1551ACLR: DescriptionBOX ABS TRN CLEAR 1.38" X 0.79"; CategoryTopical application Mechanical and electrical/engineering/automation; File Size132KB，2 Pages; ManufacturerHammond; Websitehttp://www.hammondmfg.com; Environmental Compliance

Download Datasheet Parametric View All

1551ACLR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1551ACLR	-	-	View	Buy Now

1551ACLR Overview

BOX ABS TRN CLEAR 1.38" X 0.79"

1551ACLR Parametric

Parameter Name	Attribute value
Container type	box
size/dimensions	1.380" long x 0.790" wide (35.05mm x 20.07mm)
high	0.610"（15.49mm）
Area (L x W)	1.08 in²（7.0 cm²）
design	bifurcated sides
Material	Plastic - ABS
color	translucent - transparent
thickness	0.070"（1.78mm）
characteristic	-
grade	IP54
Material flammability rating	UL94 HB

1551ACLR Preview

10/2/2018

Subminiature Plastic Enclosures (1551MINI Series) - Hammond Mfg.

Quality Products. Service Excellence.

Subminiature Plastic Enclosures

1551MINI Series

General Purpose ABS. Three Sizes, Five Colors

Key Features

Ideally suited for mounting of printed circuit boards horizontally.

Molded in ABS plastic (material has a UL94-HB rating).

Choice of three (3) lengths in five (5) colors. Stocked in black, grey. translucent clear,

translucent smoke and translucent red.

Satin texture finish.

Cover is recessed for easy label installation.

Complete with lid and two self tapping screws (plated for grey & clear, black for all other

colors).

Two (2) or four (4) P.C. board standoffs molded into interior depending on enclosure size

(see drawings for details).

Designed to meet IP54.

For these same sizes pre-configured for a USB Type A male connector, try our

1551USB

series.

For slightly larger enclosures secured with (4) screws, try our

1551

series.

Notes

Extra self tapping lid screws are #2 x 1/2" (Plated - Qty 50 - Part number

1551USB50

and

Black - Qty 50 - Part number

1551USB50BK)

To secure P.C. board use self tapping #2 x 3/16" screws (Qty 100 - Part

number

1553WTS100)

- not included with enclosure.

Part Number

1551ABK

1551AGY

1551ACLR

1551ATSK

1551ATRD

1551BBK

1551BGY

1551BCLR

1551BTSK

1551BTRD

1551CBK

1551CGY

1551CCLR

1551CTSK

1551CTRD

Color

Black

Grey

TransClear

TransSmoke

TransRed

Black

Grey

TransClear

TransSmoke

TransRed

Black

Grey

TransClear

TransSmoke

TransRed

Length

1.38

1.97

2.56

Width

0.79

0.98

1.18

Depth

0.61

Data subject to change without notice

https://www.hammfg.com/electronics/small-case/plastic/1551mini

1/2

10/2/2018

Subminiature Plastic Enclosures (1551MINI Series) - Hammond Mfg.

https://www.hammfg.com/electronics/small-case/plastic/1551mini

2/2
