Power Capacitors
Series/Type:
B25832
The following products presented in this data sheet are being withdrawn.
Ordering Code
B25832F6255K001
B25832F6205K001
B25832F6155K001
Substitute Product
Date of
Withdrawal
2014-08-14
2014-08-14
2014-08-14
Deadline Last
Orders
2015-03-31
2015-03-31
2015-03-31
Last Shipments
2016-09-30
2016-09-30
2016-09-30
EPCOS AG 2015. Reproduction, publication and dissemination of this publication, enclosures hereto and
the information contained therein without EPCOS' prior express consent is prohibited.
EPCOS AG is a TDK Group Company.
Ordering Code
B25832F4705K001
B25832F4685K001
B25832F4505K001
B25832F4475K001
B25832F4405K001
B25832F4335K001
B25832F4305K011
B25832F4305K001
B25832F4255K001
B25832F4225K001
B25832F4205K001
B25832F4165K001
B25832F4155K001
B25832F4105K001
B25832C6805K009
B25832C6705K009
B25832C6605K009
B25832C6555K009
B25832C6505K009
B25832C6405K009
B25832C6305K009
B25832C6226K009
B25832C6206K009
B25832C6186K009
B25832C6156K009
B25832C6126K009
B25832C6106K009
B25832C4805K009
B25832C4605K009
B25832C4506K009
B25832C4476K009
B25832C4406K009
B25832C4336K009
B25832C4306K009
B25832C4256K009
B25832C4226K009
B25832C4206K009
B25832C4166K009
Substitute Product
Date of
Withdrawal
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
2014-08-14
Deadline Last
Orders
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
2015-03-31
Last Shipments
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
2016-09-30
Ordering Code
B25832C4156K009
B25832C4146K009
B25832C4126K009
B25832C4106K009
Substitute Product
Date of
Withdrawal
2014-08-14
2014-08-14
2014-08-14
2014-08-14
Deadline Last
Orders
2015-03-31
2015-03-31
2015-03-31
2015-03-31
Last Shipments
2016-09-30
2016-09-30
2016-09-30
2016-09-30
For further information please contact your nearest EPCOS sales office, which will also support you in selecting a suitable
substitute. The addresses of our worldwide sales network are presented at www.epcos.com/sales.
MKV AC Capacitors
General AC Applications
Features
■
Compact design
■
Long-term stability and reliability
B25832
Applications
■
For commutation in the low-frequency range
Construction
■
■
■
■
■
■
■
Self-healing
Plastic dielectric
Oil-impregnated tubular windings (no PCB)
Metal-sprayed end faces ensure reliable contacting
Cylindrical aluminum case
Ceramic or plastic lead-throughs
Mounting bolts M8 or M12
Terminals
■
Tab connectors 6.3 mm
■
Dual tab connectors 6.3 mm
Mounting
■
If the vibration stress is
≤
5
g
and the capacitors
are
≤
60 mm in diameter, the bolt is used for mounting.
Grounding
■
Mounting bolts for grounding in accordance with VDE 0100
■
Grounding identification in accordance with DIN 40 011
Individual data sheets
Individual data sheets contain detailed specification incl. thermal data.
Upon request, these data sheets are available for each capacitor type.
Please read
Cautions and warnings
and
Important notes
at the end of this document.
2
09/05
MKV AC Capacitors
General AC Applications
Technical data
Standards
IEC 1071-1/2
EN 61071-1/2
VDE 0560 part 120 and 121
tan
δ
0
2 · 10
–4
±
10 %
(dv/dt)
max
(dv/dt)
s
T
min
T
max
α
FQ(co)
t
LD(co)
T
stg
î
---
-
C
I
S
---
-
C
– 25
°C
+ 85
°C
≤
75 %
B25832
Dielectric dissipation factor
Capacitance tolerance
Max. repetitive rate
of voltage rise
Max. non-repetitive rate
of voltage rise
Climatic data:
Min. operating temperature
Max. operating temperature
Average relative humidity
Failure quota
Load duration
Storage temperature limit
IEC climatic category
(IEC 68-1 and 2)
Test data:
AC test voltage
between terminals
between terminals and case
1000 failures per 10
9
component hours
up to 30 000 h
– 55/+ 85
°C
25/085/56
V
TT
V
TC
1.25 x V
R
, 50 Hz, 10 s (or DC 1.75 x V
R
, 10 s)
2 · V
i
+ 1000 V, 50 Hz, 10 s
Insulating voltage V
i
= max. recurrent peak
ˆ
voltage
v
/
2
≤
1
μF: ≥
3000 MΩ
> 1
μF: ≥
3000 s
≤
3 . 10
–4
Insulation resistance
Self-discharge time constant
Dissipation factor
R
ins
τ
= R
ins
x C
tan
δ
Please read
Cautions and warnings
and
Important notes
at the end of this document.
3
09/05
