PL
IA
NT
Features
n
Single-turn cermet/open-frame
n
2 mm size meets EIA/EIAJ standard trimmer footprint
n
RoHS compliant* - see processing information on RoHS compliant surface mount
*R
oH
S
C
OM
trimmers
n
For trimmer applications/processing guidelines, click here
F
RE
E
0.3
(.012)
2.2
(.087)
0.45
(.018)
LE
AD
1.1
(.043)
TC42 - 2 mm SMD Trimpot
®
Trimming Potentiometer
1.3
(.051)
1.5
(.059)
Product
Electrical Characteristics
Standard Resistance Range
.......................... 100 ohms to 1 megohm
(see standard resistance table)
Resistance Tolerance ................ ±25 % std.
Absolute Minimum Resistance
≤
1K Ohms ....................... 20 ohms max.
> 1K Ohms ..................... 2 % max. of TR
Contact Resistance Variation ........ 5 % max.
Resolution...................... Essentially infinite
Adjustment Angle...................... 240 ° ±20 °
Dimensions
2.2
(.087)
0.45
(.018)
0.45
(.018)
0.3
(.012)
Packaging Specifications
1.5
(.059)
5.5
(.217)
8.00
(.315)
Ro VE LEA
HS RS D
C ION FRE
OM S E
PL AR
IA E
NT
*
0.3
1.3
(.051) (.012)
1.1
0.8 ± 0.1
(.043)
(.031 ± .004)
0.3
(.012)
1.3
(.051)
1.5
(.059)
1.75 ± 0.1
(.069 ± .004)
3.25 ± 0.05
(.128 ± .002)
3.0
(.118)
Environmental Characteristics
Power Rating (50 VDC max.)
70 °C .......................................... 0.1 watt
Temperature Range ........-40 °C to +100 °C
Temperature Coefficient ........ ±250 ppm/°C
Humidity........................................95 % RH
TRS Max.............................................±5 %
Load Life .... @70 °C rated power 1000 hrs.
TRS ±5 %
Rotational Cycling....20 cycles, TRS ±10 %
Moisture Sensitivity Level ..................... N/A
ESD Classification (HBM)......................... 2
0.6
(.024)
1.3
(.051)
0.8 ± 0.1
1.0
(.039) (.031 ± .004)
2
0.45
(.018)
DIA.
1.55 ± 0.05
(.061 ± .002)
4.0 ± 0.1
(.157 ± .004)
1.5
(.059)
5.5
(.217)
8.00
(.315)
1.15 0.3
(.012)
(.045)
0.3
(.012)
1.75 ± 0.1
(.069 ± .004)
1.0
(.039)
3
1.0 1
(.039)
1.9
(.075)
2.8
(.110)
2.0 ± 0.1
(.079 ± .004)
DIA.
1.55 ± 0.05
(.061 ± .002)
1.15
(.045)
4.0 ± 0.1
(.157 ± .004)
9.0 ± 1.0
(.354 ± .039)
11.4 ± 1.0
(.449 ± .039)
4.0 ± 0.1 ± 0.05
3.25
(.157 ± .004) ± .002)
(.128
3.0
(.118)
0.7
(.028)
2
Physical Characteristics
Torque.................... 0.49 - 7.84 mN-m max.
Mechanical Angle ........Continuous rotation
Marking ..........................Part marking code
Standard Packaging ....... 3000 pcs./7 ” reel
Adjustment Tool ........................ See note
(1)
Use an adjustment tool with the following
recommended measurements:
• 1.2 mm (.047 in.) blade slot
• 0.2 mm (.008 in.) slot width
The recommended adjustment tool size is
not available from Bourns. Please contact
a Bourns representative for further
information.
(1)
0.6
(.024)
4.0 ± 0.1
(.157 ± .004)
0.6 (.039)
(.024)
1.0
(.039)
1.0
2.8
(.110)
3
1.3 1
(.051)
1.9
(.075)
2.0 ± 0.1
(.079 ± .004)
180.0 -3/+0
(7.09 -.118/+0)
0.7
(.028)
1.8
(.071)
1.0
Recommended Land
(.039)
1.0
(.039)
1.9
0.7
(.028)
Pattern
180.0 -3/+0
(7.09 -.118/+0)
9.0 ± 1.0
(.354 ± .039)
11.4 ± 1.0
(.449 ± .039)
0.6 (.075)
(.024)
1.3
(.051)
• Aqueous cleaning not recommended
• Flow soldering not recommended;
use reflow soldering
• Model TC42 is not designed to be used
with flux - use care with flux when soldering
Cautions
1.0
(.039)
1.8
(.071)
DIA.
60.0 -0/+1.0
(2.362 -0/+.039)
1.9
(.075)
0.7
(.028)
MM
DIMENSIONS:
(INCHES)
0.3
TOLERANCES: ±
EXCEPT WHERE NOTED
(0.01)
2
CCW
WIPER
CW
3
DIA.
1
CLOCKWISE
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
“Trimpot” is a registered trademark of Bourns, Inc.
Specifications are subject to change without notice.
Users should verify actual device performance in their specific applications.
The products described herein and this document are subject to specific disclaimers as set forth on the last page of this document, and at www.bourns.com/legal/disclaimer.pdf.
60.0 -0/+1.0
(2.362 -0/+.039)
