HUBER+SUHNER
®
DATA SHEET
Coaxial Cable Connector: 16_QMA-50-3-3/133_N
Description
Rev.: E
Right angle cable plug
Interface Standards
QMA QLF compliant
Technical Data
Electrical Data
Impedance
Interface frequency max.
Frequency range
Return loss
50
Ω
6 GHz
DC to 2.5 GHz
≥ 32 dB
soldered
soldered
0.0072 kg
-40 °C to 85 °C
compliant
Material
Brass
Bronze
Brass
PFA / PTFE
DOU-00005833
DOU-00005835
DOC-0000241717
16_QMA-50-3-3/133_NH
16_QMA-50-3-3/133_NE
SUCOFORM_141, EZ_141_TP_M17, MULTIFLEX_141
Surface Plating
SUCOPRO Plating
SUCOPLATE (R) Plating
SUCOPRO Plating
Mechanical Data
Centre contact
Outer contact
Weight
2.5 to 4 GHz
≥ 28 dB
4 to 5 GHz
≥ 25 dB
Environmental Data
Operating Temperature
2002/95/EC (RoHS)
Piece Parts
Centre contact
Outer contact
Body
Insulator
Material Data
Related Documents
Outline drawing
Catalogue drawing
Assembly instruction
Ordering Information
Bulk 100 pcs package
Single package
Suitable cables
Additional Information
HUBER+SUHNER is certified according to ISO 9001 and ISO 14001
WAIVER!
It is exclusively in written agreements that we provide our customers with warrants and
representations as to the technical contained specifications and/or the fitness for any particular
purpose. The facts and figures herein are carefully compiled to the best of our knowledge, but they are
intended for general informational purposes only.
HUBER+SUHNER AG
RF Technology
9100 Herisau, Switzerland
Phone +41 (0)71 353 41 11
Fax
+41 (0)71 353 45 90
www.hubersuhner.com
HUBER+SUHNER – Excellence in Connectivity Solutions
Document: DOC-0000178736 T
Issued: 07.01.11
Uncontrolled Copy
Page 1/1
