GP10DI ........ GP10QI
1 Amp. Glass Passivated Junction Rectifier
Dimensions in mm.
DO-41
(Plastic)
Voltage
200V to 1200V
Current
1.0 A. at 55 °C.
®
5
+0.2
-0
58.5
± 0.5
Mounting instructions
1. Min. distance from body to soldering point,
4 mm.
2. Max. solder temperature, 350 °C.
3. Max. soldering time, 3.5 sec.
4. Do not bend lead at a point closer than
2 mm. to the body.
•
Glass passivated junction
•
High current capability
•
The plastic material carries
U/L recognition 94 V-0
•
Terminals: Axial Leads
•
Polarity: Color band denotes cathode
Maximum Ratings, according to IEC publication No. 134
GP10DI
V
RRM
I
F(AV)
I
FRM
I
FSM
T
j
T
stg
E
RSM
Peak recurrent reverse voltage
Forward current at Tamb = 55 °C
Recurrent peak forward current
8.3 ms. peak forward surge current
(Jedec Method)
GP10JI GP10MI
600 V
1000 V
1.0 A
10 A
50 A
– 65 to + 175 °C
– 65 to + 175 °C
20 mJ
GP10QI
1200 V
200 V
Operating temperature range
Storage temperature range
Maximum non repetitive peak
reverse avalanche energy.
I
R
= 0.5 A ; T
J
= 25 ºC
Electrical Characteristics at Tamb = 25 °C
V
F
I
R
R
thj-a
Max. forward voltage drop at I
F
= 1 A
at 25 °C
at 125 °C
Max.
Thermal resistance (I = 10 mm.) Typ.
Max. reverse current at V
RRM
1.0 V
5µA
50 µ A
60 °C/W
45 °C/W
Jan - 03
GP10DI ........ GP10QI
Rating And Characteristic Curves
TYPICAL FORWARD CHARACTERISTIC
FORWARD CURRENT DERATING CURVE
10
1.4
10 mm. - 10 mm.
1.2
2
1
1
0.8
0.2
0.1
0.6
T
j
= 25 °C
0.4
0.2
0.01
0.6
0.8
1
1.2
1.4
1.6
0
0
25
50
75 100 125 150 175
V
F '
instantaneous forward voltage (V)
Tamb, ambient temperature (
o
C)
MAXIMUM NON REPETITIVE
PEAK FORWARD SURGE CURRENT
TYPICAL JUNCTION CAPACITANCE
50
20
T
j
= 25ºC
f = 1 MHz
40
10
8
30
6
4
20
10
2
0
1
2
4 6 10
20
40
100
Number of cycles at 60 Hz.
1
0.1
0.4
1
4
10
40 100
V
R
reverse voltage (V)
Jan - 03
