PIN
RECEPTACLES
FOR .015” - .025” DIAMETER PINS
1005/1013/8898
XXXX-0-15-XX-3X-XX-04-0
Press-fit in .057 mounting hole
Annealed brass shell for auto-clinching
*
0145/0146
014X-0-15-XX-30-XX-04-0
Basic Part
Number
Length
A
Press-fit in .059 mounting hole
1005-0
1013-0
8898-0
.138
.165
.224
Basic Part
Number
Length
A
0145-0
0146-0
.300
.410
*
NOTE: 8898 is not annealed &
A
not suitable for auto-clinching
A
4378
4378-0-15-XX-30-XX-10-0
Press-fit in .057 mounting hole
0556
0556-0-15-XX-30-XX-04-0
Press-fit in .059 mounting hole
1103
1103-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
9234
9234-0-15-XX-30-XX-10-0
Solder mount in .052 min. mounting hole
0136/37/38/39/41/48/52
01XX-0-15-XX-30-XX-04-0
Press-fit in .057 mounting hole
0447
0447-0-15-XX-30-XX-04-0
Length
A
Press-fit in .056 mounting hole
5660
5660-0-15-XX-30-XX-10-0
Solder mount in .051 min. mounting hole
Basic Part
Number
0136-0
0137-0
0138-0
0139-0
0141-0
0148-0
0152-0
1.215
.560
.210
.635
.700
.455
.410
PAGE 166 | PIN RECEPTACLES
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
RoHS - 2
2011/65/EU
ORDER CODE: XXXX - X - 15 - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
”
TIN/LEAD OVER NICKEL
80
200
”
TIN OVER NICKEL (RoHS)
15
10
”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
02
100
”
TIN/LEAD OVER NICKEL
84
100
”
TIN OVER NICKEL (RoHS)
27
30
”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
SELECT CONTACT:
#30 or #32
CONTACT (DATA ON PAGE 253)
(For alternate contact choices, see groups B and C on page 248)
