Finisar
Product Specification
2.5Gbps 850nm PIN + Preamp, LC ROSA
HFD3180-103
PRODUCT FEATURES
•
•
LC ROSA
High performance GaAs PIN
photodiode with separate
transimpedance amplifier
Low electrical parasitic
TO46 package
Data rates from 155Mbps
to 2.5Gbps
•
•
A separate detector bias pin which can
be used for receive power monitoring
Low bias currents and voltages
•
•
•
The HFD3180-103 use a high-performance GaAs PIN photo-detector packaged with a
transimpedance amplifier designed to meet performance requirements for data rates up to
2.5Gbps data communication over multi-mode optical fiber at 850nm. Applications include
Ethernet, Fiber Channel and ATM protocols. The optical assembly is designed to interface either
50mm or 62.5mm multi-mode fiber.
The HFD3180-103 is designed to be paired with Advanced Optical Components VCSEL TOSA
products (see data sheets for HFE419x products).
PRODUCT SELECTION
Part Number
HFD3180-103
Description
5 pin LC ROSA, with separate PD bias for RSSI
Confidential and Proprietary © 2013 Finisar Corporation. All rights reserved
Rev. A1
Page 1
HFD3180-103
Product Specification – Aug 2014
Finisar
I. Absolute Maximum Ratings
Parameter
Storage Temperature
Case Operating Temperature
Lead Solder Temperature
Power Supply Voltage
Incident Optical Power
Rating
-40 to +85°C
-40* to +85°C
260°C, 10 sec.
-0.5V to 4V
+3 dBm average, +6 dBm peak
Notice
Stresses greater than those listed under “Absolute Maximum Ratings”
may cause permanent damage to the device. This is a stress rating
only and functional operation of the device at these or any other
conditions above those indicated in the operations section for
extended periods of time may affect reliability.
Notice
The inherent design of this component causes it to be sensitive to
electrostatic discharge (ESD). To prevent ESD-induced damage
and/or degradation to equipment, take normal ESD precautions when
handling this product
Confidential and Proprietary © 2013 Finisar Corporation. All rights reserved
Rev. A1
Page 2
HFD3180-103
Product Specification – Aug 2014
Finisar
II.
Parameters
Data Rate
Supply Voltage
Supply Current
Electro-Optical Characteristics
Test Condition
Symbol
DR
P
R
=0µW, R
L
=50Ω AC
coupled
P
R
=-12dBm
0
o
C to 70
o
C
I
CC
ORL
λ
P
P
MAX
V
o(pk-pk)
T
BW
BW
LF
Z
OUT
S
22
NEP
12
770
0
100
1500
1.4
3.0V<Vcc<3.6V, AC coupled to 50Ω
(100Ω
differential), -40°C<T<85°C unless otherwise specified
Ω
°
°
Min.
0.15
3.0
Typ.
3.3
25
Max.
2.5
3.6
35
Units
Gbps
V
mA
dB
nm
dBm
mV
V/W
GHz
Notes
1
1
Optical Return Loss
Input Optical Wavelength
Maximum Average Input Power
before Overload
Differential Output Voltage Swing
Differential Transimpedance
-3dB Optical/Electrical Bandwidth
Low Frequency –3dB Cutoff
Output Impedance
Output Return Loss
RMS Input Referred Noise
Equivalent Power
Sensitivity, OMA
Stressed Sensitivity, OMA
Rise/Fall Time
Pulse Width Distortion
Power Supply Rejection Ratio
Monitor Current Slope
Monitor Current Offset
PD Bias Voltage
Group Delay
850
+3
150
2500
2
870
P
R,OMA
= -12Bm,
AC Coupled to R
L
=50Ω
P
R,OMA
= -12dBm,
AC Coupled to R
L
=50Ω
P
R,OMA
=-12dBm
P
R,OMA
=-12dBm
F<2GHz
1.875GHz, 4-pole BT
Filter, P
R
=0uW (Dark),
BER 10^-12
DR <= 2.5Gbps
DR <= 2.5Gbps
P
R,OMA
=-12dBm, (20%-
80%)
P
R
=0µW (Dark),
5MHz<F<2GHz
P
R
=-12dBm
P
R
=0mW
220
3500
1,2
1,2
1,2,3
1,2,3
42
8
50
12
10
58
20
KHz
Ω
dB
µW,
OMA
4
S
S
Stressed
T
R
/T
F
PWD
PSRR
I
MON
I
OFFSET
PD
BIAS
Delay
-20
-17
120
-18
-14
150
5
dBm
dBm
ps
%
dB
A/W
nA
V
ps
5
5,6
2,7
20
0.45
Vcc-1
-50
0.5
Vcc
0.55
10
Vcc+0
.5
50
1,8
9
Deterministic Jitter
Random Jitter
P
R,OMA
= -12dBm,
AC Coupled to R
L
=50Ω
2MHz<F<2GHz
P
R,OMA
= -12dBm,
AC Coupled to R
L
=50Ω
P
R,OMA
= -12dBm,
AC Coupled to R
L
=50Ω
10
DJ
TIA
RJ
TIA
30
3
40
5
ps
ps
11
12
Confidential and Proprietary © 2013 Finisar Corporation. All rights reserved
Rev. A1
Page 3
HFD3180-103
Product Specification – Aug 2014
Finisar
Notes:
1. P
R
is the average optical power at the fiber face.
2. P
R,OMA
is the peak to peak optical power at the fiber face (Optical Modulation
Amplitude)
2
P
(
ER
−
1
)
P
R
,
OMA
≡
R
where ER is the extinction ratio (linear) of the optical
ER
+
1
source.
3. Bandwidth and Low Frequency Cutoff are measured with a small signal sinusoidal
light source with –12dBm average power
4. RMS input referred optical noise equivalent power is obtained by measuring the RMS
output noise into a 3200 MHz, 4-pole Bessel-Thompson filter then dividing by the
responsivity. A scaling factor of 14 is used to predict a BER of 10
-12
.
5. Sensitivity is measured with an optical source with an extinction ratio of 3dB.
6. Stressed receiver sensitivity is measured with 3.5dB vertical eye closure (intersymbol
interference) and with 0.3UI of jitter added. The measurement technique is defined in
IEEE 802.3ae.
7.
Rise/Fall times are corrected for optical source Rise/Fall times.
2
2
2
T
TIA
=
T
MEASURED
−
T
OPTICAL
8. Value shown is with no external power supply filtering.
9. The monitor current slope is measured as the current into the PD
BIAS
connection.
10. Group delay is a sensitive measurement to package interface, and includes the effects
of PD, TIA and package. Measurement is made with TO leads as short as possible.
11. DJ
TIA
is specified as contributed DJ by the TIA, obtained from
2
2
2
DJ
TIA
=
DJ
TOTAL
−
DJ
OPTICAL
12. RJ
TIA
is specified as contributed DJ by the TIA, obtained from
2
2
2
RJ
TIA
=
RJ
TOTAL
−
RJ
OPTICAL
13. If external bias voltage is applied to Vpd while Vcc is externally unbiased, internal
biasing of the TIA will occur, resulting in erroneous RSSI current.
Confidential and Proprietary © 2013 Finisar Corporation. All rights reserved
Rev. A1
Page 4
HFD3180-103
Product Specification – Aug 2014
Finisar
III.
Interface configuration
V
PD
100Ω
V
CC
HFD3180-203
V
CC
V
PD
OUTN
OUTP
Case
50Ω
50Ω
20x
RSSI ~ 1V/mW
100Ω
Note: 100Ω resistor
only needed with
high impedance
limit ing amplifiers
Optional RSSI implementation is shown in blue.
Optional 100
Ω
differential termination for high impedance limiting amplifiers is
shown in red.
Recommended bias filter network
Note, better performance will be obtained if a ferrite bead is used in place of the
inductor.
IN
22uH
OUT
100uF
100nF
Confidential and Proprietary © 2013 Finisar Corporation. All rights reserved
Rev. A1
Limiting Amp
Page 5
100nF
