ceramic dielectric capacitors suited for bypass and decoupling
applications or for frequency discriminating circuits where Q and
stability of capacitance characteristics are not critical. X7R exhibits
a predictable change in capacitance with respect to time and
voltage and boasts a minimal change in capacitance with reference
to ambient temperature. Capacitance change is limited to ±15%
from -55°C to +125°C.
KEMET automotive grade array capacitors meet the demanding
requirements.
•
•
•
•
•
•
-55°C to +125°C operating temperature range
Saves both circuit board and inventory space
Reduces placement costs and increases throughput
RoHS Compliant
EIA 0508 (2-element) and 0612 (4-element) case sizes
DC voltage ratings of 10 V, 16 V, 25 V, 50 V, 100 V, and 200 V
Ordering Information
CA
06
4
C
Series
104
Capacitance
Code (pF)
K
Capacitance
Tolerance
J = ±5%
K = ±10%
M = ±20%
4
Voltage
R
Dielectric
A
C
TU
Packaging/Grade
(C-Spec)
3
Blank = Bulk
TU = 7" Reel
Unmarked
TM = 7" Reel Marked
AUTO = Automotive
Grade
Ceramic Case Size Number of
Array
(L" x W")
1
Capacitors
05 = 0508
06 = 0612
2=2
4=4
Failure Rate/ Termination
Design
Finish
2
A = N/A
C = 100%
Matte Sn
L = SnPb
(5%
minimum)
C = Standard
X = Flexible Digits + Number
Termination
of Zeros
8 = 10 V R = X7R
4 = 16 V
3 = 25 V
5 = 50 V
1 = 100 V
2 = 200 V
All previous reference to metric case dimension "1632" has been replaced with an inch standard reference of "0612". Please reference all new designs using the
"0612" nomenclature. "CA064" replaces "C1632" in the ordering code.
1
2
2,3
3
Additional reeling or packaging options may be available. Contact KEMET for details.
(5 ±1 seconds and charge/discharge not exceeding 50 mA)
5%(10 V), 3.5%(16 V and 25 V) and 2.5%(50 V to 200 V)
(Rated voltage applied for 120 ±5 seconds @ 25°C)
Regarding aging rate: Capacitance measurements (including tolerance) are indexed to a referee time of 1,000 hours.
Capacitance and dissipation factor (DF) measured under the following conditions:
Note: When measuring capacitance it is important to ensure the set voltage level is held constant. The HP4284 and Agilent E4980 have a feature known as
Automatic Level Control (ALC). The ALC feature should be switched to "ON."
Post Environmental Limits
High Temperature Life, Biased Humidity, Moisture Resistance
