D52DK1 Overview

STARTER KIT

D52DK1 Parametric

Parameter Name	Attribute value
type	Transceiver, ANT™
frequency	-
Supporting products/related products	nRF52832
What's included	plate

Preview

Download Datasheet

View All

D52 ANT SoC Module Series

D52Q Models

D52M Models

Module Hardware



Integrated printed antenna



On-board 32MHz and 32.768 kHz crystal clocks



Supply Voltage range:

1.7V to 3.6V (D52QD2M4IA, D52MD2M8IA)

1.71V to 3.6V (D52QD2M4IA-A)



Operating temperature: Industrial (-40°C to +85°C)



Up to 30 GPIOs (D52QD2M4IA)



Up to 24 GPIOs (D52QD2M4IA-A, D52MD2M8IA)



Programmable output/channel from -20dBm to 4dBm



Excellent receiver sensitivity

-93dBm (ANT mode)

-96dBm (BLE mode)



1dBm resolution RSSI



Total 512kB flash, 64kB RAM



SPI, I2C and UART interface



ARM SWD interface



Internal DC/DC converter supported



20 x 20mm module (D52QD2M4IA, D52QD2M4IA-A)



14 x 9.8 x 2.0mm module (D52MD2M8IA)



Onboard 3-axis MEMS accelerometer (D52QD2M4IA-A)

LIS2DH by ST Microelectronics

2 programmable interrupt pins



Layout compatible options with N5150M4CD,

N550M4CC, N548M4CB, ANTAP281M4IB,

ANTC782M4IB (D52Q)



Layout compatible options with N5150M8CD,

N550M8CC, N548M8CB (D52M)



Radio regulatory approval for major markets



BLUETOOTH SIG qualification



RoHS compliant

Series Members:



D52QD2M4IA, D52QD2M4IA-A, D52QD2M6IA-A,

D52MD2M8IA

All models preloaded with ANT Network Processor

application.

ANT® Operation (using the latest s212 or s332

SoftDevice)



79 selectable RF channels (2402 to 2480 MHz)



Flexible network topologies: peer-to-peer, star, tree,

high node count, mesh and more



Broadcast, acknowledged, and burst data

communication modes



Built-in device search and pairing



Built-in interference handling and radio coexistence

management with application radio disable requests

and application flash write/erase requests



Enhanced ANT features:

Supports up to 15 logical channels each with

configurable channel periods (5.2ms - 2s)

Advanced burst data transfer modes (up to

60kbps)

Optional channel encryption mode (aes-128)

Supports up to 8 public, private and/or managed

networks

Advanced power management features to

optimize application power consumption including

Event Filtering and Selective Data Updates

Asynchronous transmit channel

Fast channel initiation

High duty search

Bluetooth®

low energy operation (when loaded with

the latest S132 or S332 SoftDevice)



Bluetooth 4.2 compliant low energy single-mode

protocol stack suitable for Bluetooth low energy

products

Concurrent Central, Observer, Peripheral, and

Broadcaster roles with:



Multiple connections as a central



One connection as a peripheral



Observer



Broadcaster

Link layer

L2CAP, ATT, and SM protocols

GATT and GAP APIs

GATT Client and Server

In certain configurations; see section 2.3 -

Pin-outs

- for

complete details

Table of Contents

D52 ANT SoC Module Series .................................................................................................................................................1

Table of Figures .....................................................................................................................................................................4

List of Tables..........................................................................................................................................................................5

Notices and Restricted Use Information .............................................................................................................................6

One Year Limited Warranty..................................................................................................................................................7

D52 ANT SoC Module Series Overview.......................................................................................................................8

1.1

1.2

1.3

1.4

Nomenclature ............................................................................................................................................... 9

Production Tracking Code ............................................................................................................................. 9

Models ....................................................................................................................................................... 10

D52 ANT SoC Module Starter Kit and Components ....................................................................................... 11

Product Overview...................................................................................................................................................... 12

2.1

2.2

2.3

D52Q Model Block Diagrams ....................................................................................................................... 12

D52M Model Block Diagram ........................................................................................................................ 13

Pin-outs ..................................................................................................................................................... 13

2.3.1

2.4

2.5

(Optional) Accelerometer Specification .......................................................................................... 17

Preloaded Software .................................................................................................................................... 17

D52 Module Programming........................................................................................................................... 18

2.5.1

2.5.2

2.5.3

Programming via SWD Interface ................................................................................................... 18

Initializing the SoftDevice ............................................................................................................. 18

Configuring the DC/DC converter .................................................................................................. 18

2.6

Design Considerations ................................................................................................................................ 18

2.6.1

2.6.2

2.6.3

D52Q M6 module mounting .......................................................................................................... 18

D52Q M4 Module Mounting........................................................................................................... 18

D52M M8 Module Mounting .......................................................................................................... 20

2.7

Assembly Considerations............................................................................................................................. 21

2.7.1

2.7.2

2.7.3

2.7.4

Moisture Control........................................................................................................................... 21

D52Q M4 Module Solder Stencil .................................................................................................... 22

D52M M8 Module Solder Stencil .................................................................................................... 22

Cleaning Process .......................................................................................................................... 22

Regulatory Approvals and Compliance ................................................................................................................... 23

3.1

3.2

3.3

3.4

3.5

3.6

United States ............................................................................................................................................. 23

Canada ...................................................................................................................................................... 23

European Economic Area ............................................................................................................................ 24

Australia and New Zealand.......................................................................................................................... 25

Japan ......................................................................................................................................................... 25

Korea ......................................................................................................................................................... 25

Page 3 of 38

D52 ANT SoC Module Series Datasheet, Rev 2.0

3.7

BLUETOOTH Qualification ........................................................................................................................... 25

Licensing & Conditions of Use .................................................................................................................................. 26

4.1

4.2

Conditions of Use ....................................................................................................................................... 26

SoftDevice Licensing ................................................................................................................................... 26

Electrical Specifications ............................................................................................................................................ 27

5.1

5.2

5.3

5.4

Recommended Operating Conditions ........................................................................................................... 27

Absolute Maximum Ratings ......................................................................................................................... 27

Radio Operation Specifications .................................................................................................................... 27

Electrical Specifications ............................................................................................................................... 29

Mechanical Drawings ................................................................................................................................................ 30

Support ...................................................................................................................................................................... 32

7.1

7.2

7.3

7.4

ANT Forum................................................................................................................................................. 32

Technical References .................................................................................................................................. 32

ANT Developer’s Zone

................................................................................................................................ 32

ANT and ANT+ Social Media ....................................................................................................................... 33

Appendix A

–

Using the ANT Network Processor Configuration .................................................................................... 34

Pin Assignments in the ANT Network Processor Configuration ................................................................................. 34

Asynchronous Serial Mode ..................................................................................................................................... 35

Byte Synchronous Serial Mode ............................................................................................................................... 37

DC/DC Configuration ............................................................................................................................................. 37

Appendix B

–

D52 Module Series Pre-Loaded Software Versions ................................................................................. 38

dynastream.com thisisant.com

Page 4 of 38

D52 ANT SoC Module Series Datasheet, Rev 2.0

Table of Figures

Figure 1: D52 Module Series Nomenclature ................................................................................................. 9

Figure 2: Production Tracking Code for D52M (left) and D52Q (right) modules ............................................. 9

Figure 3: D52QD2M4IA-A Model (with accelerometer) Module Block Diagram ............................................. 12

Figure 4: D52QD2M4IA Model (no accelerometer) Module Block Diagram ................................................... 12

Figure 5: D52MD2M4IA Model Module Block Diagram ................................................................................ 13

Figure 6: D52Q M4 (20mm x 20mm) Bottom View ..................................................................................... 14

Figure 7: D52M M8 (14.0mm x 9.8mm) Bottom View ................................................................................. 14

Figure 8: D52Q M6 (Development Module) - Top View ............................................................................... 15

Figure 9: D52Q M6 (Development Module) - Bottom View.......................................................................... 15

Figure 10: Memory Map of the Preloaded Software .................................................................................... 17

Figure 11: D52Q signal pads, component outline and keepout areas .......................................................... 18

Figure 12: D52Q Module Mounting ............................................................................................................ 19

Figure 13: D52M Module Mounting ........................................................................................................... 20

Figure 14: D52M signal pads, component outline and keepout areas .......................................................... 21

Figure 15: D52Q M4 Solder Stencil ............................................................................................................ 22

Figure 16: D52M M8 Solder Stencil ........................................................................................................... 22

Figure 17: D52Q M4 Module Typical Antenna Gain (dBi) ............................................................................ 28

Figure 18: D52M M8 Module Typical Antenna Gain (dBi) ............................................................................ 29

Figure 19: D52Q M4 Mechanical Drawing ................................................................................................. 30

Figure 20: D52M M8 Mechanical Drawing .................................................................................................. 31

Figure 21: Using ANT Network Processor .................................................................................................. 34

Figure 22: D52Q M4 ANT NP Configuration Async Serial Connection ........................................................... 36

Figure 23: D52Q M4 ANT NP Configuration Byte Sync Connection .............................................................. 37

dynastream.com thisisant.com

Page 5 of 38

D52 ANT SoC Module Series Datasheet, Rev 2.0

List of Tables

Table 1: D52 ANT SoC Module Series Models............................................................................................... 8

Table 2: D52 ANT SoC Module Series Models............................................................................................. 10

Table 3: D52 ANT SoC Module Starter Kit .................................................................................................. 11

Table 4: D52 Module Series Pin-Out .......................................................................................................... 16

Table 5: Accelerometer Pin Assignment ..................................................................................................... 17

Table 6: D52 Module Series Moisture Control Levels .................................................................................. 21

Table 7: SoftDevice Licensing and Downloads ........................................................................................... 26

Table 8: Recommended Operating Conditions ........................................................................................... 27

Table 9: Absolute Maximum Ratings ......................................................................................................... 27

Table 10: Current Consumption of Radio Operation ................................................................................... 27

Table 11: Pin Assignments in ANT Network Processor Configuration on D52Q models ................................. 34

Table 12: Pin Assignments in ANT Network Processor Configuration on D52M models ................................. 35

Table 13: Asynchronous Serial Mode Baud Rate Select .............................................................................. 35

Table 14: Byte-Sync Mode Speed Selection ............................................................................................... 37

Table 15: ANT DC/DC Configuration Command.......................................................................................... 38

Table 16: ANT DC/DC Configuration Response .......................................................................................... 38

Table 17: D52 Preloaded Software Versions .............................................................................................. 38

dynastream.com thisisant.com

D52DK1 Related Products

	D52DK1	D52QD2M4IA-REEL	D52QD2M4IA-A-TRAY	D52QD2M4IA-A-REEL	D52QD2M6IA-A-TRAY
Description	STARTER KIT	MODULE	MODULE	MODULE	STARTER KIT EXPANSION
frequency	-	2.4GHz	2.4GHz	2.4GHz	2.4GHz
RF series/standard	-	Bluetooth	Universal ISM > 1GHZ	Bluetooth	Universal ISM > 1GHZ
protocol	-	Bluetooth v4.2	ANT™	Bluetooth v4.2	ANT™
data rate	-	60kbps	60kbps	60kbps	60kbps
Power - output	-	4dBm	4dBm	4dBm	4dBm
Sensitivity	-	-96dBm	-96.5dBm	-96dBm	-96.5dBm
serial interface	-	I²C，SPI，UART	I²C，SPI，UART	I²C，SPI，UART	I²C，SPI，UART
Antenna type	-	Integrated, tracking	Integrated, tracking	Integrated, tracking	Integrated, tracking
IC/parts used	-	nRF52832	nRF52832	nRF52832	nRF52832
storage	-	512kB Flash, 64kB RAM	512kB Flash, 64kB RAM	512kB Flash, 64kB RAM	512kB Flash, 64kB RAM
Voltage - Power	-	1.7 V ~ 3.6 V	1.7 V ~ 3.6 V	1.7 V ~ 3.6 V	1.7 V ~ 3.6 V
Installation type	-	surface mount	surface mount	surface mount	surface mount
Operating temperature	-	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C	-40°C ~ 85°C
Package/casing	-	module	module	module	module

Recommended Resources

Acousto-optic digital level detector circuit diagram

Local oscillator and equivalent circuitb

Zero trigger integrated circuit temperature control circuit onea

Staircase wave signal generation circuit composed of 7555 and 4017

TDA2320 (TV) infrared remote control receiving preamplifier circuit

Color TV remote control 03

CCS installation issues: ::InstallJammer::actions::$component $this" while executing "::InstallJammer::actions::$component $this" while executing "$obj execute" (procedure "::InstallJammer::ExecuteActions" line 69) invoked fr...; dl04110514 TI Technology Forum

Understanding NB-IoT technology: There is a certain complementary effect between various access technologies, and NB-IoT can occupy a place in the field of Internet of Things by relying on its technical characteristics. PART 1/Differ...; Jacktang Wireless Connectivity

How to use PCI card to control computer restart or blue screen?: I want to make something like this now. The hardware is a PCI control chip + a single-chip microcomputer. I put this card in the PCI slot. After the computer starts, the single-chip microcomputer send...; 美丽的错误 Embedded System

Is there any harmony file for quartus ii 13.0.1?: Is there a harmonized file for Quartus II 13.0.1? :time: I see there are 12, 14, and the latest 15, but not 13. {:1_96:} I just need 13.0.1. Please help the forum master....; murongyu FPGA/CPLD

The earthquake is ruthless, but there is love in the world. Bless Yushu and share: May God bless the people of Yushu to overcome the difficulties. . ....; crh719 Embedded System

See how to translate this sentence?: // // Enable[color=red] lazy stacking[/color] for interrupt handlers. This allows floating-point // instructions to be used within interrupt handlers, but at the expense of // extra stack usage. // RO...; 平湖秋月 Microcontroller MCU

Shortcut: A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 AA AB AC AD AE AF AG AH AI AJ AK AL AM AN AO AP AQ AR AS AT AU AV AW AX AY AZ B0 B1 B2 B3 B4 B5 B6 B7 B8 B9 BA BB BC BD BE BF BG BH BI BJ BK BL BM BN BO BP BQ BR BS BT BU BV BW BX BY BZ C0 C1 C2 C3 C4 C5 C6 C7 C8 C9 CA CB CC CD CE CF CG CH CI CJ CK CL CM CN CO CP CQ CR CS CT CU CV CW CX CY CZ D0 D1 D2 D3 D4 D5 D6 D7 D8 D9 DA DB DC DD DE DF DG DH DI DJ DK DL DM DN DO DP DQ DR DS DT DU DV DW DX DZ

Popular Components
