Dimensions: [mm]
25,0
Recommended Land Pattern: [mm]
26,2
5,4
3,3
3,3
Material:
Base Material
Plating
Version
Tin plate
Tin
One Piece
0,2
2
0,
detail B
2,9
25,0
R
R
3,2
0,1
12,5
0,4
4,6
2,9
2,1
2,9
2,5
1,00
12,5
25,4
sectional drawing A-A
A
7,5
7,5
B
A
r
0,12 circular
26,2
5,4
General Information:
Storage Temperature (in original
packaging)
Operating Temperature
25,4
-20 °C up to +60 °C
-40 °C up to +125 °C
Test conditions of Electrical Properties: +20°C, 33% RH if not specified differently
Scale - 1,5:1
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
CREATED
CHECKED
GENERAL TOLERANCE
PROJECTION
METHOD
KaS
DESCRIPTION
JoV
DIN ISO 2768-1m
WE-SHC Shielding Cabinet
ORDER CODE
36903255S
REVISION
STATUS
DATE
BUSINESS UNIT
PAGE
001.000
Valid
2016-11-02
eiSos
1/2
