HMC527LC4
v03.0514
GaAs MMIC I/Q MIXER
8.5 - 13.5 GHz
Typical Applications
The HMC527LC4 is ideal for:
Features
Wide IF Bandwidth: DC - 2 GHz
Image Rejection: 35 dB
LO to RF Isolation: 45 dB
High Input IP3: +28 dBm
24 Lead 4x4mm SMT Package: 16mm²
MIXERS - I/Q, IRMS & RECEIVERS - SMT
• Point-to-Point Radios
• Point-to-Multi-Point Radios & VSAT
• Test Equipment & Sensors
• Military End-Use
Functional Diagram
General Description
The HMC527LC4 is a compact general purpose
I/Q MMIC mixer in a leadless RoHS compliant SMT
package, which can be used as either an Image
Reject Mixer or a Single Sideband Upconverter. The
mixer utilizes two standard Hittite double balanced
mixer cells and a 90 degree hybrid fabricated in a
GaAs MESFET process. A low frequency quadrature
hybrid was used to produce a 100 MHz USB IF output.
This product is a much smaller alternative to hybrid
style Image Reject Mixers and Single Sideband
Upconverter assemblies. The HMC527LC4 eliminates
the need for wire bonding allowing use of surface
mount manufacturing techniques.
Electrical Specifications,
T
A
= +25 °C, IF= 100 MHz, LO = +19 dBm*
Parameter
Frequency Range, RF/LO
Frequency Range, IF
Conversion Loss (As IRM)
Image Rejection
1 dB Compression (Input)
LO to RF Isolation
LO to IF Isolation
IP3 (Input)
Amplitude Balance
Phase Balance
37
17
17
Min.
Typ.
8.5 - 13.5
DC - 2
8
25
+21
45
22
+25
0.6
6
37
18
10
27
Max.
Min.
Typ.
10.5 -12
DC - 2
7.5
34
+21
45
24
+28
0.4
6
9.5
Max.
Units
GHz
GHz
dB
dB
dBm
dB
dB
dBm
dB
Deg
* Unless otherwise noted, all measurements performed as downconverter.
1
For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
HMC527LC4
v03.0514
GaAs MMIC I/Q MIXER
8.5 - 13.5 GHz
Data taken as IRM with External IF Hybrid
Conversion Gain vs. Temperature
0
Image Rejection vs. Temperature
CONVERSION GAIN (dB)
-5
IMAGE REJECTION (dB)
40
30
+25C
+85C
-40C
-10
20
-15
+25 C
+85 C
-40 C
10
-20
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
0
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
Conversion Gain vs. LO Drive
0
Return Loss
0
CONVERSION GAIN (dB)
RETURN LOSS (dB)
-5
-5
-10
-10
-15
RF
LO
-15
+17dBm
+19dBm
+21dBm
-20
-20
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
-25
8
9
10
11
12
13
14
FREQUENCY (GHz)
Input P1dB vs. Temperature
24
22
20
P1dB (dBm)
18
16
14
12
10
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
+25C
+85C
-55C
Input IP3 vs. LO Drive
35
30
25
IP3 (dBm)
20
15
10
5
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
LO = +17 dBm
LO = +19 dBm
LO = +21 dBm
For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
MIXERS - I/Q, IRMS & RECEIVERS - SMT
2
50
HMC527LC4
v03.0514
GaAs MMIC I/Q MIXER
8.5 - 13.5 GHz
Quadrature Channel Data Taken Without IF Hybrid
Isolations
IF Bandwidth*
0
RETURN LOSS
CONVERSION GAIN
MIXERS - I/Q, IRMS & RECEIVERS - SMT
-10
-20
ISOLATION (dB)
LO/IF2
RESPONSE (dB)
-5
-30
LO/IF1
-40
RF/IF1
LO/RF
-50
RF/IF2
-10
-15
-60
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
-20
0.5
1
1.5
2
2.5
3
3.5
IF FREQUENCY (GHz)
Amplitude Balance vs. LO Drive
4
Phase Balance vs. LO Drive
15
PHASE BALANCE (degrees)
10
5
0
-5
-10
-15
AMPLITUDE BALANCE (dB)
2
LO = +17dBm
LO = +19dBm
LO = +21dBm
LO = +17dBm
LO = +19dBm
LO = +21dBm
0
-2
-4
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
Upconverter Performance Conversion
Gain vs. LO Drive*
0
Upconverter Performance Sideband
Rejection vs. LO Drive*
0
SIDEBAND REJECTION (dBc)
-10
-20
-30
-40
-50
-60
CONVERSION GAIN (dB)
-5
LO = +17 dBm
LO = +19 dBm
LO = +21 dBm
-10
-15
+17 dBm
+19 dBm
+21 dBm
-20
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
8
9
10
11
12
13
14
RF FREQUENCY (GHz)
* Conversion gain data taken with external IF hybrid
3
For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
