GDZ-G-Series
www.vishay.com
Vishay Semiconductors
Small Signal Zener Diodes
FEATURES
• Silicon planar Zener diodes
• Low Zener impedance and low leakage current
• Popular in Asian designs
• Compact surface mount device
• Ideal for automated mounting
• AEC-Q101 qualified available
• ESD capability according to AEC-Q101:
human body model > 8 kV
machine model > 800 V
PRIMARY CHARACTERISTICS
PARAMETER
V
Z
range nom.
Test current I
ZT
V
Z
specification
Int. construction
VALUE
2.0 to 36
5
Pulse current
Single
UNIT
V
mA
• Base P/N-G3 - green, commercial grade
• Base P/N-HG3 - green, AEC-Q101 qualified
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
ORDERING INFORMATION
DEVICE NAME
ORDERING CODE
GDZ2V0B-G3-08 to GDZ36B-G3-08
GDZ2V0B-G3-18 to GDZ36B-G3-18
GDZ-G-series
GDZ2V0B-HG3-08 to GDZ36B-HG3-08
GDZ2V0B-HG3-18 to GDZ36B-HG3-18
3000 (8 mm tape on 7" reel)
10 000 (8 mm tape on 13" reel)
15 000/box
10 000/box
TAPED UNITS PER REEL
3000 (8 mm tape on 7" reel)
10 000 (8 mm tape on 13" reel)
MINIMUM ORDER QUANTITY
15 000/box
10 000/box
PACKAGE
PACKAGE NAME
SOD-323
WEIGHT
4 mg
MOLDING COMPOUND
FLAMMABILITY RATING
UL 94 V-0
MOISTURE SENSITIVITY
LEVEL
MSL level 1
(according J-STD-020)
SOLDERING CONDITIONS
260 °C/10 s at terminals
ABSOLUTE MAXIMUM RATINGS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Power dissipation
Junction temperature
Storage temperature range
Operating temperature range
TEST CONDITION
SYMBOL
P
tot
T
j
T
stg
T
op
VALUE
200
150
-55 to +150
-55 to +150
UNIT
mW
°C
°C
°C
Rev. 1.6, 14-Oct-16
Document Number: 83334
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GDZ-G-Series
www.vishay.com
Vishay Semiconductors
ZENER VOLTAGE
RANGE
REVERSE
CURRENT
I
R
at V
R
μA
MAX.
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
0.5
0.5
0.5
0.5
0.5
0.5
1
1
1
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
120
120
120
100
50
20
10
5
5
2
2
1
1
0.5
0.5
0.5
0.5
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.5
0.7
1
1
1
1
1
1
1
1
1
2.5
3
3.5
4
5
6
7
8
9
10
11
12
13
15
17
19
21
23
25
27
V
MAX.
100
100
100
110
120
120
100
100
100
100
80
60
60
40
30
30
30
30
30
30
37
42
50
65
85
100
120
150
200
250
300
ELECTRICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
TEST CURRENT
I
ZT1
mA
MAX.
2.2
2.41
2.63
2.91
3.22
3.53
3.845
4.16
4.43
4.75
5.2
5.73
6.33
6.93
7.6
8.36
9.23
10.21
11.22
12.24
13.49
14.98
16.51
18.35
20.39
22.47
24.78
27.53
30.69
33.79
36.87
I
ZT2
DYNAMIC RESISTANCE
Z
Z
at I
ZT1
MAX.
1000
1000
1000
1000
1000
1000
1000
1000
1000
800
500
200
100
60
60
60
60
60
60
80
80
80
80
80
100
100
120
150
200
250
300
Z
ZK
at I
ZT2
MARKING
CODE
PART NUMBER
V
Z
at I
ZT1
V
MIN.
2.02
2.22
2.43
2.69
3.01
3.32
3.6
3.89
4.17
4.55
4.98
5.49
6.06
6.65
7.28
8.02
8.85
9.77
10.76
11.74
12.91
14.34
15.85
17.56
19.52
21.54
23.72
26.19
29.19
32.15
35.07
GDZ2V0B-G
GDZ2V2B-G
GDZ2V4B-G
GDZ2V7B-G
GDZ3V0B-G
GDZ3V3B-G
GDZ3V6B-G
GDZ3V9B-G
GDZ4V3B-G
GDZ4V7B-G
GDZ5V1B-G
GDZ5V6B-G
GDZ6V2B-G
GDZ6V8B-G
GDZ7V5B-G
GDZ8V2B-G
GDZ9V1B-G
GDZ10B-G
GDZ11B-G
GDZ12B-G
GDZ13B-G
GDZ15B-G
GDZ16B-G
GDZ18B-G
GDZ20B-G
GDZ22B-G
GDZ24B-G
GDZ27B-G
GDZ30B-G
GDZ33B-G
GDZ36B-G
05
15
25
35
45
55
65
75
85
95
U1
U2
U3
U4
U5
U6
U7
U8
U9
UA
UB
UC
UD
UE
UH
UK
UL
UM
UN
UP
UT
Notes
• The Zener voltage V
Z
is measured 40 ms after power is supplied
• The operating resistance (Z
Z
, Z
ZK
) are measured by superimposing a 1 kHz alternating current on the regulated current (I
Z
).
Rev. 1.6, 14-Oct-16
Document Number: 83334
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
GDZ-G-Series
www.vishay.com
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
0.12
Vishay Semiconductors
Temperature Coefficient (%/K)
0.10
0.08
0.06
0.04
0.02
0
- 0.02
- 0.04
- 0.06
- 0.08
0
4
8
12 16
20 24 28
32 36
19964
Zener Voltage V
Z
(V)
Fig. 1 - Zener Voltage Temperature Coefficient vs.
Zener Voltage
PACKAGE DIMENSIONS
in millimeters (inches):
SOD-323
1.15 [0.045]
0.8 [0.031]
0.2 [0.008]
0.1 [0.004] max.
1.1 [0.043]
0.15 [0.006]
0.25 [0.010]
1.95 [0.077]
Cathode bar
1.60 [0.063]
0.40 [0.016]
0.20 [0.008]
2.85 [0.112]
2.50 [0.098]
Footprint recommendation:
0.8 [0.031]
1.5 [0.059]
0° - 8°
0.40 [0.016]
0.10 [0.004]
0.8 [0.031]
1.6 [0.063]
Document no.:
S8-V-3910.02-001
(4)
Created - Date: 24.August.2004
Rev. 6 - Date: 23.Sept.2016
17443
Rev. 1.6, 14-Oct-16
Document Number: 83334
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
0.6 [0.024]
Legal Disclaimer Notice
www.vishay.com
Vishay
Disclaimer
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,
“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other
disclosure relating to any product.
Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or
the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all
liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,
consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular
purpose, non-infringement and merchantability.
Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of
typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding
statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a
particular product with the properties described in the product specification is suitable for use in a particular application.
Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over
time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s
technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,
including but not limited to the warranty expressed therein.
Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining
applications or for any other application in which the failure of the Vishay product could result in personal injury or death.
