The SY10/100EL05 are 2-input differential AND/NAND
gates. These devices are functionally equivalent to the
E404 devices, with higher performance capabilities. With
propagation delays and output transition times
significantly faster than the E404, the EL05 is ideally
suited for those applications which require the ultimate
in AC performance.
Because a negative 2-input NAND is equivalent to a
2-input OR function with inverted inputs, the differential
inputs and outputs of the device allows the EL05 to also
be used as a 2-input differential OR/NOR gate.
The differential inputs employ clamp circuitry so that,
under open conditions (pulled down to V
EE
), the input to
the AND gate will be HIGH. In this way, if one set of
inputs is open, the gate will remain active to the other
input.
PIN NAMES
Pin
D
0
, D
1
Q
Function
Data Inputs
Data Outputs
M9999-031006
hbwhelp@micrel.com or (408) 955-1690
Rev.: G
Amendment: /0
1
1
Issue Date: March 2006
Micrel, Inc.
SY10EL05
SY100EL05
PACKAGE/ORDERING INFORMATION
Ordering Information
(1)
D
0
D
0
D
1
D
1
1
2
3
4
8
7
6
5
V
CC
Q
Q
V
EE
Part Number
SY10EL05ZC
SY10EL05ZCTR
(2)
SY100EL05ZC
SY100EL05ZCTR
(2)
SY10EL05ZI
SY10EL05ZITR
(2)
SY100EL05ZI
SY100EL05ZITR
(2)
SY10EL05ZG
(3)
SY10EL05ZGTR
(2, 3)
SY100EL05ZG
(3)
SY100EL05ZGTR
(2, 3)
Package
Type
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Z8-1
Operating
Range
Commercial
Commercial
Commercial
Commercial
Industrial
Industrial
Industrial
Industrial
Industrial
Industrial
Industrial
Industrial
Package
Marking
HEL05
HEL05
XEL05
XEL05
HEL05
HEL05
XEL05
XEL05
HEL05 with
Pb-Free bar-line indicator
HEL05 with
Pb-Free bar-line indicator
XEL05 with
Pb-Free bar-line indicator
XEL05 with
Pb-Free bar-line indicator
Lead
Finish
Sn-Pb
Sn-Pb
Sn-Pb
Sn-Pb
Sn-Pb
Sn-Pb
Sn-Pb
Sn-Pb
Pb-Free
NiPdAu
Pb-Free
NiPdAu
Pb-Free
NiPdAu
Pb-Free
NiPdAu
8-Pin SOIC (Z8-1)
Notes:
1. Contact factory for die availability. Dice are guaranteed at T
A
= 25°C, DC Electricals only.
2. Tape and Reel.
3. Pb-Free package is recommended for new designs.
M9999-031006
hbwhelp@micrel.com or (408) 955-1690
2
Micrel, Inc.
SY10EL05
SY100EL05
DC ELECTRICAL CHARACTERISTICS
V
EE
= V
EE
(Min.) to V
EE
(Max.); V
CC
= GND
T
A
= –40
°
C
Symbol
I
EE
Parameter
Power Supply Current
10EL
100EL
Min.
—
—
Typ.
18
18
–5.2
–4.5
—
Max.
22
22
–5.5
–5.5
150
Min.
14
14
–4.75
–4.20
—
T
A
= 0
°
C
Typ.
18
18
–5.2
–4.5
—
Max.
22
22
–5.5
–5.5
150
T
A
= +25
°
C
Min.
14
14
–4.75
–4.20
—
Typ.
18
18
–5.2
–4.5
—
Max.
22
22
–5.5
–5.5
150
T
A
= +85
°
C
Min.
14
16
–4.75
–4.20
—
Typ.
18
21
–5.2
–4.5
—
Max.
22
25
V
–5.5
–5.5
150
µA
Unit
mA
V
EE
Power Supply Voltage
10EL –4.75
100EL –4.20
Input HIGH Current
—
I
IH
AC ELECTRICAL CHARACTERISTICS
V
EE
= V
EE
(Min.) to V
EE
(Max.); V
CC
= GND
T
A
= –40
°
C
Symbol
t
PD
V
PP
V
CMR
t
r
t
f
Parameter
Propagation Delay to
Output D
Minimum Input Swing
(1)
Common Mode Range
(2)
Min.
135
150
(2)
Typ.
260
—
—
225
Max.
440
—
–0.4
350
Min.
185
150
(2)
100
T
A
= 0
°
C
Typ.
275
—
—
225
Max.
390
—
–0.4
350
T
A
= +25
°
C
Min.
185
150
(2)
100
Typ.
275
—
—
225
Max.
390
—
–0.4
350
T
A
= +85
°
C
Min.
215
150
(2)
100
Typ.
305
—
—
225
Max.
420
—
–0.4
350
Unit
ps
mV
V
ps
Output Rise/Fall Times Q 100
(20% to 80%)
NOTES:
1. Minimum input swing for which AC parameters are guaranteed. The device has a DC gain of
≈40.
2. The CMR range is referenced to the most positive side of the differential input signal. Normal operation is obtained if the HIGH level falls within the specified
range and the peak-to-peak voltage lies between V
PP
min. and 1V. The lower end of the CMR range is dependent on V
EE
and is equal to V
EE
+ 3.0V.
M9999-031006
hbwhelp@micrel.com or (408) 955-1690
3
Micrel, Inc.
SY10EL05
SY100EL05
8-PIN SOIC .150" WIDE (Z8-1)
Rev. 03
MICREL, INC. 2180 FORTUNE DRIVE SAN JOSE, CA 95131
TEL
USA
+ 1 (408) 944-0800
FAX
+ 1 (408) 474-1000
WEB
http://www.micrel.com
The information furnished by Micrel in this datasheet is believed to be accurate and reliable. However, no responsibility is assumed by Micrel for its use.
Micrel reserves the right to change circuitry and specifications at any time without notification to the customer.
Micrel Products are not designed or authorized for use as components in life support appliances, devices or systems where malfunction of a product can
reasonably be expected to result in personal injury. Life support devices or systems are devices or systems that (a) are intended for surgical implant into
the body or (b) support or sustain life, and whose failure to perform can be reasonably expected to result in a significant injury to the user. A Purchaser’s
use or sale of Micrel Products for use in life support appliances, devices or systems is at Purchaser’s own risk and Purchaser agrees to fully indemnify
Micrel for any damages resulting from such use or sale.
