REVISION AT
DO NOT
SCALE FROM
THIS PRINT
DESIGNED & DIMENSIONED IN MILLIMETERS
(INCHES FOR REFERENCE)
(No OF POS x 0.635[.0250]) +4.750[.1870] REF
(No OF POS -1) x 0.635[.0250]
2.69 .106
REF
C
02
LSS-1XX-XX-XX-DV-XX-XX
NO OF POSITIONS
-05, -10, 20, -30, -40, -50
(PER ROW)
LEAD STYLE
-01: 3 mm (SEE TABLE 3)
-02: 6 mm (SEE TABLE 3)
-03: 4 mm (SEE TABLE 3)
OPTION
-K: POLYIMIDE FILM
(USE K-DOT-.138-.250-.005)
(SEE FIG 2, SHT 2)
-TR: TAPE & REEL
(SEE FIG 4, SHT 2)
01
0.20 .008 REF
0.635 .0250
(TOL NON-ACCUM)
SEE NOTE 4
"A"
"B"
REF
0.85 .033 REF
0.71 .028
REF (TYP)
OPTION
PLATING SPECIFICATION
-A: ALIGNMENT PIN
-L: 10µ" AU IN CONTACT AREA,
(REQUIRED FOR -01 LEAD STYLE;
MATTE TIN ON TAIL
OPTIONAL FOR -02 & -03)
(USE C-185-XX-LM)
-LC: LOCKING CLIP
-F: 3µ" AU IN CONTACT AREA,
(-02 & -03 LEAD STYLES ONLY)
MATTE TIN ON TAIL
(USE LC-08-TM-01)
(USE C-185-XX-FM)
(SEE FIG 3, SHT 2)
-H: 30µ" AU IN THE CONTACT AREA,
(SEE NOTE 6)
3µ" AU ON TAIL
(USE C-185-XX-H)
ROW SPECIFICATION
*
-LM: 10µ" AU IN CONTACT AREA,
-DV: DOUBLE VERTICAL
MATTE TIN ON TAIL
(USE C-185-XX-LM)
*
-FM: 3µ" AU IN CONTACT AREA,
MATTE TIN ON TAIL
(USE C-185-XX-FM)
*
= FOR EXISTING CUSTOMERS ONLY
C
+0.10
+.004
0.87
- 0.07
.034
- .003
(SEE NOTE 5)
LSS-XX-01-DV-A
C
+0.04
0.67
- 0.10
.026
- .004
(SEE NOTE 5)
+.002
"A"
"C" REF
C
"A" ± .076[.0030]
C
0.10 [.004]
C-185-01-XX
(No OF POS x 0.635[.0250]) +1.500[.0591]
REF
1.10 .043
REF
4.00 .157
REF
0.80 .031
REF (TYP)
C
0.160±0.130 .0063±.0051
SECTION "A"-"A"
SCALE 5 : 1
4.600±0.130 .1811±.0051
C
C
3 MAX SWAY
(TYP)
0.14 .006
REF
LSS-120-01-XX-DV-A SHOWN
FIG 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILLIMETERS.
TOLERANCES ARE:
DECIMALS
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. BURR ALLOWANCE: .038 [.0015].
3. MINIMUM PUSHOUT FORCE; TERMINALS: .5 LBS, CONTACTS: .5 LB.
4. PIN 01 WILL MATE WITH CONTACT 02 ON MATING CONNECTOR.
5. MEASURE FROM TOP OF VERTICAL WALL.
6. MINIMUM PULL OUT FORCE FOR -LC IS .75 LB.
7. FOR APPLICATIONS REQUIRING TWO OR MORE CONNECTORS PER BOARD,
CONTACT IPG@SAMTEC.COM.
.X:
.3 [.01]
2
.XX: .13 [.005]
.XXX: .051 [.0020]
ANGLES
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
INSULATOR: LCP, COLOR: BLACK
CONTACT: PHOS BRONZE
.635mm TERMINAL/SOCKET COMBO
LSS-1XX-XX-XX-DV-XX-XX
07/01/2002
SHEET
1
OF
2
F:\DWG\MISC\MKTG\LSS-1XX-XX-XX-DV-XX-XX-MKT.SLDDRW
BY:
CHAD F
REVISION AT
-K: POLYIMIDE FILM OPTION
(USE K-DOT-.138-.250-.005)
C
"E" 0.50[.020]
C
0.36±0.51 .014±.020
3.5 .14
"D"
POS 01
FIG 2
FIG 4
"B"
"B"
TUBE: PT-1-24-13-09
PLUG: TP-24
"E" =((NO OF POS X 0.635 [.0250]) + 4.750 [.1870])/2) - 1.75 [.0689]
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
SECTION "B"-"B"
SCALE 1.5 : 1
-LC: LOCKING CLIP OPTION
(USE LC-08-TM-01)
-02 & -03 LEAD STYLES ONLY
(SEE NOTE 6, SHT. 1)
TUBE: PT-1-24-11-09
PLUG: TP-09
LOAD PARTS WITH PIN #1 IN DIRECTION OF ARROW.
FIG 3
TAPE & REEL
1.3966 .055 REF
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
14.2000 .559 REF
(No OF POS x 0.635[.0250]) +1.500[.0600]
.635mm TERMINAL/SOCKET COMBO
LC-08-TM-01
F:\DWG\MISC\MKTG\LSS-1XX-XX-XX-DV-XX-XX-MKT.SLDDRW
SHEET SCALE: 4:1
LSS-1XX-XX-XX-DV-XX-XX
07/01/2002
SHEET
2
OF
2
BY:
CHAD F
