1N4001 THRU 1N4007
GENERAL PURPOSE PLASTIC RECTIFIER
Reverse Voltage -
50 to 1000 Volts
DO-204AL
Forward Current -
1.0 Ampere
FEATURES
1.0 (25.4)
MIN.
0.107 (2.7)
0.080 (2.0)
DIA.
0.205 (5.2)
0.160 (4.1)
♦
The plastic package carries Underwriters Laboratory
Flammability Classification 94V-0
♦
Construction utilizes void-free
molded plastic technique
♦
Low reverse leakage
♦
High forward surge current capability
♦
High temperature soldering guaranteed:
250°C/10 seconds, 0.375" (9.5mm) lead length,
5 lbs. (2.3kg) tension
MECHANICAL DATA
1.0 (25.4)
MIN.
0.034 (0.86)
0.028 (0.71)
DIA.
NOTE:
Lead diameter is
0.026 (0.66)
0.023 (0.58)
for suffix "E" part numbers
Case:
JEDEC DO-204AL molded plastic body
Terminals:
Plated axial leads, solderable per MIL-STD-750,
Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:
0.012 ounce, 0.3 gram
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
SYMBOLS
1N
4001
1N
4002
1N
4003
1N
4004
1N
4005
1N
4006
1N
4007
UNITS
*Maximum repetitive peak reverse voltage
*Maximum RMS voltage
*Maximum DC blocking voltage
*Maximum average forward rectified current
0.375" (9.5mm) lead length at T
A
=75°C
*Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method) T
A
=75°C
*Maximum instantaneous forward voltage at 1.0A
*Maximum full load reverse current
full cycle average 0.375" (9.5mm) lead length at
T
L
=75°C
*Maximum DC reverse current
at rated DC blocking voltage
Typical reverse recovery time
(NOTE 1)
Typical junction capacitance
(NOTE 2)
Typical thermal resistance
(NOTE 3)
Maximum DC blocking voltage temperature
*Operating junction and storage temperature range
T
A
= 25°C
T
A
=100°C
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
200
140
200
400
280
400
1.0
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amp
I
FSM
V
F
I
R(AV)
30.0
1.1
30.0
5.0
50.0
30.0
15.0
50.0
25.0
+150
-50 to +175
Amps
Volts
µA
µA
µs
pF
°C/W
°C
°C
I
R
t
rr
C
J
R
ΘJA
R
ΘJL
T
A
T
J
, T
STG
NOTES:
(1) Measured on Tektronix Type "S" recovery plug-in. Tektronix 545 Scope or equivalent, I
FM
=20mA, I
RM
=1mA
(2) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts
(3) Thermal resistance from junction to ambient and from junction to lead at 0.375" (9.5mm) lead length, P.C.B. mounted
*JEDEC registered value
4/98
RATINGS AND CHARACTERISTIC CURVES 1N4001 THRU 1N4007
FIG. 2 - MAXIMUM NON-REPETITIVE PEAK
FORWARD SURGE CURRENT
FIG.1 - FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD RECTIFIED CURRENT,
AMPERES
30
PEAK FORWARD SURGE CURRENT,
AMPERES
1.0
60 H
Z
RESISTIVE OR
INDUCTIVE LOAD
8.3ms SINGLE HALF SINE WAVE
(JEDEC Method)
T
A
=75°C
0.8
0.2 x 0.2” (5.0 x 5.0mm)
COPPER PADS
25
0.6
20
0.4
15
0.2
0.375” (9.5mm) LEAD LENGTH
10
0
5.0
0
25
50
75
100
125
150
175
1
10
NUMBER OF CYCLES AT 60 H
Z
100
AMBIENT TEMPERATURE, °C
FIG. 4 - TYPICAL REVERSE CHARACTERISTICS
FIG. 3 - TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT, MICROAMPERES
1,000
20
INSTANTANEOUS FORWARD CURRENT,
AMPERES
10
T
J
=25°C
PULSE WIDTH=300µs
1% DUTY CYCLE
100
T
J
=150°C
1
10
T
J
=100°C
0.1
1
0.1
T
J
=25°C
0.01
0.6
0.8
1.0
1.2
1.4
1.6
1.8
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
0.01
0
20
40
60
80
100
PERCENTAGE OF PEAK REVERSE VOLTAGE, %
FIG. 5 - TYPICAL JUNCTION CAPACITANCE
100
TRANSIENT THERMAL IMPEDANCE,
°C/W
T
J
=25°C
f=1.0 MHz
Vsig=50mVp-p
FIG. 6 - TYPICAL TRANSIENT THERMAL IMPEDANCE
100
JUNCTION CAPACITANCE, pF
10
10
1
1
0.1
1
10
100
0.1
0.01
0.1
1
t, PULSE DURATION, sec.
10
100
REVERSE VOLTAGE, VOLTS
