CONDUCTIVE POLYMER TANTALUM SOLID ELECTROLYTIC CAPACITORS
F38
Conductive Polymer
Resin-molded Chip, High Capacitance Series
Adapted to the RoHS directive (2002/95/EC).
Specifications
Item
Performance Characteristics
Category Temperature Range –55 to +105˚C (Rated temperature + 85˚C)
Capacitance Tolerance
±20%
(120Hz)
Dissipation Factor (at 120Hz) Refer to the list below
ESR (100kHz)
Leakage Current
Ripple Current
Refer to the list below
After 5 minute's application of rated voltage, leakage current
at 20˚C is not more than 0.1CV
Refer to the list below
Type numbering system (Example : 6.3V 10
µ
F)
1
2
3
4
5
6
7
8
9
10
11
At 60˚C, 90 to 95% R.H. 500hours
Capacitance Change Within –20 to +30% of initial value
Damp Heat
(No voltage applied) Dissipation Factor......1.5 times initial specified value or less
Leakage Current........Initial specified value or less
–55˚C / +105˚C 30 minutes each 5 cycle
Capacitance Change Within
±20%
of initial value
Temperature Cycles
Dissipation Factor......Initial specified value or less
Leakage Current........Initial specified value or less
Resistance
to Soldering Heat
Test Condition ; 10 second reflow at 240˚C
Capacitance Change Within
±20%
of initial value
Dissipation Factor......1.3 times initial specified value or less
Leakage Current........Initial specified value or less
After application of surge voltage in series with a 1kΩ resistor
at the rate of 30 seconds ON, 30 seconds OFF, for 1000
sucessive test cycles at 85˚C, capacitors meet the
characteristics requirements listed below.
Capacitance Change...Within
±20%
of initial value
Dissipation Factor........Initial specified value or less
Leakage Current..........Initial specified value or less
After 1000 hours' application of rated voltage in series
with a 3Ω resistor at 85˚C.
Capacitance Change....Within
±20%
of initial value
Dissipation Factor...1.5 times initial specified value or less
Leakage Current...Initial specified value or less
After 1000 hours' application of derated voltage in series
with a 3Ω resistor at 105˚C,capacitors meet the characteristic
requirements listed below
Capacitance Change....Within
±20%
of initial value
Dissipation Factor...3 times initial specified value or less
Leakage Current...Initial specified value or less
After applying the pressure load of 5N for 10±1 seconds
horizontally to the center of capacitor side body which has
no electrode and has been soldered beforehand on an
aluminum substrate, there shall be found
neither exfoliation nor its sign at the
5N (0.51kg
•
f)
For 10±1 seconds
terminal electrode.
Keeping a capacitor surface-mounted on a substrate upside
down and supporting the substrate at both of the opposite
bottom points 45mm apart from the center of the capacitor,
the pressure strength is applied with a specified jig at the
center of the substrate so that the substrate may bend by
1mm as illustrated.
20
R230
Then, there shall be found no
remarkable abnormality on the
capacitor terminals.
45
45
1mm
F 3 8 0 J 1 0 6 M M
A
Taping code
Tape width Reel Dia
(mm)
(φ180mm)
A
8
Case code
Capacitance tolerance
Rated Capacitance
Rated voltage
Series
Drawing
L
H
W
1
Surge
W
2
Endurance 1
S
1
Case code
M
S
L
1.6
±
0.1
2.0
±
0.1
S
2
W
1
S
1
W
2
0.65
±
0.1
0.9
±
0.1
H
0.8
±
0.1
0.8
±
0.1
S Case
(mm)
S
1
0.5
±
0.1
0.5
±
0.1
S
2
0.6
±
0.1
1.0
±
0.1
0.85
±
0.1
1.25
±
0.1
Endurance 2
Marking
M Case
Capacitance code
J
Rated voltage
(Voltage code)
Jn
Rated voltage
(Voltage code)
Shear Test
Standard ratings
V
Cap.(
µ
F)
Code
4
0G
M
M
S
S
6.3
0J
M
M
•
S
S
(S)
4.7
10
22
33
47
475
106
226
336
476
10
1A
M
M
•
S
(S)
Capacitance
code
S
a
n
s
Terminal Strength
( ) The series in parentheses are being developed.
Please contact to your local Nichicon sales office when
these series are being designed in your application.
Standard rating
Rated Volt Rated Capacitance Case
(V)
code
(µF)
Part Number
Leakage Current Disspation Factor
(µF)
(%@120Hz)
∗
As for the surge voltage refer to page 301 for details.
ESR
(mΩ@100kHz)
Rated Ripple
(mArms@100kHz)
4
6.3
10
10
22
33
47
10
22
22
33
4.7
10
10
M
M
S
S
M
M
S
S
M
M
S
F380G106MMA
F380G226MMA
F380G336MSA
F380G476MSA
F380 J 106MMA
F380 J 226MMA
F380 J 226MSA
F380 J 336MSA
F381A475MMA
F381A106MMA
F381A106MSA
4.0
8.8
13.2
18.8
6.3
13.9
13.9
20.8
4.7
10.0
10.0
6
6
6
6
6
6
6
6
6
6
6
200
200
200
200
200
200
200
200
200
200
200
350
350
450
450
350
350
450
450
350
350
450
