FR430 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Topical application> Wireless rf/communication> FR430

FR430: DescriptionRF ANT 440MHZ WHIP STR N FEM; CategoryTopical application Wireless rf/communication; File Size71KB，2 Pages; ManufacturerLaird Technologies; Environmental Compliance

Download Datasheet Parametric Compare View All

FR430 Overview

RF ANT 440MHZ WHIP STR N FEM

FR430 Parametric

Parameter Name	Attribute value
frequency group	UHF（300 MHz ~ 1 GHz）
Frequency (center/band)	440MHz
Frequency Range	430MHz ~ 450MHz
Antenna type	Whip-shaped, straight
Number of frequency bands	1
VSWR	1.5
Return loss	-
Gain	3dBi
Power - Max	150W
characteristic	-
Termination	Connector, N female
Intrusion protection	-
Installation type	Bracket installation
Height (maximum value)	34.000"（863.60mm）
application	-

Preview

Download Datasheet

View All

Laird Technologies

Web site: www.LairdTech.com

Item # FR430, UHF Fiberglass Omnidirectional Antenna

UHF Fiberglass Omnidirectional Antenna

FR Series Fiberglass Omnis

Laird Technologies' UHF fiberglass series is best suited to base station and talkarround applications. The versatility in

frequency and gain selection combined with a highly reliable solid brass radiator provide exceptional value for superior RF

performance. The quality design of the integrated pigtail and N-female connector are excellent weather-proofing features.

Mounting hardware is included facilitating installation.

SPECIFICATIONS

Band

UHF

Series

Frequency

430 to 450 MHz

Gain

3 dBi

Bandwidth

20 MHz

3dB Beamwidth, E Plane

40 º

Height

34.00 in

86.36 cm

Weight

1.08 lbs

0.49 kg

0.164 m

0.015 ft

Wind Surface Area

VSWR

1.5:1

Polarization

Vertical

Impedance

50 ohms

Pigtail

12 in (30.5 cm) UltraLink

RF Connector

N (Female)

Wind Survival

125 mph

200 kph

12/6/2012 | Page 1 of 2

FR430 Related Products

	FR430
Description	RF ANT 440MHZ WHIP STR N FEM
frequency group	UHF（300 MHz ~ 1 GHz）
Frequency (center/band)	440MHz
Frequency Range	430MHz ~ 450MHz
Antenna type	Whip-shaped, straight
Number of frequency bands	1
VSWR	1.5
Gain	3dBi
Power - Max	150W
Termination	Connector, N female
Installation type	Bracket installation
Height (maximum value)	34.000"（863.60mm）
