PolySwitch®
PTC Devices
Overcurrent Protection Device
PRODUCT: BD280-1130-20/16
DOCUMENT: SCD26435
REV LETTER: H
REV DATE: JULY 26, 2016
PAGE: 1 OF 2
Specification Status: Released
Electrical Rating
Voltage: 14 Vdc MAX
Current: 100 A MAX
Terminal Material:
Brass H65
Thickness: 0.8mm
Tin plating thickness: 5μm
Insulating Material:
Black& Yellow color PBT,
Meets UL94V-0
Requirements
Marking:
- Manufacturer’s
Mark 14VDC - Voltage
Rating
BD280-1130-10 - Part ID
- Lot Number
TABLE I. DIMENSIONS :
A
mm :
in*:
MIN
30.0
1.181
MAX
30.6
1.205
MIN
8.7
0.343
B
MAX
9.3
0.366
MIN
10.9
0.429
MIN
10.75
0.423
I
MAX
11.5
0.453
MIN
0.8
0.031
C
MAX
11.25
0.443
MIN
6.05
0.238
J
MAX
1.2
0.047
MIN
0.6
0.024
D
MAX
6.65
0.262
E(x2)
MIN
MAX
2.55
3.05
0.1
0.12
K
MAX
1.0
0.039
F
MIN
3.3
0.13
MAX
3.9
0.154
G
H
MIN MAX MIN
MAX
3.4
4
1.7
2.3
0.134 0.157 0.067 0.091
*Rounded off approximation
INITIAL
RESISTANCE
VALUES
OHMS
AT 25°C
MIN │MAX
0.0028│0.045
Reference Documents:
Precedence:
Effectivity:
CAUTION:
TABLE II: PERFORMANCE RATINGS:
TIME TO TRIP TRIP CURRENT R1max ONE- HOLD CURRENT TRIPPED-STATE
AT 80AMPS
AT Rmin
HOUR
AT R1max
POWER
POST-TRIP
DISSIPATION
RESISTANCE
SECONDS AT
AMPS
OHMS
AMPS
WATTS AT
25°C
AT 25°C
AT 25°C
AT 25°C
20°C, 14V
MAX
MAX
MAX
MIN
TYP
10.0
26.0
0.0064
16
5.2
PS300, PS400 & SAE-J2685
This specification takes precedence over documents referenced herein.
Reference documents shall be the issue in effect on the date of invitation or bid.
Operation beyond the rated voltage or current may result in rupture, electrical arcing or flame
When using a test probe to probe either of the two test points on the top of the device, care
should be taken to avoid puncturing through the insulating material of the device, as this can
result in shorting out the terminals which can cause electrical arcing or flame.
ELV Compliant
Pb-Free
Materials Information
ROHS Compliant
© 2016 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised July 26, 2016
littelfuse.com
PolySwitch®
PTC Devices
Overcurrent Protection Device
PRODUCT: BD280-1130-20/16
DOCUMENT: SCD26435
REV LETTER: H
REV DATE: JULY 26, 2016
PAGE: 2 OF 2
