INTERCONNECTS
SERIES 850 & 851 • .050” GRID SOLDER CUP
HEADERS AND SOCKETS • SINGLE ROW STRIPS
•
Solder cups are pre-aligned and accept up to
(Number of Pins
X .050") + .015"
26 AWG wire
•
Series 850 headers use MM #3050-0 pins. See
page 244 for details
(TYP)
.050
•
Series 851 sockets use MM #1157-0 receptacles
(Number of Pins
X .050") + .015"
.087
.024 DIA.
.055
that accept pin diameters from .015”-.020”.
See page 160 for details
.100
.181
.084
•
Receptacles use Hi-Rel, 3-finger BeCu #11
.303
.035 DIA.
.032 DIA.
.016 DIA.
contact rated at 3 amps. See page 251 for
details
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
.050
FIG. 1
(Number of Pins
X .050") + .015"
.0435
.087
ORDERING INFORMATION
Series 850...003
Single Row Solder Cup / Solder Tail
850-XX-0_ _-10-003000
Specify number of pins
01-50
FIG. 1
Series 850...003
Single Row Right Angle Solder Cup
850-XX-0_ _-20-003000
01-50
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.016 DIA.
FIG. 2
RoHS - 2
Specify number of pins
(TYP)
.050
.025
.040 DIA.
2011/65/EU
XX=Plating Code
See Below
10
10
μ”
Au
.084
.055
.125
.225±.005
.119±.010
SPECIFY PLATING CODE XX=
Pin Plating
Series 851...003
Single Row Solder Cup Socket
851-XX-_ _ _-10-003000
01-50
FIG. 2
(Number of Pins
FIG. 3
X .050") + .015"
Specify number of pins
PAGE 35.1 | INTERCONNECTS
.087
.041 DIA.
.038 DIA.
.028 DIA.
HOLE
.033 DIA.
.340
.075
.140 .159
2011/65/EU
.060
.024 DIA.
HOLE
.050
.090
RoHS - 2
XX=Plating Code
See Below
13
10
μ”
Au
30
μ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
FIG. 3
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
