SMDSWLF.020 1OZ datasheet, PDF

Datasheet> All Categories > Tools and equipment> SMDSWLF.020 1OZ

SMDSWLF.020 1OZ: DescriptionSLD WIRE NO-CLEAN 96.5/3/.5 1OZ.; CategoryTools and equipment; File Size105KB，3 Pages; ManufacturerChip Quik; Environmental Compliance

Download Datasheet Parametric View All

SMDSWLF.020 1OZ Overview

SLD WIRE NO-CLEAN 96.5/3/.5 1OZ.

SMDSWLF.020 1OZ Parametric

Parameter Name	Attribute value
type	bonding wire
component	Sn96.5Ag3Cu0.5（96.5/3/0.5）
diameter	0.020"（0.51mm）
melting point	423 ~ 428°F（217 ~ 220°C）
Flux type	No cleaning required
Wire gauge	24 AWG，25 SWG
Craftsmanship	Lead-free
form	Spool, 1 oz (28.35g)
shelf life	not applicable
Shelf life start date	-
Storage/refrigeration temperature	-
delivery information	-
weight	0.062 lbs (28.12g)

Preview

Download Datasheet

View All

SMDSWLF.020 1OZ

Datasheet revision 1.6

www.chipquik.com

Solder Wire SAC305 No-Clean with 2.2% Flux Core 1oz Spool

Product Highlights

No-Clean Water-Washable

Synthetic Flux Core

The clear, non-corrosive, non-conductive residue is meant to be left on the board. Residues that do remain are water soluble

if you want to remove them. Clean with hot water at 60°C (140°F) minimum.

2.2% flux core

Halogen content: None

RoHS II and REACH compliant

Specifications

Alloy:

Wire Diameter:

Flux Type:

Flux Classification:

Melting Point:

Packaging:

Sn96.5/Ag3.0/Cu0.5

0.020” (0.5mm)

No-Clean Water-Washable Synthetic

ROL0

217-220°C (423-428°F)

1 oz spool

Test Results

Test J-STD-004 or other

requirements as stated

Copper Mirror

Corrosion

Quantitative Halides

Electrochemical Migration

Surface Insulation Resistance 85°C,

85% RH @ 168 Hours

Visual

Conflict Minerals Compliance

REACH Compliance

Test Requirement

IPC-TM-650: 2.3.32

IPC-TM-650: 2.6.15

IPC-TM-650: 2.3.28.1

IPC-TM-650: 2.6.14.1

IPC-TM-650: 2.6.3.7

IPC-TM-650: 3.4.2.5

Electronic Industry Citizenship

Coalition (EICC)

Articles 33 and 67 of Regulation (EC)

No 1907/2006

Result

L: No breakthrough

L: No corrosion

L: <0.5%

L: <1 decade drop (No-clean)

L: ≥100MΩ (No-clean)

Clear and free from precipitation

Compliant

Contains no substance >0.1% w/w that

is listed as a SVHC or restricted for

use in solder materials

Conforms to the following Industry Standards:

J-STD-004B, Amendment 1 (Solder Fluxes):

J-STD-006C, Amendments 1 & 2 (Solder Alloys and Fluxed/Non-Fluxed Solders):

RoHS 2 Directive 2011/65/EU:

Yes
