SWM30-48-EV-P6 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> SWM30-48-EV-P6

SWM30-48-EV-P6: DescriptionAC/DC WALL MOUNT 48V 30W; CategoryPower/power management; File Size306KB，5 Pages; ManufacturerCUI; Websitehttp://www.cui.com; Environmental Compliance

Download Datasheet Parametric View All

SWM30-48-EV-P6 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SWM30-48-EV-P6	-	-	View	Buy Now

SWM30-48-EV-P6 Overview

AC/DC WALL MOUNT 48V 30W

SWM30-48-EV-P6 Parametric

Parameter Name	Attribute value
Use area	Europe
form	Wall mounting
input type	Fixed insert
Voltage - input	90 ~ 264 VAC
Voltage - Output	48V
Current - Output (maximum)	620mA
Power (W)	30W
No-load power consumption	75mW (maximum)
polarization	positive center
application	Medical type
efficiency	Level VI, CoC Tier 2
Operating temperature	0°C ~ 40°C
Output connector	Round tube plug, 2.5mm inner diameter x 5.5mm outer diameter x 9.5mm
size/dimensions	2.99" long x 1.69" wide x 1.16" high (75.9mm x 42.9mm x 29.5mm)
Approval	CE，TUV
input connector	CEE 7/16
Wire length	47.2"（1.20m）

Preview

Download Datasheet

View All

For more information, please visit the

product page

For information on related products, view

Dc Power Connectors

date

page

06/27/2017

1 of 5

SERIES:

SWM30-E

│

DESCRIPTION:

AC-DC POWER SUPPLY

FEATURES

• up to 30 W power

• EN 60601-1 4th edition

• compact design

• universal input (90~264 Vac)

• single regulated output from 5~48 Vdc

• over voltage and short circuit protections

• DOE Level VI / CoC Tier 2 efficiency

• 2 MOPP compliant

MODEL

SWM30-5-EV

SWM30-9-EV

SWM30-12-EV

SWM30-15-EV

SWM30-18-EV

SWM30-24-EV

SWM30-36-EV

SWM30-48-EV

Notes:

output

voltage

(Vdc)

output

current

max

(A)

output

power

max

(W)

ripple

and noise

max

(mVp-p)

efficiency

level

4.0

3.0

2.0

1.66

1.50

0.83

0.62

100

180

250

350

480

1. At full load, 100 ~ 240 Vac input, 20 MHz bandwidth oscilloscope, output terminated with a low ESR 47 μF electrolytic and 0.1 μF multilayer capacitor.

2. CoC Tier 2 compliant.

PART NUMBER KEY

SWM30

- E V

XXX

CXX

Base Number

Output Voltage

AC Input Type:

Europe

Orientation:

V = vertical

Reserved for Custom

Configurations

DC Plug Type:

XXX = See output plug options

on page 4 for more details

cui.com
