New
on
enerati
G
PLC
FT1A Series
- 40 I/O
Key Features
•
•
•
•
•
•
•
•
•
•
•
Available in 100-240 VAC and 24 VDC power
Available with/without embedded LCD
10 Amp Relay contacts
USB Mini-B Programming Port
Embedded 6-pt analog inputs (0-10VDC, 10-bit, DC power)
Integrated 4 x 100KHz high-speed counter
Embedded Ethernet port
Supports Modbus TCP and RTU
SD Memory card for data logging and program storage
Optional RS232C/RS485 adapter
100KHz high-speed outputs
General Specifications
Part Numbers
Appearance
LCD Screen
Operating Temperature
Storage Temperature
Rated Power Voltage
Allowable Voltage Range
Rated Power Frequency
Maximum Power Consumption
Weight
24V DC
20.4 to 28.8V DC (Including ripple voltage)
–
7.9W
Approx. 420g
Yes
N/A
Yes
N/A
FT1A-H40RKA, H40RSA
FT1A-B40RKA, B40RSA
FT1A-H40RC
FT1A-B40RC
0 to +55°C (operating ambient temperature)
–25 to +70°C (no freezing)
100 to 240V AC
85 to 264V AC
50/60Hz (47 to 63Hz)
48VA
Approx. 580g
Function Specifications
Part Numbers
Program Capacity
Note 1
Points
Digital Input (Terminal No.)
Shared Analog Input (Terminal No.)
Input
Output Points
10A Relay Output (Terminal No.)
2A Relay Output (Terminal No.)
Transistor Output (Terminal No.)
User Program Storage
RAM
Backup Duration
Backup Function
Battery
Charging Time
Battery Life
Replaceability
Clock Function
Note 3
Control System
8 (Q4 to Q7, Q10 to Q13))
4 (Q14 to Q17)
Flash ROM (10,000 rewriting life)
Backup data: Internal relay, shift register, counter current value,
data register
Note 2
, clock data (year, month, and day)
Approx. 30 days (typical) at 25°C after backup battery fully charge
Lithium
Approx. 15 hours for charging from 0% to 90% of full charge
5 years
Not possible
Clock accuracy: ±30 sec/month (typical) at 25°C
Stored program system
Specifications con’t on next page
18 (I0 to I7, I10 to I17, I20, I21)
6 (I22 to I27)
16
4 (Q0 to Q3)
12 (Q4 to Q7, Q10 to Q13, Q14 to Q17)
–
FT1A-H40RKA, H40RSA, B40RKA, B40RSA
47,400 bytes (11,850 steps)
24
24 (I0 to I7, I10 to I17, I20 to I27)
–
FT1A-H40RC, B40RC
Specifications con’t
Part Numbers
Instruction Words
Processing Time
Internal Relay
Shift Register
Data Register
Counter (adding, reversible)
Timer (1-sec, 100ms,10ms, 1ms)
Input Filter
Catch Input/Interrupt Input
Self-diagnostic Function
Points
High-speed Counter
Maximum Counter Frequency
Counting Range
Operation Mode
Pulse Output (Maximum
frequency: 100kHz)
Pulse Output (Maximum
frequency: 5kHz)
Analog Voltage Input
Points
Points
Points (Terminal No.)
Input voltage Range
Digital Resolution
Points
USB Port
Expansion Communication Ports
Ethernet Port
Memory Cartridge Connectors
SD Memory Card Slots
1. Step is equivalent to 4 bytes.
2. Among data registers D0 to D1999, only D0 to D999 are backed up.
3. Set the calendar/clock using the clock function in WindLDR.
USB Standard
Connector
Input Points
Basic Instructions
Advanced Instructions
Basic Instruction
END Processing
FT1A-H40RKA, H40RSA, B40RKA, B40RSA
42
DC: 125, AC: 111
0.95ms (1000 steps)
640μs
1024
128
2,000
200
200
Without filter, 3 to 15ms (selectable in increments of 1ms)
6
Keep data, Power failure, Clock error, Watchdog timer, Timer/counter preset value change error,
User program syntax, User program execution, System error, Memory cartridge transfer error
Total 6 points
0 to 4,294,967,295 (32 bit)
Rotary encoder mode and adding counter mode
2 (Q14, Q15)
2 (Q16, Q17)
6 (I22 to I27)
0 to 10V DC
0 to 1000
1
USB 2.0
Mini-B type
2
1
1
1
–
–
–
–
Single/two-phase selectable: 100kHz (2 points) , Single-phase: 100kHz (4 points)
FT1A-H40RC, B40RC
Dimensions (mm)
With LCD
FT1A-H40*A/*C
160 160
160
FT1A-H***A FT1A-H***C
60 60
78
Without LCD
FT1A-B40*A/*C
160 160
160
FT1A-B***A
60 60
FT1A-B***C
78
(60)
90
110
90
110
90
110
90
110
90
110
5
5
5
5
Mounting Hole Layout
144
(90)
100
(160)
IDEC Corporation
•
1175 Elko Drive
•
Sunnyvale, CA 94089
•
800-262-IDEC (4332)
•
Fax: 408-745-5258
•
www.IDEC.com/usa
©2013 IDEC Corporation. All Rights Reserved.
03/13
PDF only
