Directional Antenna
1700 TO 2700 MHz DIRECTIONAL DIE CAST GRID ANTENNA SYSTEM
The DC24 is a directional antenna system, which incorporates a 2-piece aluminum die cast
parabolic grid type antenna reflector with a patented 50-ohm passive feed dipole. Installation is
simple with the Laird adjustable tilt “Heavy Duty” bracket that comes standard. The bracket
accommodates poles from 1 to 2.0 inches OD. Brackets are full galvanized for extreme corrosion
protection and each reflector comes complete with stainless steel hardware and complete
assembly instructions. The dipole feed assembly comes with a 30 inch LMR240 pigtail terminated
with an N male or N female connector. Other connector configurations are available upon request.
DC24
FEATURES
•
•
•
•
•
•
•
Small size/reduced shipping cost
50-ohm passive feed dipole
30 in pigtail with N male or N female Connector
24 dBi antenna gain; horizontal or vertical polarity
Rugged, lightweight and waterproof
Heavy duty adjustable tilt bracket
2-Piece powder coat painted die cast aluminum
MARKETS
• 2.4 GHz ISM band applications
• Wireless internet access
• Wireless bridges
• Point-to-point repeaters
• MMDS applications
• Streaming video
• WiMAX
FREQUENCY
RANGE MODEL
PF-1
PF-2
MIN
2400
2100
TYP
MAX
2483
2686
UNITS
MHz
MHz
SPECIFICATIONS
PARAMETER
Gain
Input Return Loss (S11)
VSWR
3 dB Beam Angle
Cross Pole
Front-to-Back
Side Lobe
Impedance
Input Power
Focal Length
Dimension (L x W)
Weight
Pole Diameter (OD)
Operating Temperature
Wind Loading 100 MPH
Wind Loading 140 MPH
MIN
TYP
24
-14
1.5:1
8
26
MAX
UNITS
dBi
dB
deg
dB
dB
dB
ohm
w
in (cm)
in (cm)
lbs (kgs)
in (mm)
°C
lbs (kg)
lbs (kg)
24
50
16 (40.6)
42 x 24 (107 x 61)
5.5 (2)
1 (25)
-45
2 (50)
+70
80.5 (36.5)
126 (57)
DC24-HD-PF-xxxx-xx
Freq. Range
Americas: +1.847 839.6907
IAS-AmericasEastSales@lairdtech.com
Europe: +44.(0).1628.858941
IAS-EUSales@lairdtech.com
Asia: +86.21.5855.0827.127
IAS-AsiaSales@lairdtech.com
SYSTEM ORDERING
PF1 - PMPF-1 2.4 GHz ISM Band PF2
- PMPF-2 2.5 GHz MMDS Band
Feed Option
P - Pigtail with N Male connector PF -
Pigtail with N Female connector
ANT-DS-DC24 0911
