Product Bulletin
PanTher
™
LS8E and
LS8EQ
Hand-Held Thermal Transfer Printers
The PanTher
™
LS8E and LS8EQ Hand-Held Thermal Transfer Printers
produce high-quality, industrial labels on a wide variety of label materials for
electrical and network applications such as wire/cable, components, safety,
and facility identification.
A partial cut feature provides the flexibility to create tear-apart labels for quicker
installation. The printers use label cassettes that contain an integrated memory
device for automatic formatting, recall of last legend used, and the number of labels
remaining in the cassette. These fast-loading P1
™
label cassettes include both label
material and ribbon to make changing labels easy.
Part of the complete line of identification solutions from Panduit, the PanTher
™
LS8E and LS8EQ
Printers are compact, rugged, and easy to use on-site to meet the demanding requirements of
electrical and network users, while delivering productivity gains throughout the physical infrastructure.
Key Features
QWERTY keypad
Label cut-to-length functionality
Cassettes with automatic
label recognition
Fast-loading label cassette
Unique cutter design allows full
or partial label cutting
Market specific labeling tools
USB interface
Benefits
Innovative design delivers faster text entry and label design for
enhanced productivity
Eliminates label waste and time associated with trimming labels
Label cassettes contain an integrated memory device for automatic formatting,
recall of last legend used, and number of labels remaining in the cassette
Contains both label material and ribbon to make changing labels easy
Flexibility to create individually cut labels or a strip of tear-apart labels for
quicker installation
Simplify label creation for network components, panel building, and construction
and maintenance
Allows importing data, system upgrades, and printing labels from a wireless laptop
or desktop computer
Label Types
Self-Laminating Labels
Turn-Tell
®
Labels
Marker Plates
Flag Labels
Die-Cut Heat Shrink Labels
Die-Cut Vinyl Cloth Labels
Die-Cut Nylon Cloth Labels
Die-Cut Component Labels
Die-Cut Component Labels
Label Types
Continuous Heat Shrink Labels
Continuous Vinyl Cloth Labels
Continuous Nylon Cloth Labels
Continuous Terminal Block Labels
Continuous Reflective Tapes
Continuous Tapes
Ultimate ID
®
Network Labels
w w w .p an du it.c om
PanTher
™
LS8E and LS8EQ Ordering Information
Std.
Pkg.
Qty.
1
Part Number
LS8EQ-KIT-ACS
Part Description
Includes LS8EQ printer with QWERTY keypad, one cassette of S100X150VAC
self-laminating labels, six AA alkaline batteries, LS8E-ACS, LS8-CASE, LS8-PCKIT,
LS8-IB, LS8-WS, quick reference card, and operator’s manual.
LS8EQ-KIT
Includes LS8EQ printer with QWERTY keypad, one cassette of S100X150VAC
self-laminating labels, six AA alkaline batteries, LS8-CASE, LS8-PCKIT, LS8-IB,
LS8-WS, quick reference card, and operator’s manual.
1
LS8EQ
LS8EQ
Includes LS8EQ printer with QWERTY keypad, one cassette of S100X150VAC
self-laminating labels, six AA alkaline batteries, and quick reference card.
1
LS8E-KIT-ACS
Includes LS8E printer, one cassette of S100X150VAC self-laminating labels, six
AA alkaline batteries, LS8E-ACS, LS8-CASE, LS8-PCKIT, LS8-IB, LS8-WS, quick
reference card, and operator’s manual.
1
LS8E-KIT
Includes LS8E printer, one cassette of S100X150VAC self-laminating labels, six AA
alkaline batteries, LS8-CASE, LS8-PCKIT, LS8-IB, LS8-WS, quick reference card,
and operator’s manual.
1
LS8E
Includes LS8E printer, one cassette of S100X150VAC self-laminating labels, six AA
alkaline batteries, and quick reference card.
1
LS8E
Accessories for LS8E and LS8EQ printers
LS8E-ACS*
120 VAC power adapter for North America.
1
LS8-CASE
Rigid carrying case.
1
LS8-PCKIT
Includes USB cable and PC interface software for importing data, system upgrades,
or printing from a wireless laptop or desktop computer.
1
LS8-IB
Protective impact bumper.
1
LS8-WS
Wrist strap.
1
LS8-CLN
Cleaning kit.
1
*Cannot be used to charge batteries. Other adapters available, replace S with A (Australia), C (China), E (Europe), and U (UK).
2
Self-Laminating Label Cassettes
• Fast loading P1
™
Label Cassette includes both label material and ribbon to make changing labels easy
• Self-laminating adhesive labels for wire/cable identification include a colored print-on area and
clear overlaminate
Self-Laminating Vinyl (VA, VB, VD, VH, VI)
40°F to 150°F (-40°C to 66°C)
Part Number
S050X075VAC
S050X125VAC
S050X150VAC
S075X075VAC
S075X100VAC
S075X125VAC
S075X150VAC
S100X075VAC
S100X125VAC
S100X150VAC
S100X150VBC
S100X150VDC
S100X150VHC
S100X150VIC
S100X225VAC
S100X225VBC
S100X225VDC
S100X225VHC
S100X225VIC
S100X400VAC
S100X650VAC
Print-On
Area
color
White
White
White
White
White
White
White
White
White
White
TIA Blue
TIA Green
TIA Red
TIA Yellow
White
TIA Blue
TIA Green
TIA Red
TIA Yellow
White
White
Width
In.
0.50
0.50
0.50
0.75
0.75
0.75
0.75
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
mm
12.7
12.7
12.7
19.1
19.1
19.1
19.1
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
Length
In.
0.75
1.25
1.50
0.75
1.00
1.25
1.50
0.75
1.25
1.50
1.50
1.50
1.50
1.50
2.25
2.25
2.25
2.25
2.25
4.00
6.50
mm
19.1
31.8
38.1
19.1
25.4
31.8
38.1
19.1
31.8
38.1
38.1
38.1
38.1
38.1
57.2
57.2
57.2
57.2
57.2
101.6
165.1
Print-On
Area Height
In.
0.25
0.38
0.50
0.25
0.38
0.38
0.50
0.25
0.38
0.50
0.50
0.50
0.50
0.50
0.75
0.75
0.75
0.75
0.75
1.00
1.50
mm
6.4
9.7
12.7
6.4
9.7
9.7
12.7
6.4
9.7
12.7
12.7
12.7
12.7
12.7
19.1
19.1
19.1
19.1
19.1
25.4
38.1
Min. Cable
O.D.
In.
0.08
0.12
0.16
0.08
0.12
0.12
0.16
0.08
0.12
0.16
0.16
0.16
0.16
0.16
0.24
0.24
0.24
0.24
0.24
0.32
0.48
mm
2.0
3.1
4.0
2.0
3.1
3.1
4.0
2.0
3.1
4.0
4.0
4.0
4.0
4.0
6.1
6.1
6.1
6.1
6.1
8.1
12.2
Max. Cable
O.D.
In.
0.16
0.28
0.32
0.16
0.16
0.28
0.32
0.16
0.28
0.32
0.32
0.32
0.32
0.32
0.48
0.48
0.48
0.48
0.48
0.95
1.59
mm
4.0
7.0
8.1
4.0
4.0
7.0
8.1
4.0
7.0
8.1
8.1
8.1
8.1
8.1
12.2
12.2
12.2
12.2
12.2
24.3
40.4
Wire/Cable
Size Range
18 – 14 AWG
12 – 10 AWG
Cat. 5e/Cat. 6
18 – 14 AWG
12 – 10 AWG
12 – 10 AWG
Cat. 5e/Cat. 6
18 – 14 AWG
12 – 10 AWG
Cat. 5e/Cat. 6
Cat. 5e/Cat. 6
Cat. 5e/Cat. 6
Cat. 5e/Cat. 6
Cat. 5e/Cat. 6
8 – 4 AWG
8 – 4 AWG
8 – 4 AWG
8 – 4 AWG
8 – 4 AWG
2 – 1 AWG
1/0-250 MCM
Labels Std. Std.
Per
Pkg. Ctn.
Cassette Qty. Qty.
450
1
10
225
1
10
200
1
10
350
1
10
275
1
10
225
1
10
200
1
10
350
1
10
1
10
225
200
1
10
200
1
10
200
1
10
200
1
10
1
10
200
125
1
10
1
10
125
125
1
10
125
1
10
125
1
10
1
10
75
50
1
10
Order number of cassettes required.
LabelCore
™
Fiber Optic Cable Identification System
•
Provides a larger labeling surface on small fiber cables and allows legends to be clearly seen
•
Sleeve is made of flexible PVC material
•
Locate sleeve on straight section of cable at least 2 inches from fiber boot
Part Number
NWSLC-2Y-AQ
NWSLC-2Y
NWSLC-3Y
NWSLC-7Y
Part Description
Aqua, cable identification sleeve for 2mm simplex cable, 1 inch long.
Yellow, cable identification sleeve for 2mm simplex cable, 1 inch long.
Orange, cable identification sleeve for 3mm simplex cable, 1 inch long.
White, cable identification sleeve for 3mm duplex fiber cable, 1 inch long.
Std.
Pkg.
Qty
100
100
100
100
Std.
Ctn.
Qty
1000
1000
1000
1000
Order number of sleeves required.
S e l f - L a m i n a t i n g L a b e l C a s s e t t e s f o r U s e w i t h L a b e l C o r e
™
Fiber Optic Cable Identification System
Width
In.
mm
1.00 25.4
Length
In.
mm
1.60 40.6
Print-On
Min. Cable
Area Height
O.D.
In.
mm
In.
mm
0.80 20.3 0.25
6.4
Max. Wire
O.D.
In.
mm
0.25
6.4
Std. Std.
Pkg. Ctn.
Qty. Qty.
1
10
Part Number
S100X160VAC
Part Description
White print-on, self-laminating vinyl label
175/cassette. For use with NWSLC-2Y,
NWSLC-3Y, and NWSLC-2Y-AQ
White print-on, self-laminating vinyl label,
125/cassette. For use with NWSLC-7Y.
S100X220VAC
1.00
25.4
2.20
55.9
1.10
27.9
0.35
8.9
0.35
8.9
1
10
Order number of cassettes required.
3
Turn-Tell
®
Label Cassettes
• Fast-loading P1
™
Label Cassettes includes both label material and ribbon to make changing
labels easy
• Innovative label design allows labels to rotate for visibility from any angle, and for repositioning
on the wire/cable to align legends and improve aesthetics
• Labels can be easily installed on existing terminated wires and assemblies without disconnecting
the wires/cables
Polymer Film (V1, V2, V3, V7, V8)
-40°F to 200°F (-40°C to 93°C)
Part Number
Part Description
R100X075V1C
White print-on area, 18 – 14 AWG
wire/cable, 150/cassette.
R100X125V1C
White print-on area, 12 – 10 AWG
wire/cable, Cat. 3 UTP cable, 100/
cassette.
R100X150V1C
White print-on area, 10 – 6 AWG wire/
cable, Cat. 5e/6/6A UTP and
Cat. 5e FTP cable, 100/cassette.
R100X150V2C
Blue print-on area, 10 – 6 AWG wire/
cable, Cat. 5e/6/6A UTP and
Cat. 5e FTP cable, 100/cassette.
R100X150V3C
Green print-on area, 10 – 6 AWG
wire/cable, Cat. 5e/6/6A UTP and
Cat. 5e FTP cable, 100/cassette.
R100X150V7C
Red print-on area, 10 – 6 AWG wire/
cable, Cat. 5e/6/6A UTP and
Cat. 5e FTP cable, 100/cassette.
R100X150V8C
Yellow print-on area, 10 – 6 AWG
wire/cable, Cat. 5e/6/6A UTP and
Cat. 5e FTP cable, 100/cassette.
R100X225V1C
White print-on area, 8 – 4 AWG wire/
cable, Cat. 6 FTP and
Cat. 6A cable, 75/cassette.
R100X225V2C
Blue print-on area, 8 – 4 AWG wire/
cable, Cat. 6 FTP and
Cat. 6A cable, 75/cassette.
R100X225V3C
Green print-on area, 8 – 4 AWG wire/
cable, Cat. 6 FTP and
Cat. 6A cable, 75/cassette.
R100X225V7C
Red print-on area, 8 – 4 AWG wire/
cable, Cat. 6 FTP and
Cat. 6A cable, 75/cassette.
R100X225V8C
Yellow print-on area, 8 – 4 AWG wire/
cable, Cat. 6 FTP and
Cat. 6A cable, 75/cassette.
Order number of cassettes required.
Width
Color In.
mm
White 1.00 25.4
White 1.00
White 1.00
TIA
Blue
1.00
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
25.4
Length
In.
mm
0.75 19.1
1.25
1.50
1.50
1.50
1.50
1.50
2.25
2.25
2.25
2.25
2.25
31.8
38.1
38.1
38.1
38.1
38.1
57.2
57.2
57.2
57.2
57.2
Print-On
Min. Cable
Area Height
O.D.
In.
mm
In.
mm
0.25
6.4
0.12
3.1
0.38
0.50
0.50
0.50
0.50
0.50
0.75
0.75
0.75
0.75
0.75
9.7
12.7
12.7
12.7
12.7
12.7
19.1
19.1
19.1
19.1
19.1
0.16
0.22
0.22
0.22
0.22
0.22
0.28
0.28
0.28
0.28
0.28
4.1
5.6
5.6
5.6
5.6
5.6
7.1
7.1
7.1
7.1
7.1
Max. Wire
O.D.
In.
mm
0.16
4.1
0.22
0.28
0.28
0.28
0.28
0.28
0.39
0.39
0.39
0.39
0.39
5.6
7.1
7.1
7.1
7.1
7.1
9.9
9.9
9.9
9.9
9.9
Std.
Pkg.
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
Std.
Ctn.
Qty.
10
10
10
10
10
10
10
10
10
10
10
10
TIA 1.00
Green
TIA
Red
1.00
TIA 1.00
Yellow
White 1.00
TIA
Blue
1.00
TIA 1.00
Green
TIA
Red
1.00
TIA 1.00
Yellow
Marker Plate Label Cassettes
•
Fast-loading P1
™
Label Cassette includes both label material and ribbon to make changing labels easy
•
Marker plates are designed for use on larger diameter wire/cables and may be applied after all terminations are complete
•
Meets requirements for MIL-STD-202F, Notice 12 Method 215J
Polyester/Polyolefin (Y6, Y7)
-58°F to 221°F (-50°C to 105°C)
Part Number
M300X050Y6C
M300X050Y7C
4
Color
Yellow
White
Width
In.
mm
3.00
76.2
3.00
76.2
Length
In.
mm
0.50
12.7
0.50
12.7
Print-On Area Width
In.
mm
1.80
45.7
1.80
45.7
Recommended Cable Tie
Vertical
Horizontal
PLT2.5I-C
PLT2.5I-C
PLT2.5I-C
PLT2.5I-C
Std. Std.
Labels Per Pkg. Ctn.
Cassette Qty. Qty.
50
1
10
50
1
10
Order number of cassettes required.
Flag Label Cassettes
•
Fast-loading P1
™
Label Cassette includes both label material and ribbon to make changing labels easy
•
Provides larger label area for small cables
•
Innovative design allows flag labels to be applied in either adhesive or non-adhesive orientations
Polyester (AJ)
-40°F to 302°F (-40°C to 150°C)
Part Number
F100X150AJC
Color
White
Width
In.
mm
1.00
25.4
Length
In.
mm
1.50
38.1
Min. Cable O.D.
In.
mm
0.12
3.1
Max. Wire O.D.
In.
mm
0.20
5.1
Std. Std.
Labels Per Pkg. Ctn.
Wire Range Cassette Qty. Qty.
12 – 10 AWG
200
1
10
Order number of cassettes required.
Non-Laminated Label Cassettes
•
Fast-loading P1
™
Label Cassette includes both label material and ribbon to make changing labels easy
•
Non-laminated adhesive labels for wire/cable identification
•
Vinyl cloth labels can be repositioned or reused
Vinyl Cloth (CB)
Nylon Cloth (C1, C2)
50°F to 170°F (10°C to 77°C)
-40°F to 285°F (-40°C to 140°C)
Die-Cut Vinyl Cloth Labels
Part Number
N050X075CBC*
N100X075CBC
N050X150CBC*
N100X125CBC*
N100X150CBC
N100X175CBC*
Color
White
White
White
White
White
White
Width
In.
mm
0.50
12.7
1.00
25.4
0.50
12.7
1.00
25.4
1.00
25.4
1.00
25.4
Length
In.
mm
0.75
19.1
0.75
19.1
1.50
38.1
1.25
31.8
1.50
38.1
1.75
44.5
Min. Cable O.D.
In.
mm
0.12
3.1
0.12
3.1
0.24
6.1
0.20
5.1
0.24
6.1
0.28
7.1
Max. Wire O.D.
In.
mm
0.16
4.1
0.16
4.1
0.40
10.2
0.32
8.1
0.40
10.2
0.48
12.2
Wire Range
12 – 10 AWG
12 – 10 AWG
8 – 2 AWG
10 – 6 AWG
8 – 2 AWG
6 – 1 AWG
Std. Std.
Labels Per Pkg. Ctn.
Cassette Qty. Qty.
125
1
10
125
1
10
75
1
10
75
1
10
75
1
10
50
1
10
*Perforated labels can be used as full-sized or half-sized markers.
Order number of cassettes required.
Continuous Vinyl Cloth Tape
Part Number
T050X000CBC-BK
T100X000CBC-BK
Color
White
White
Height
In.
mm
0.50
12.7
1.00
25.4
Length
Ft.
m
12.5
3.8
12.5
3.8
Std.
Pkg.
Qty.
1
1
Std.
Ctn.
Qty.
10
10
Order number of cassettes required.
Die-Cut Nylon Cloth Labels
Part Number
N050X075C1C
N050X075C2C
N050X125C1C
N050X125C2C
N100X075C1C
N100X075C2C
N100X125C1C
N100X125C2C
Color
White
Yellow
White
Yellow
White
Yellow
White
Yellow
Width
In.
mm
0.50
12.7
0.50
12.7
0.50
12.7
0.50
12.7
1.00
25.4
1.00
25.4
1.00
25.4
1.00
25.4
Length
In.
mm
0.75
19.1
0.75
19.1
1.25
31.8
1.25
31.8
0.75
19.1
0.75
19.1
1.25
31.8
1.25
31.8
Min. Cable O.D.
In.
mm
0.12
3.1
0.12
3.1
0.20
5.1
0.20
5.1
0.12
3.1
0.12
3.1
0.20
5.1
0.20
5.1
Max. Wire O.D.
In.
mm
0.16
4.1
0.16
4.1
0.32
8.1
0.32
8.1
0.16
4.1
0.16
4.1
0.32
8.1
0.32
8.1
Wire Range
12 – 10 AWG
12 – 10 AWG
10 – 6 AWG
10 – 6 AWG
12 – 10 AWG
12 – 10 AWG
10 – 6 AWG
10 – 6 AWG
Std. Std.
Labels Per Pkg. Ctn.
Cassette Qty. Qty.
250
1
10
250
1
10
150
1
10
150
1
10
250
1
10
250
1
10
150
1
10
150
1
10
5
Order number of cassettes required.
京公网安备 11010802033920号
EEWORLD
