TESDUB5V0/12V/24V
Taiwan Semiconductor
Small Signal Product
Bi-directional ESD Protection Diode
FEATURES
- Meet IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact)
- Protects one Bi-directional I/O line
- Low clamping voltage
- Working Voltage : 5, 12 and 24V
- High component density
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
0603-B
MECHANICAL DATA
Case:
0603-B standard package molded plastic
Terminals:
Gold plated, solderable per MIL-STD-750, method 2026
Weight:
3 mg (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
TESDUB5V0
Diode breakdown voltage
TESDUB12V
TESDUB24V
TESDUB5V0
Leakage current
TESDUB12V
TESDUB24V
TESDUB5V0
Junction capacitance
TESDUB12V
TESDUB24V
ESD capability
TESDUB5V0
Clamping voltage
TESDUB12V
TESDUB24V
TESDUB5V0
Peak pulse power
Junction temperature range
Storage temperature range
TESDUB12V
TESDUB24V
T
J
T
STG
T
P
=8/20μs
P
PP
IEC 61000-4-2 (air)
IEC 61000-4-2 (contact)
I
PP
=5A, T
P
=8/20μs
I
PP
=1A, T
P
=8/20μs
I
PP
=1A, T
P
=8/20μs
Vc
ESD
VR=5V
VR=12V
VR=24V
VR=0V,
f=1MHz
C
T
I
L
IR=1mA
V
BO
CONDITIONS
SYMBOL
MIN
5.1
13
25
-
-
-
-
-
-
-
-
-
-
-
-
-
-
TYP
7
17
28
0.1
-
-
15
12
10
-
-
-
-
-
-
-
-
-55 to +125
-55 to +150
MAX
-
-
-
2
-
-
20
-
-
15
8
15
25
47
75
25
47
°C
°C
W
V
KV
pF
μA
V
UNIT
Version: C1601
TESDUB5V0/12V/24V
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
PART NO.
TESDUBxxx
(Note 1, 2)
PACKING CODE
RG
PACKING CODE
SUFFIX
G
PACKAGE
0603-B
PACKING
4K / 7" Reel
Note 1: "xxx" defines voltage from 5V (TESDUB5V0) to 24V (TESDUB24V)
Note 2: Whole series with green compound
EXAMPLE
EXAMPLE P/N
TESDUB5V0 RGG
PART NO.
TESDUB5V0
PACKING CODE
RG
PACKING CODE
SUFFIX
G
DESCRIPTION
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
Fig. 1 8/20μs Peak pulse current waveform
acc. IEC 61000-4-5
tr = 8μs to 100%
80
1
Reverse current (μA)
Fig. 2 Reverse characteristics
10
100
Percent of I
PPM
60
0.1
40
20μs to 50μs
20
0.01
0
0
10
20
Time (μs)
30
40
0.001
0
20
40
60
Time (μs)
80
100
Fig. 3 Capacitance between terminals characteristics
15
5V0
12
Capacitance(pF)
Power Rating (%)
12V
9
24V
6
120
100
80
60
40
20
0
0
0
10
20
Reverse voltage (V)
30
40
0
25
Fig.4 Power derating curve
Mounting on glass epoxy PCB
Fig. 4
3
50
75
100
125
150
Ambient Temperature (
°
C)
Version: C1601
TESDUB5V0/12V/24V
Taiwan Semiconductor
Small Signal Product
DIMENSIONS
0603-B
DIM.
A
B
C
D
E
F
Unit (mm)
Min
1.60
0.80
0.30
0.70
0.65
0.28
Max
1.80
1.00
0.45
0.85
0.75
0.35
Unit (inch)
Min
0.063
0.031
0.012
0.028
0.026
0.011
Max
0.071
0.039
0.018
0.033
0.030
0.014
SUGGESTED PAD LAYOUT
DIM.
G
X
X1
Y
Unit (mm)
0.80
0.60
2.00
0.80
MARKING
Part No.
TESDUB5V0
TESDUB12V
TESDUB24V
Marking
E05
E12
E24
Version: C1601
TESDUB5V0/12V/24V
Taiwan Semiconductor
Small Signal Product
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf,
assumes no responsibility or liability for any errors or inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to
any intellectual property rights is granted by this document. Except as provided in TSC's terms and conditions of
sale for such products, TSC assumes no liability whatsoever, and disclaims any express or implied warranty,
relating to sale and/or use of TSC products including liability or warranties relating to fitness for a particular purpose,
merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications.
Customers using or selling these products for use in such applications do so at their own risk and agree to fully
indemnify TSC for any damages resulting from such improper use or sale.
Version: C1601
