2403460 Overview

TOUCH PANEL WITH 22.9 CM/9" TFT-

2403460 Parametric

Parameter Name	Attribute value
display type	TFT - Color
display mode	conductive
touchscreen	capacitive
Screen diagonal size	9"（228.60mm）
Visible range	-
backlight	LED
dot pixel	800 x 480（WVGA）
interface	Ethernet, RS-232, USB
Graphic color	Red, green, blue (RGB)
background color	-
point size	-
point spacing	-

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/pi/products/2403460

Touch panel - TP 3090W/P - 2403460

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Touch panel with 22.9 cm/9" TFT-display (Projective-capacitive (PCAP)), 800 x 480 Pixel(s) (WVGA), 16.7

million colors, ARM Cortex -A8, 1000 MHz, 2x USB host 2.0, 1 x Ethernet (10/100 Mbps), RJ45, Windows

Embedded Compact 7 and user software: Visu+. (bus system: without)

Similar figure

Your advantages

Robust and sturdy, thanks to glass front suitable for industrial use

Fast response and display refresh, thanks to powerful processor

Flexible connection to third-party systems by means of various drivers

Integrated Visu+ visualization software

Mobile system access with the Visu+ mobile app

Key Commercial Data

Packing unit

GTIN

4055626355214

1 pc

Technical data

Note

Utilization restriction

EMC: class A product, see manufacturer's declaration in the download

area

Dimensions

External dimension, width

External dimension, height

External dimension, depth

Note regarding external dimension

Installation dimension, width

Installation dimension, height

Installation dimension, depth

Note regarding installation dimension

271 mm

179 mm

6 mm

Dimensions of the front plate

261 mm

169 mm

53 mm

Installation cutout

10/16/2018 Page 1 / 3
