コモンモードチョークコイル
（ACライン用）
リードタイプ
COMMON MODE CHOKE COILS
(FOR AC LINES)
LEADED TYPE
OPERATING
等価回路
（Equivalent
circuit）
TEMP.
TLF9UAタイプ：ー25∼＋115℃
TLF14CBタイプ：ー20∼＋105℃
TLF25RAタイプ：ー25∼＋105℃
（½品自己発熱を含む）
（Including
self-generated heat）
特長 FEATURES
・TLF
9UA
（H）
タイプ
…………………………………………………
小型½状
・TLF14CB
（H）
タイプ
…………………………………………………
普通½状
・TLF25RA
タイプ
…………………………………………………
大電流容量
・TLF
9UA
（H）
TYPE ............................................ Small-sized configuration
・TLF14CB
（H）
TYPE ................................................ Ordinary configuration
・TLF25RA
TYPE ............. Large current capacity for power supply line use
用途 APPLICATIONS
TV、VTR、SW電源,NCマシン、コンピュータおよび周辺機器,各種計測器、
各種制御装½などの雑音端子電圧、電源ラインノイズ対策
・TLF
9UA
（H）
TYPE
…………………………………………
小電力用の機器
・TLF14CB
（H）
TYPE
……………………………
入力電力数10W
の機器
・TLF25RA
TYPE
………………………………………………
高電力用の機器
As a preventive measure against noise terminal voltage or power supply
noise in TV or VTR units, SW power supplies, NC machines, computer
systems, peripheral units, measuring instruments, and controllers.
（H）
Type ............................................... low-current applications
・TLF
9UA
・TLF14CB
（H）
Types ...........equipment with several tens of watts of input power
・TLF25RA
Type ....................................................high-current applications
½名表記法 ORDERING
CODE
1
½式
TLF
ラインフィルタ
3
½状
RA△
UA△
UAH
CB△
CBH
リングコア縦½
U字コア縦½
U字コア横½
□字コア分割巻縦型
□字コア分割巻横型
△＝スペース
4
公称インダクタンス
（μH）
例
102
103
1000
10000
5
インダクタンス許容差
（％）
△
W
公称値以上
±
100
10
△＝スペース
6
定格電流
（A）
R54
0R8
R＝小数点
0.54
0.8
2
コア寸法
（mm）
△9
14
25
9
14
25
△＝スペース
7
½品区分記号
△
一般
△＝スペース
8
½社管理記号
△
標準品
△＝スペース
T L F
△
9 U A H 1 0 2 W 0 R 8
○ ○
1
2
3
4
5
6
7
8
1
Type
TLF
Line filter
3
Shape
RA△
UA△
UAH
CB△
CBH
Ring core, vertical type
U core, vertical type
U core, horizontal type
Square type core
vertically split wound
Square type core
horizontally split wound
△＝Blank
space
4
Nominal Inductance
（μH）
example
102
103
1000
10000
5
Inductance tolerance
（％）
△
W
Nominal Values or higher
±
100
10
△＝Blank
space
6
Rated current A）
（
R54
0R8
R=decimal point
0.54
0.8
2
Core dimensions
（mm）
△9
14
25
9
14
25
△＝Blank
space
7
Product classification code
△
Standard
△＝Blank
space
8
Internal code
△
Standard Product
△＝Blank
space
