Continued from the preceding page.
1
■
Construction
PVZ2R
#2-Terminal
■
Standard Land Pattern
PVZ2R
0.9
0.6
Driver Plate
3.0 Dia.
#1-Terminal
Wiper
2.5
0.7
0.6
0.7
0.6
2.5
Resistive
Element
#3-Terminal
Resin Substrate
(
Tolerancein:
±0.1
)
mm
■
Characteristics
Humidity Exposure
High Temperature
Exposure
Humidity Load Life
Load Life
Temperature Cycle
Temperature Coefficient
of Resistance
Rotational Life
Res. Change : +10, -2%
Res. Change : R
<
50kohm···+2, -10%
=
50kohm<R···+2, -15%
Res. Change :
±10%
Res. Change : R
<
50kohm···+2, -10%
=
50kohm<R···+2, -15%
Res. Change :
±5%
±500ppm/˚C
Res. Change :
±10%
(10 cycles)
PVA2 Series
0.45±0.1
1. Ultra-small and thin external dimensions of
2.2(W)x2.75(L)x0.90 max.(T)mm.
2. For the terminal attachment method of construction
which uses neithr solder nor adhesives, good
solderability and terminal attachment intensity
are realized.
3. Beause of multi-contact wiper structure, PVA2 have
a stable characteristics (low noise).
4. PVA2 series don't use a solder, flux and cleaning
solvent, so they are environmentally friendly
products.
5. Heat resistance performance enables high temperature
peak re-flow soldering.
6. PVA2 series comply with RoHS directive.
1.3
2.75
1.3
0.75
Resin
0.6
0.9
0.6
#1
#3
0.5
#2 (Wiper Contact)
#1
#3
CLOCKWISE
CIRCUIT
(
Tolerance:
±0.2
)
in mm
■
Applications
1. Thin-model optical pick-up module
2. LCD module
3. Optical communication module
4. Small sensor module
5. Digital camera
6. Small telecommunicaion equipment, etc.
Power Rating
(W)
0.1(70°C)
0.1(70°C)
0.1(70°C)
0.1(70°C)
Number of Turns
(Effective Rotation Angle)
1(260°±10°)
1(260°±10°)
1(260°±10°)
1(260°±10°)
TCR
(ppm/°C)
±250
±250
±250
±250
Part Number
PVA2A101A01
PVA2A151A01
PVA2A221A01
PVA2A331A01
Soldering Method
Reflow/Soldering Iron
Reflow/Soldering Iron
Reflow/Soldering Iron
Reflow/Soldering Iron
Total Resistance Value
100ohm
±25%
150ohm
±25%
220ohm
±25%
330ohm
±25%
Continued on the following page.
8
0.5
■
Features
2.2
#2
0.8±0.1
2.4 Dia
0.4
0.8
!Note
• This PDF catalog is downloadedand
!CAUTION
(forMurata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our products in it may be discontinued without advance notice. Please check with our
!Note
• Please read rating from the website of storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
sales representatives or product engineers before ordering.
• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
• This PDF catalog has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
R50E.pdf
05.9.9
1
PVZ2/PVA2 Series Notice
■
Notice (Operating and Storage Conditions)
1. Store in temperatures of -10 to +40 deg. C and
relative humidity of 30-85%RH.
2. Do not store in or near corrosive gases.
3. Use within six months after delivery.
4. Open the package just before using.
5. Do not store under direct sunlight.
6. If you use the trimmer potentiometer in an
environment other than listed below, please
consult with a Murata factory representative prior
to using.
The trimmer potentiometer should not be used under
the following environmental conditions:
(1) Corrosive gaseous atmosphere
(Ex. Chlorine gas, Hydrogen sulfide gas, Ammonia
gas, Sulfuric acid gas, Nitric oxide gas, etc.)
(2) In liquid
(Ex. Oil, Medical liquid, Organic solvent, etc.)
(3) Dusty/dirty atmosphere
(4) Direct sunlight
(5) Static voltage nor electric/magnetic fields
(6) Direct sea breeze
(7) Other variations of the above
■
Notice (Rating)
1. When using with partial load (rheostat), minimize
the power depending on the resistance value.
2. The maximum input voltage to a trimmer
potentiometer should not exceed (P
•
R)^1/2 or the
maximum operating voltage, whichever is smaller.
3. If the trimmer potentiometer is used in DC and high
humidity conditions, please connect wiper (#2) for
plus and resistive element (#1 or #3) for minus.
(PVZ Series only)
■
Notice (Soldering and Mounting)
1. Soldering
(1) Reflow soldering method and soldering iron are
available. Cannot be soldered using the flow
soldering method (dipping). If you use the flow
soldering method, the trimmer potentiometer may
not function.
(2) Use our standard land dimension. Excessive land
area causes displacement due to the effect of
the surface tension of the solder. Insufficient
land area leads to insufficient soldering
strength of the chip.
(3) Soldering condition
Refer to the temperature profile.
If the soldering conditions are not suitable,
e.g., excessive time and/or excessive
temperature, the trimmer potentiometer may
deviate from the specified characteristics.
(4) Apply the appropriate amount of solder paste.
The thickness of solder paste should be printed
from 100 micro m to 150 micro m and the
dimension of land pattern used should be Murata's
standard land pattern at reflow soldering.
Insufficient amounts of solder can lead to
insufficient soldering strength on PCB.
Excessive amounts of solder may cause bridging
between the terminals.
(5) The soldering iron should not come in contact
with the case of the trimmer potentiometer. If
such contact does occur, the trimmer
potentiometer may be damaged.
2. Mounting
(1) Do not apply excessive force (preferably 4.9N
(Ref.; 500gf) max.), when the trimmer
potentiometer is mounted to the PCB.
(2) Do not warp and/or bend PC board to prevent
trimmer potentiometer from breakage.
(3) In chip placers, the recommended size of the
cylindrical pick-up nozzle should be outer
dimension 1.5-1.8mm dia. and inner dimension
1.3mm dia.
3. Cleaning
(1) In case there is flux on the resistive element,
clean sufficiently with cleaning solvents and
completely remove all residual flux.
(2) Isopropyl-alcohol and Ethyl-alcohol are
applicable solvents for cleaning. If you use any
other types of solvents, please evaluate
performance by your product.
10
!Note
• This PDF catalog is downloadedand
!CAUTION
(forMurata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our products in it may be discontinued without advance notice. Please check with our
!Note
• Please read rating from the website of storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
sales representatives or product engineers before ordering.
• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
• This PDF catalog has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product specifications or transact the approval sheet for product specifications before ordering.
R50E.pdf
05.9.9
PVZ2/PVA2 Series Notice
■
Soldering Profile
Reflow Soldering Profile
1. Soldering profile for Lead-free solder (96.5Sn/3.0Ag/0.5Cu)
T5
Temperature (°C)
T3
T2
T1
t2
t3
Limit Profile
Standard Profile
T4
1
t1
Time (s)
Standard Profile
Pre-heating
Series
Temp. (T1)
°C
Time (t1)
sec.
Peak
Heating
Cycle of
Temperature
Reflow
Temp. (T2) Time (t2)
(T3)
°C
sec.
°C
Time
Pre-heating
Temp. (T1)
°C
Time (t1)
sec.
Limit Profile
Heating
Temp. (T4)
°C
Peak
Cycle of
Temperature
Reflow
Time (t3)
(T5)
sec.
°C
Time
PVA2
PVZ2****A**
PVZ2****C**
150 to 180 60 to 120
130 to 160 60 to 120
150 to 180 60 to 120
220
200
220
30 to 60
20 to 50
30 to 60
245±3
245±3
245±3
2
2
2
150 to 180 60 to 120
130 to 160 60 to 120
150 to 180 60 to 120
220
200
220
30 to 60
20 to 50
30 to 60
260 +5/-0
250
260
2
2
2
2. Soldering profile for Eutectic solder (63Sn/37Pb)
(Limit profile: refer to 1)
Standard Profile
Pre-heating
T2
T1
t2
Standard Profile
Temperature (°C)
T3
Heating
Temp. (T2)
°C
Series
Temp. (T1)
°C
Time (t1)
sec.
Peak
Cycle of
Temperature
Reflow
Time (t2)
(T3)
sec.
°C
Time
t1
time (s)
PVA2
PVZ2****A**
PVZ2****C**
150
60 to 120
183
30
230
1
Soldering Iron
Standard Condition
Series
Temperature of Soldering Iron Tip
°C
Soldering Time
sec.
Soldering Iron Power Output
W
Cycle of Soldering Iron
Time
PVA2
PVZ2****A**
PVZ2****C**
350±10
3 max.
30 max.
1
■
Notice (Handling)
1. Use suitable screwdrivers that fit comfortably in
driver slot. We recommend the screwdriver below.
* Recommended screwdriver for manual adjustment
Murata P/N: KMDR190
2. Don't apply more than 4.9N (Ref.; 500gf) of twist
and stress after mounting onto PCB to prevent
contact intermittence. If excessive force is
applied, the trimmer potentiometer may not
function.
3. Please use within the effective rotational angle.
The trimmer potentiometer does not have a
mechanical stop for over rotation. In cases out of
effective rotational angle, the trimmer
potentiometer may not function.
4. When using a lock paint to fix slot position or
cover the rotor, please evaluate performance by
your product. Lock paint may cause corrosion or
electrical contact problems.
■
Notice (Other)
1. Please make sure that your product has been
evaluated and confirmed against your
specifications when our product is mounted to your
product.
2. Murata cannot guarantee trimmer potentiometer
integrity when used under conditions other than
those specified in this document.
11
