RHG7628-CPU-410GSFP-DC datasheet, PDF

Datasheet> All Categories > Module/solution> RHG7628-CPU-410GSFP-DC

RHG7628-CPU-410GSFP-DC: DescriptionNETWORK SWITCH-MANAGED 24 PORT; CategoryModule/solution; File Size5MB，205 Pages; ManufacturerATOP Technologies

Download Datasheet Parametric Compare View All

RHG7628-CPU-410GSFP-DC Overview

NETWORK SWITCH-MANAGED 24 PORT

RHG7628-CPU-410GSFP-DC Parametric

Parameter Name	Attribute value
type	Switch - Managed
Configuration	Modular-Rack
Number of ports	24
copper port	16
Copper type	10/100/1000
Fiber optic port	12
Fiber type	SFP
SFP/XFP port	12
SFP/XFP type	SFP, Gigabit
PoE port	8
Connector type	RJ45，SFP
Voltage - input	48 ~ 57VDC
Intrusion protection	IP30
Installation type	DIN rail
Operating temperature	-40°C ~ 75°C

Preview

Download Datasheet

View All

Industrial Managed

Layer-3 Ethernet Switch

User Manual

Atop Technologies, Inc.

Industrial Managed

Layer-3 Switch

User Manual

V1.3

September 28

, 2017

Series covered by this manual:

EHG76XX, EHG96XX, RHG76XX*, EHG77XX*, EMG86XX,

The user interface on these products may be slightly different

from the one shown on this user manual

This PDF Document contains internal hyperlinks for ease of navigation.

For example, click on any item listed in the

Table of Contents

to go to that page.

Published by:

Page

205

Industrial Managed

Layer-3 Ethernet Switch

User Manual

Important Announcement

The information contained in this document is the property of Atop Technologies, Inc., and is supplied for the sole

purpose of operation and maintenance of Atop Technologies, Inc., products.

No part of this publication is to be used for any other purposes, and it is not to be reproduced, copied, disclosed,

transmitted, stored in a retrieval system, or translated into any human or computer language, in any form, by any

means, in whole or in part, without the prior explicit written consent of Atop Technologies, Inc.,

Offenders will be held liable for damages and prosecution.

All rights, including rights created by patent grant or registration of a utility model or design, are reserved.

Disclaimer

We have checked the contents of this manual for agreement with the hardware and the software described. Since

deviations cannot be precluded entirely, we cannot guarantee full agreement. However, the data in this manual is

reviewed regularly and any necessary corrections will be included in subsequent editions.

Suggestions for improvement are welcome. All other product’s names referenced herein are registered trademarks

of their respective companies.

Preface

This manual contains some advanced network management knowledge, instructions, examples, guidelines, and

general theories. The contents are designed to help users manage the switch and use its software, a background

in general theory is a must, when reading it. Please refer to the Glossary for technical terms and abbreviations.

Who Should Use This User Manual

This manual is to be used by qualified network personnel or support technicians who are familiar with network

operations, and might be useful for system programmers or network planners as well. This manual also provides

helpful and handy information for first time users. For any related problems, please contact your local distributor. If

they are unable to assist you, please redirect your inquiries to www.atop.com.tw.

Warranty Period

Atop technology provides a limited 5-year warranty for managed Ethernet switches.

Documentation Control

Author:

Revision:

Revision History:

Creation Date:

Last Revision Date:

Product Reference:

Document Status:

Matteo Tabarelli

1.3

DIP switch configuration, OSPFv2 enhancement

2 November 2016

27 November 2017

Layer-3 Managed Switch

Released

Page

205

Industrial Managed

Layer-3 Ethernet Switch

User Manual

Table of Contents

1.1

1.2

Introduction ................................................................................................................14

Introduction to Industrial Managed Switch ..................................................................................... 14

Software Features .......................................................................................................................... 15

Configuring with a Web Browser ...............................................................................16

2.1

Web-based Management Basics ................................................................................................... 16

2.1.1 Default Factory Settings ................................................................................................................. 16

2.1.2 Login Process and Main Window Interface .................................................................................... 17

2.2

Basic Information............................................................................................................................ 18

2.2.1 Sys Info .......................................................................................................................................... 18

2.2.2 Device Information Setting ............................................................................................................. 19

2.2.3 Console Setting .............................................................................................................................. 19

2.2.4 Protocols Status ............................................................................................................................. 20

2.2.5 Power Status .................................................................................................................................. 21

2.2.6 Temperature Log ............................................................................................................................ 21

2.3

Administration ................................................................................................................................. 23

2.3.1 Password ........................................................................................................................................ 23

2.3.2 IP Setting ........................................................................................................................................ 25

2.3.3 IPv6 Setting .................................................................................................................................... 28

2.3.4 Ping ................................................................................................................................................ 30

2.3.5 Ping6 .............................................................................................................................................. 31

2.3.6 Mirror Port ...................................................................................................................................... 32

2.3.7 System Time .................................................................................................................................. 33

2.3.8 Modbus Setting .............................................................................................................................. 34

2.3.9 Precision Time Protocol (PTP) ....................................................................................................... 42

2.3.10 Secure Shell - SSH ........................................................................................................................ 46

2.3.11 Telnet ............................................................................................................................................. 46

2.3.12 DIP Switch ...................................................................................................................................... 47

2.4

IP Routing (Layer-3 Switching Features) ....................................................................................... 47

2.4.1 IP Routing’s Setting ........................................................................................................................ 48

2.4.2 IPv4 Static Routing ......................................................................................................................... 48

2.4.3 RIP Setting ..................................................................................................................................... 49

2.4.4 OSPF Settings ................................................................................................................................ 50

2.4.5 OSPF Global Setting ...................................................................................................................... 51

2.4.6 OSPF Area Setting ......................................................................................................................... 51

2.4.7 OSPF Interface Setting .................................................................................................................. 52

2.4.8 OSPF Virtual Link Setting .............................................................................................................. 54

2.4.9 OSPF Area Aggregation Setting .................................................................................................... 55

2.4.10 OSPF Routing Table ...................................................................................................................... 56

2.5

Forwarding ..................................................................................................................................... 57

2.5.1 QoS ................................................................................................................................................ 57

2.5.2 Rate Control ................................................................................................................................... 61

2.5.3 Storm Control ................................................................................................................................. 62

2.6

Port-related settings ....................................................................................................................... 64

2.6.1 Port Setting ..................................................................................................................................... 65

2.6.2 Port Status ...................................................................................................................................... 66

2.6.3 Mini-GBIC Port Status .................................................................................................................... 67

2.6.4 Port Statistics ................................................................................................................................. 67

2.7

Power over Ethernet....................................................................................................................... 69

2.7.1 PoE Setting .................................................................................................................................... 69

2.7.2 PoE Status ..................................................................................................................................... 70

2.7.3 PoE Alarm Setting .......................................................................................................................... 71

2.8

Trunking ......................................................................................................................................... 72

Page

205

Industrial Managed

Layer-3 Ethernet Switch

User Manual

2.8.1 Trunking Setting ............................................................................................................................. 72

2.8.2 LACP Status ................................................................................................................................... 74

2.9

2.9.1

2.9.2

2.9.3

2.9.4

Unicast/Multicast MAC ................................................................................................................... 76

Add Static MAC .............................................................................................................................. 77

Black-List MAC ............................................................................................................................... 78

MAC Aging Time ............................................................................................................................ 78

MAC Table ..................................................................................................................................... 79

2.10

GARP/GVRP/GMRP ...................................................................................................................... 81

2.10.1 Multicast Group Table .................................................................................................................... 81

2.10.2 GARP Setting ................................................................................................................................. 82

2.10.3 GVRP Setting ................................................................................................................................. 83

2.10.4 GMRP Setting ................................................................................................................................ 85

2.11

IP Multicast ..................................................................................................................................... 86

2.11.1 IGMP .............................................................................................................................................. 87

2.11.2 Static IP Multicast ........................................................................................................................... 93

2.12

SNMP ............................................................................................................................................. 94

2.12.1 SNMP Agent ................................................................................................................................... 95

2.12.2 SNMP V1/V2c Community Setting ................................................................................................. 96

2.12.3 Trap Setting .................................................................................................................................... 96

2.12.4 SNMPv3 Auth. Setting.................................................................................................................... 97

2.13

Spanning Tree ................................................................................................................................ 99

2.13.1 Spanning Tree Setting.................................................................................................................. 100

2.13.2 Bridge Info .................................................................................................................................... 102

2.13.3 Port Setting ................................................................................................................................... 103

2.13.4 MSTP Instance ............................................................................................................................. 105

2.14

VLAN ............................................................................................................................................ 107

2.14.1 VLAN Setting ................................................................................................................................ 108

2.14.2 802.1Q VLAN ............................................................................................................................... 109

2.14.3 Port-Based VLAN ......................................................................................................................... 112

2.14.4 MAC-Based VLAN........................................................................................................................ 113

2.14.5 IP Subnet-Based VLAN ................................................................................................................ 113

2.14.6 Protocol-Based VLAN .................................................................................................................. 114

2.14.7 QinQ ............................................................................................................................................. 115

2.15

Security ........................................................................................................................................ 117

2.15.1 Port Security ................................................................................................................................. 117

2.15.2 802.1X .......................................................................................................................................... 119

2.15.3 ACL............................................................................................................................................... 123

2.16

MACsec (802.1AE) * (selected devices only) .............................................................................. 126

2.16.1 Static SAK .................................................................................................................................... 126

2.16.2 Static CAK .................................................................................................................................... 127

2.17

ERPS Ring ................................................................................................................................... 128

2.17.1 ESRP Setting ............................................................................................................................... 130

2.17.2 iA-Ring Settings ............................................................................................................................ 135

2.17.3 C-Ring

(Compatible-Ring)

Settings .............................................................................................. 137

2.17.4 U-Ring .......................................................................................................................................... 137

2.17.5 Compatible-Chain Settings .......................................................................................................... 140

2.18

LLDP............................................................................................................................................. 143

2.18.1 LLDP Settings .............................................................................................................................. 143

2.18.2 LLDP Neighbors ........................................................................................................................... 144

2.19

PROFINET ................................................................................................................................... 146

2.19.1 PROFINET Settings ..................................................................................................................... 146

Page

205

RHG7628-CPU-410GSFP-DC Related Products

	RHG7628-CPU-410GSFP-DC	RHG7628-CPU-410GSFP-R
Description	NETWORK SWITCH-MANAGED 24 PORT	NETWORK SWITCH-MANAGED 24 PORT
type	Switch - Managed	Switch - Managed
Configuration	Modular-Rack	Modular-Rack
Number of ports	24	24
copper port	16	16
Copper type	10/100/1000	10/100/1000
Fiber optic port	12	12
Fiber type	SFP	SFP
SFP/XFP port	12	12
SFP/XFP type	SFP, Gigabit	SFP, Gigabit
PoE port	8	8
Connector type	RJ45，SFP	RJ45，SFP
Voltage - input	48 ~ 57VDC	48 ~ 57VDC
Intrusion protection	IP30	IP30
Installation type	DIN rail	DIN rail
Operating temperature	-40°C ~ 75°C	-40°C ~ 75°C

Recommended Resources

Loopback comparator circuit

LA6520 three-terminal output operational power amplifier circuit diagram

Simplified circuit diagram for charging current control

Voltage output display part circuit diagram

Photoelectric coupling timing control circuit

555 household appliance protector circuit

Opencv library call problem: If the hps part on the DE1-SoC board calls the opencv library, does the software have to be written in C++?...; 的神等等 FPGA/CPLD

mega48pa-au encountered a problem: I don't know which software and download cable to use to identify it. When I used 64 before, I could use ISPDOWN to identify it. Can you please tell me?...; freelife80 MCU

[Ask TI] Confusion about cmd memory allocation and program burning: I'm looking at ckfa recently and have the following questions: 1. When the program is burned, does it place the execution program and constants directly according to the memory allocation of cmd? 2. I...; 安_然 Microcontroller MCU

Is there any company that specializes in microcontroller design solutions?: Are there any companies that specialize in MCU design solutions? That is, other companies have needs, and then the MCU design solution company will provide solutions based on the actual situation, inc...; qianbing Embedded System

C Language Manual: Shared C language manual, hoping to bring useful content to others...; liuyy0928 DSP and ARM Processors

Principle of six-wire resistance measurement: I am a novice, and I have just started working on this kind of thing. I always can't find the principle of six-wire measurement. Can someone who has done it tell me about its principle and implementat...; 春风维修 Embedded System

Shortcut: A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 AA AB AC AD AE AF AG AH AI AJ AK AL AM AN AO AP AQ AR AS AT AU AV AW AX AY AZ B0 B1 B2 B3 B4 B5 B6 B7 B8 B9 BA BB BC BD BE BF BG BH BI BJ BK BL BM BN BO BP BQ BR BS BT BU BV BW BX BY BZ C0 C1 C2 C3 C4 C5 C6 C7 C8 C9 CA CB CC CD CE CF CG CH CI CJ CK CL CM CN CO CP CQ CR CS CT CU CV CW CX CY CZ D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 DA DB DC DD DE DF DG DH DI DJ DK DL DM DN DO DP DQ DR DS DT DU DV DW DX DZ

Popular Components
