Datasheet> All Categories > Discrete semiconductor> diode> 1N4148

Preview

1N4148: Description0.2 A, SILICON, SIGNAL DIODE, DO-35; CategoryDiscrete semiconductor diode; File Size323KB，3 Pages; ManufacturerFORMOSA; Websitehttp://www.formosams.com/

Download Datasheet Parametric Compare View All

1N4148 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N4148	-	-	View	Buy Now

1N4148 Overview

0.2 A, SILICON, SIGNAL DIODE, DO-35

1N4148 Parametric

Parameter Name	Attribute value
Maker	FORMOSA
Parts packaging code	DO-35
package instruction	O-LALF-W2
Contacts	2
Reach Compliance Code	unknow
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1 V
JEDEC-95 code	DO-35
JESD-30 code	O-LALF-W2
Maximum non-repetitive peak forward current	2 A
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	0.15 A
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Maximum power dissipation	0.5 W
Maximum repetitive peak reverse voltage	100 V
Maximum reverse recovery time	0.004 µs
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL

Preview

Download Datasheet

View All

F

ORMOSA

MS

1N4148/1N4448

High-speed switching diode

Features

1.

2.

High reliability

High speed (t

rr

=

4 ns)

Applications

Extreme fast switches

Construction

Silicon epitaxial planar

Absolute Maximum Ratings

T

j

=25?

Parameter

Repetitive peak reverse voltage

Reverse voltage

Peak forward surge current

Repetitive peak forward voltage

Forward current

Average forward current

Power dissipation

Junction temperature

Storage temperature range

V

R

=0

I=4mm T

L

=

25?

t

p

=1µ s

Test Conditions

Type

Symbol

V

RRM

V

R

I

FSM

I

FRM

I

F

I

FAV

P

V

T

j

T

stg

Value

100

75

2

500

300

150

500

175

-65~+175

Unit

V

A

mA

mW

?

Maximum Thermal Resistance

T

j

=25?

Parameter

Junction ambient

Test Conditions

I=4mm T

L

=constant

Symbol

R

thJA

Value

350

Unit

K/W

FORMOSA MS

1

1N4148 Related Products

	1N4148	1N4448
Description	0.2 A, SILICON, SIGNAL DIODE, DO-35	0.15 A, SILICON, SIGNAL DIODE, DO-204AH
Maker	FORMOSA	FORMOSA
Parts packaging code	DO-35	DO-35
package instruction	O-LALF-W2	O-LALF-W2
Contacts	2	2
Reach Compliance Code	unknow	unknown
ECCN code	EAR99	EAR99
Shell connection	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE
Diode component materials	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	1 V	0.72 V
JEDEC-95 code	DO-35	DO-35
JESD-30 code	O-LALF-W2	O-LALF-W2
Maximum non-repetitive peak forward current	2 A	2 A
Number of components	1	1
Number of terminals	2	2
Maximum operating temperature	150 °C	150 °C
Minimum operating temperature	-55 °C	-55 °C
Maximum output current	0.15 A	0.15 A
Package body material	GLASS	GLASS
Package shape	ROUND	ROUND
Package form	LONG FORM	LONG FORM
Maximum power dissipation	0.5 W	0.5 W
Maximum repetitive peak reverse voltage	100 V	100 V
Maximum reverse recovery time	0.004 µs	0.004 µs
surface mount	NO	NO
Terminal form	WIRE	WIRE
Terminal location	AXIAL	AXIAL
