1N4002 Overview

1 A, 100 V, SILICON, SIGNAL DIODE, DO-41

1N4002 Parametric

Parameter Name	Attribute value
Maker	DCCOM [ DC COMPONENTS ]
package instruction	O-PALF-W2
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	DO-41
JESD-30 code	O-PALF-W2
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Maximum repetitive peak reverse voltage	100 V
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL
Base Number Matches	1

Preview

Download Datasheet

View All

DC COMPONENTS CO., LTD.

R

1N4001

THRU

1N4007

RECTIFIER SPECIALISTS

TECHNICAL SPECIFICATIONS OF SILICON RECTIFIER

VOLTAGE RANGE - 50 to 1000 Volts

CURRENT - 1.0 Ampere

FEATURES

*

Low cost

Low leakage

Low forward voltage drop

High current capability

DO-41

MECHANICAL DATA

*

Case: Molded plastic

Epoxy: UL 94V-0 rate flame retardant

Lead: MIL-STD-202E, Method 208 guaranteed

Polarity: Color band denotes cathode end

Mounting position: Any

Weight: 0.33 gram

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

o

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

Dimensions in inches and (millimeters)

SYMBOL

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current

at T

A

= 75

o

C

Peak Forward Surge Current 8.3 ms single half sine-wave

superimposed on rated load (JEDEC Method)

Maximum Instantaneous Forward Voltage at 1.0A DC

o

Maximum DC Reverse Current

@T

A

= 25 C

at Rated DC Blocking Voltage

@T

A

= 100

o

C

Maximum Full Load Reverse Current Average, Full Cycle

.375*(9.5mm) lead length at T

L

= 75

o

C

Typical Junction Capacitance (Note)

Typical Thermal Resistance

Operating and Storage Temperature Range

NOTES : Measured at 1 MH

Z

and applied reverse voltage of 4.0 volts

V

RRM

V

RMS

V

DC

I

O

I

FSM

V

F

1N4001

50

35

50

1N4002

100

70

100

1N4003

200

140

200

1N4004 1N4005

400

280

400

1.0

30

1.1

5.0

500

30

600

420

600

1N4006

800

560

800

1N4007

1000

700

1000

UNITS

Volts

Amps

Volts

uAmps

pF

0

I

R

C

J

R

θ

JA

T

J

, T

STG

15

50

-65 to + 175

C/ W

0

C

104
