XHP50B-00-0000-0D0HH435H: DescriptionLED XHP50.2 WARM WHITE SMD; CategoryLED optoelectronic/LED; File Size2MB，26 Pages; ManufacturerCree; Websitehttp://www.cree.com/; Environmental Compliance

Download Datasheet Parametric View All

XHP50B-00-0000-0D0HH435H Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	XHP50B-00-0000-0D0HH435H	-	-	View	Buy Now

XHP50B-00-0000-0D0HH435H Overview

LED XHP50.2 WARM WHITE SMD

XHP50B-00-0000-0D0HH435H Parametric

Parameter Name	Attribute value
color	white, warm color
CCT（K）	3500K 2nd order MacAdam ellipse
Flux, current at 85°C - Test	1005 lm（970 lm ~ 1040 lm）
Flux, current at 25°C - Test	-
Current - Test	700mA
Voltage - Forward (Vf) (Typical)	11.2V
Lumens/Watt at different test currents	128 lm/W
CRI (high color rendering index)	80
Current - maximum	1.5 A
perspective	120°
Installation type	surface mount
Package/casing	2020 (5050 Metric)
Supplier device packaging	2-SMD
size/dimensions	0.197" long x 0.197" wide (5.00mm x 5.00mm)
Height - Installation (maximum)	0.143"（3.63mm）
Package thermal resistance	1.2°C/W

Preview

Download Datasheet

View All

CLD-DS150 Rev 0F

Product family data sheet

Cree

XLamp

XHP50.2 LEDs

ProDuCt DEsCriPtion

The XLamp XHP50.2 LeD is the next

generation of extreme High Power LeDs

that delivers the lowest3 system cost

through the best lumen density, reliability

and color consistency. Built on Cree’s

latest high-power LeD technology, the

XHP50.2 LeD improves the lumen density,

voltage

characteristics,

reliability

and

FEAturEs

•

Available in white, configurable to 6 V

or 12 V by PCB layout

Available in 5-step easyWhite

bins

at 3000 K to 5000 K CCT, 3-step

EasyWhite bins at 2700 K to 5000 K

and 2-step EasyWhite bins at 2700 K

to 4000 K CCT

•

Available in ANSI white bins at

3000 K to 7000 K CCT

Available in standard, 70-, 80-, and

90-minimum CRI options

Binned at 85 °C

Maximum drive current: 3000 mA

(6 V), 1500 mA (12 V)

Low thermal resistance: 1.2 °C/W

Wide viewing angle: 120°

Unlimited floor life at

≤ 30 ºC/85% RH

Reflow solderable - JEDEC

J-STD-020C

RoHS and ReACh compliant

recognized component

(E349212)

tAbLE oF ContEnts

Characteristics ..............................................2

Flux Characteristics, easyWhite

Order

Codes and Bins .............................................3

Flux Characteristics, ANSI White Order

Codes and Bins .............................................5

Relative Spectral Power Distribution ...........7

Relative Flux vs. Junction Temperature

.......7

electrical Characteristics ..............................8

Relative Flux vs. Current ...............................9

Relative Chromaticity vs Current............... 10

Relative Chromaticity vs Temperature ...... 11

Typical Spatial Distribution........................ 11

Thermal Design .......................................... 12

Performance Groups – Luminous Flux..... 13

Performance Groups – Chromaticity........ 13

Cree’s easyWhite

Chromaticity Regions

Plotted on the 1931 CIe Curve ..................

Cree’s ANSI Cool White Kits Plotted on

ANSI Standard Chromaticity Regions ....... 17

Cree’s ANSI Warm and Neutral White Kits

Plotted on ANSI Standard Chromaticity

Regions ....................................................... 18

Bin and Order Code Formats ..................... 19

Reflow Soldering Characteristics

.............. 20

Notes .......................................................... 21

Mechanical Dimensions ............................ 23

Electrical Configuration

............................. 24

Tape and Reel ............................................. 25

Packaging ...................................................

optical performance of the XHP50 LeD in

the same 5.0 mm x 5.0 mm footprint. The

new XHP50.2 LeD provides an easy drop-in

upgrade to achieve higher system LPW

for lighting manufacturers with existing

XHP50 designs, eliminating redesign costs.

Its unparalleled lumen density and longer

lifetime at higher operating temperatures

also enables new and innovative lighting

designs at lower system costs.

WWW.CREE.Com/XLAmp

, XLamp

and

EasyWhite

are registered trademarks and the Cree logo is a trademark of Cree, Inc. UL

and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

Recommended Resources
