t
H
T
A
Supply Voltage
HIGH Level Input Voltage
LOW Level Input Voltage
HIGH Level Output Current
LOW Level Output Current
Clock Frequency
Width of Clock Pulse
Data Setup Time
Data Hold Time
HIGH
LOW
(Note 2)
(Note 2)
0
14
14
15
↑
0
↑
0
70
Parameter
Min
4.5
2
0.8
−2.6
24
35
Nom
5
Max
5.5
Units
V
V
V
mA
mA
MHz
ns
ns
ns
ns
°C
Free Air Operating Temperature
Note 2:
The (↑) arrow indicates the positive edge of the Clock is used for reference.
Electrical Characteristics
over recommended operating free air temperature range. All typical values are measured at V
CC
=
5V, T
A
=
25°C.
Symbol
V
IK
V
OH
Parameter
Input Clamp Voltage
HIGH Level
Output Voltage
V
OL
LOW Level
Output Voltage
V
CC
=
4.5V
V
IL
=
V
IL
Max
V
CC
=
4.5V to 5.5V
V
CC
=
4.5V
V
IH
=
2V
Conditions
V
CC
=
4.5V, I
I
= −18
mA
I
OH
=
Max
I
OH
= −400 µA
I
OL
=
12 mA
I
OL
=
24 mA
I
I
I
IH
I
IL
I
O
I
OZH
I
OZL
I
CC
Input Current at Max Input Voltage V
CC
=
5.5V, V
IH
=
7V
HIGH Level Input Current
LOW Level Input Current
Output Drive Current
OFF-State Output Current
HIGH Level Voltage Applied
OFF-State Output Current d
LOW Level Voltage Applied
Supply Current
V
CC
=
5.5V, V
IH
=
2.7V
V
CC
=
5.5V, V
IL
=
0.4V
V
CC
=
5.5V, V
O
=
2.25V
V
CC
=
5.5V, V
IH
=
2V
V
O
=
2.7V
V
CC
=
5.5V, V
IH
=
2V
V
O
=
0.4V
V
CC
=
5.5V
Outputs Open
Outputs HIGH
Outputs LOW
Outputs Disabled
11
17
17
−30
2.4
V
CC
−
2
0.25
0.35
0.4
0.5
0.1
20
−0.2
−112
20
−20
18
27
28
3.2
Min
Typ
Max
−1.2
Units
V
V
V
V
V
mA
µA
mA
mA
µA
µA
mA
mA
mA
3
www.fairchildsemi.com
