M2217 SL005 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wire/cable> M2217 SL005

M2217 SL005: DescriptionMULTI-PAIR 8COND 18AWG 100'; CategoryWire/cable; File Size179KB，3 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric Compare View All

M2217 SL005 Overview

MULTI-PAIR 8COND 18AWG 100'

M2217 SL005 Parametric

Parameter Name	Attribute value
Cable type	Multiple pairs
Number of conductors	8 (4 twisted pairs)
Wire gauge	18 AWG
Number of wire strands	7/28
conductor material	bare copper
Sheath (insulation) material	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.300"（7.62mm）
Shield type	-
length	100.0'（30.5m）
Casing color	slate color
grade	-
characteristic	-
Voltage	300V
Operating temperature	-20°C ~ 75°C
use	-
Sheath (insulation) thickness	0.0150"（0.381mm）
conductor insulation	Polyvinyl chloride (PVC)
shielding material	-
Shielding range	-

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. M2217

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Pair

c) Pair

(1) Twists:

2) Cable Assembly

a) Twists:

3) Jacket

a) Color(s)

Color

BLACK-RED

BLACK-WHITE

4 X 1 PAIR

18 (7/26) AWG BC

0.010" Wall, Nom. PVC

Alpha Wire Color Code A1

Pair

Color

BLACK-GREEN

BLACK-BLUE

Pair

Color

0.048

0.068

2/Cond Cabled Together

6.0 Twists/foot (min)

4 Components Cabled

3.0 Twists/foot (min)

0.015" Wall, Nom.,PVC

SLATE

ALPHA WIRE-* P/N M2217 4PR 18 AWG

0.300 (0.313 Max.)

b) Print

EXXXXXX 75C CMR (UL) C(UL) CE ROHS

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

Applicable Specifications

1) UL

2) CSA International

3) CE:

CMR

C(UL) TYPE CMR

EU Low Voltage Directive 2006/95/EC

75°C

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS

Compliance on this item. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Mutual Capacitance

3) Characteristic Impedance

4) Inductance

5) Conductor DCR

-20 to 75°C

10X Cable Diameter

111 Lbs, Maximum

(For Engineering purposes only)

300 V

RMS

38 pf/ft @1 kHz, Nominal

55 Ω

0.16 µH/ft, Nominal

6.1 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 500 FT

c) 100 FT

d) Bulk(Made-to-order)

Flange x Traverse x Barrel (inches)

16 x 11 x 8 Continuous length

12 x 10 x 5 Continuous length

12 x 4.5 x 3.5 Continuous length

[Spool dimensions may vary slightly]

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: M2217

M2217 , RoHS-Compliant Commencing With 7/1/2005 Production

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive, with regards to restrictions of the use of certain hazardous substances used in the manufacture of

electrical and electronic equipment. The reader is referred to this Directive for the specific definitions and extents of this Directive. No Exemptions

are required for RoHS Compliance on this item. It should be noted that this product does not fall within the scope of Directive 2011/65/EU, but this

Certificate is offered for cases where this product will be used within EEE that does fit within the Directive's scope. Additionally, Alpha certifies that

the listed part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-

2006.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire Company:

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

Dave Watson, Director of Engineering & QA

5/13/2013

M2217 SL005 Related Products

	M2217 SL005	M2217 SL001	M2217 SL002
Description	MULTI-PAIR 8COND 18AWG 100'	MULTI-PAIR 8COND 18AWG 1000'	MULTI-PAIR 8COND 18AWG 500'
Cable type	Multiple pairs	Multiple pairs	Multiple pairs
Number of conductors	8 (4 twisted pairs)	8 (4 twisted pairs)	8 (4 twisted pairs)
Wire gauge	18 AWG	18 AWG	18 AWG
Number of wire strands	7/28	7/28	7/28
conductor material	bare copper	bare copper	bare copper
Sheath (insulation) material	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.300"（7.62mm）	0.300"（7.62mm）	0.300"（7.62mm）
length	100.0'（30.5m）	1000.0'（304.8m）	500.0'（152.4m）
Casing color	slate color	slate color	slate color
Voltage	300V	300V	300V
Operating temperature	-20°C ~ 75°C	-20°C ~ 75°C	-20°C ~ 75°C
Sheath (insulation) thickness	0.0150"（0.381mm）	0.0150"（0.381mm）	0.0150"（0.381mm）
conductor insulation	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)	Polyvinyl chloride (PVC)
